X470D4U
B450D4U-V1L
User Manual
Version 1.0
Published August 2019
Copyright©2019 ASRock Rack INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X470D4U/BULK/VN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK X470D4U/BULK/VN

Summary of Contents for ASROCK X470D4U/BULK/VN

  • Page 1 X470D4U B450D4U-V1L User Manual Version 1.0 Published August 2019 Copyright©2019 ASRock Rack INC. All rights reserved.
  • Page 2 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRock Rack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,...

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Expansion Slots (PCI Express Slots) Jumpers Setup Onboard Headers and Connectors Dr.
  • Page 5 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 Storage Configuration 3.3.4 ACPI Configuration 3.3.5 USB Configuration 3.3.6 Super IO Configuration 3.3.7 H/W Monitor 3.3.8 AMD CBS 3.3.9 AMD PBS 3.3.10 Instant Flash Server Mgmt 3.4.1 System Event Log 3.4.2 BMC Network Configuration...
  • Page 6 Support CD Information 4.2.1 Running The Support CD 4.2.2 Drivers Menu 4.2.3 Utilities Menu 4.2.4 Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 8: Specifications

    1.2 Specifications X470D4U / B450D4U-V1L MB Physical Status Form Factor micro-ATX Dimension 9.6'' x 9.6'' (24.4 cm x 24.4 cm) Processor System AMD AM4 Socket Ryzen™ PRO/ Ryzen™ 2 and 3 generation series processors Socket AM4 PGA 1331 Chipset AMD X470 / B450 System Memory Capacity - 4 x 288-pin DDR4 DIMM slots...
  • Page 9 X470D4U / B450D4U-V1L X470D4U: LAN Controller - 2 x RJ45 GLAN by Intel® I210AT - 1 x RJ45 Dedicated IPMI LAN port - Supports Wake-On-LAN - Supports Energy Efficient Ethernet 802.3az - Supports Dual LAN with Teaming function - Supports PXE - LAN1 supports NCSI B450D4U-V1L: - 1 x RJ45 GLAN by Intel®...
  • Page 10 16MB AMI UEFI Legal BIOS BIOS Features - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8 Support - ASRock Rack Instant Flash Hardware Monitor Temperature - CPU/DDR temperature sensing - MB/Card side temperature sensing...
  • Page 11 X470D4U / B450D4U-V1L Support OS Microsoft® Windows®: Windows 10 (64 bit) Linux®: - UBuntu 16.04.4 (64 bit) - RedHat Enterprise Linux Server 7.3 (64bit) - RedHat Enterprise Linux Server 7.4 (64bit) * Please refer to our website for the latest OS support list. *The Linux system doesn’t support Raid mode.

  • Page 12: Unique Features

    POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 13: Motherboard Layout

    X470D4U / B450D4U-V1L 1.4 Motherboard Layout 24.4cm (9.6 in) UID1 (X470D4U only) ATXPWR1 PSU_SMB1 (X470D4U only) FAN2 DDR4_B1 (64 bit, 288-pin moule) FAN3 FAN4 DDR4_B2 (64 bit, 288-pin module) NUT110_2 NUT110_1 DDR4_A1 (64 bit, 288-pin module) DDR4_A2 (64 bit, 288-pin module) LAN1 FAN1 NUT80_2...
  • Page 14 Description ATX 12V Power Connector (ATX12V1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue) PSU SMBus Header (PSU_SMB1) (X470D4U only) ATX Power Connector (ATXPWR1) Front Fan Connector (FAN3) Front Fan Connector (FAN4) Front Fan Connector (FAN2) 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White) CPU Fan Connector (FAN1) AM4 PGA 1331 Socket M.2 Socket (M2_2) (Type 2242 / 2260 / 2280 / 22110)
  • Page 15 X470D4U / B450D4U-V1L Description Chassis ID1 Jumper (CHASSIS_ID1) (X470D4U only) Chassis ID2 Jumper (CHASSIS_ID2) (X470D4U only) BMC SMBus Header (BMC_SMB_1) (X470D4U only) Intelligent Platform Management Bus header (IPMB1) (X470D4U only) PWM Configuration Header (PWM_CFG1) *For DIMM installation and configuration instructions, please see p.22 (Installation of Memory Modules (DIMM)) for more details.

  • Page 16: Onboard Led Indicators

    1.5 Onboard LED Indicators PSU_SMB1 DDR4_B1 (64 bit, 288-pin moule) FAN2 FAN3 FAN4 DDR4_B2 (64 bit, 288-pin module) NUT110_2 NUT110_1 DDR4_A1 (64 bit, 288-pin module) DDR4_A2 (64 bit, 288-pin module) FAN1 NUT80_2 NUT80_1 ATX12V1 NUT60_2 NUT60_1 NUT42_2 NUT42_1 RoHS PWM_CFG1 M2_2 M2_1 X470D4U...
  • Page 17 X470D4U / B450D4U-V1L Item Status Description SB_PWR1 Green STB PWR ready FAN_LED4 Amber FAN4 failed FAN_LED3 Amber FAN3 failed FAN_LED2 Amber FAN2 failed FAN_LED1 Amber FAN1(CPU) failed FAN_LED5 Amber FAN5 failed FAN_LED6 Amber FAN6 failed BMC_LED1 Green BMC heartbeat LED...

  • Page 18: I/O Panel

    1.6 I/O Panel No. Description No. Description GLAN RJ-45 Port (LAN2) UID Switch (UID1) (X470D4U only) (X470D4U only) VGA Port (VGA1) USB 3.1 Gen1 Ports (USB3_1_2) LAN RJ-45 Port (IPMI_LAN1) Serial Port (COM1) (X470D4U only) (X470D4U only) GLAN RJ-45 Port (LAN1) *There are two LED next to the LAN port.
  • Page 19 X470D4U / B450D4U-V1L **There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port LAN Port (LAN1, LAN2) LED Indications Activity / Link LED Speed LED Status Description Status...

  • Page 20: Block Diagram

    1.7 Block Diagram X470D4U...
  • Page 21 X470D4U / B450D4U-V1L B450D4U-V1L...

  • Page 22: Chapter 2 Installation

    Chapter 2 Installation This is a micro-ATX form factor (9.6” x 9.6”, 24.4 cm x 24.4 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

  • Page 23: Installing The Cpu

    X470D4U / B450D4U-V1L 2.3 Installing the CPU Unplug all power cables before installing the CPU.

  • Page 25: Installing The Cpu Fan And Heatsink

    X470D4U / B450D4U-V1L 2.4 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 27 X470D4U / B450D4U-V1L...

  • Page 28: Installing Memory Modules (Dimm)

    2.5 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs. 2.
  • Page 29 X470D4U / B450D4U-V1L The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 30: Expansion Slots (Pci Express Slots)

    2.6 Expansion Slots (PCI Express Slots) There are 3 PCI Express slots on this motherboard. PCIE slot: PCIE4 (PCIE 3.0 x16 slot, from CPU) is used for PCI Express x8 lane width cards. (X470D4U only) PCIE5 (PCIE 3.0 x8 slot, from CPU) is used for PCI Express x4 lane width cards. PCIE6 (PCIE 3.0 x16 slot, from CPU) is used for PCI Express x16 lane width cards.
  • Page 31 X470D4U / B450D4U-V1L Step 4. Align the card connector with the slot and press firmly until the card is completely seated on the slot. Step 5. Fasten the card to the chassis with screws. Step 6. Replace the system cover.

  • Page 32: Jumpers Setup

    2.7 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
  • Page 33 X470D4U / B450D4U-V1L X470D4U: Chassis ID1 Jumper (3-pin CHASSIS_ID1) (see p.7, No. 32) Chassis ID2 Jumper (3-pin CHASSIS_ID2) (see p.7, No. 33) Chassis ID3 Jumper Reserved for system level Reserved for system level (3-pin CHASSIS_ID3) (see p.7, No. 31) X470D4U: Chassis ID1 Jumper (3-pin CHASSIS_ID1) (see p.7, No.

  • Page 34: Onboard Headers And Connectors

    2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header C onnec t t he power sw itch, PLED+ PLED-...
  • Page 35 X470D4U / B450D4U-V1L X470D4U: Auxiliary Panel Header This header supports multiple (18-pin AUX PANEL1) functions on the front panel, (see p.7, No. 27) including the front panel SMB, internet status indicator and chassis intrusion pin. B450D4U-V1L: A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows you to connect SMBus (System Management Bus) equipment.
  • Page 36 X470D4U: The SATA3 DOM Serial ATA3 DOM connector supports SATA3_0 Connector both a SATA DOM (SATA3_0) (Disk-On-Module) and (see p.7, No. 14) a SATA data cable for internal storage device. Serial ATA3 Connectors These connectors X470D4U: support SATA data SATA3_1 SATA3_0 (SATA3_1: cables for internal...
  • Page 37 4 -P i n C PU f a n (Q u ie t FAN_VOLTAGE (see p.7, No. 9) Fan) connectors. If you plan CPU_FAN_SPEED FAN_SPEED_CONTROL to connect a 3-Pin CPU fan, please connect it to Pin 1-3. *For more details, please refer to the Cooler QVL list on the ASRock Rack website.
  • Page 38 ATX Power Connector This motherboard provides a (24-pin ATXPWR1) 24-pin ATX power connector. (see p.7, No. 4) To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATX 12V Power This motherboard provides Connectors one 8-pin ATX 12V power (8-pin ATX12V1) connector.
  • Page 39 X470D4U / B450D4U-V1L X470D4U: The header is used for the SM Baseboard Management BUS devices. BMC_SMB_PRESENT_1_N Controller SMBus Header Power (5-pin BMC_SMB_1) BMC_SMBCLK (see p.7, No. 34) BMC_SMBDATA PWM Configuration This header is used for PWM Header configurations. (3-pin PWM_CFG1) (see p.7, No.

  • Page 40: Dr. Debug

    2.9 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31 PEI_MEMORY_INSTALLED 0x32 PEI_CPU_INIT 0x33 PEI_CPU_CACHE_INIT...
  • Page 41 X470D4U / B450D4U-V1L 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 42 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 43 X470D4U / B450D4U-V1L 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 44 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 45 X470D4U / B450D4U-V1L 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...

  • Page 46: Unit Identification Purpose Led/Switch

    2.10 Unit Identification purpose LED/Switch With the UID button, You are able to locate the server you’re working on from behind a rack of servers. X470D4U: When the UID button on the Unit Identification front or rear panel is pressed, purpose LED/Switch the front/rear UID blue LED (UID1)

  • Page 47: M.2_Ssd (Ngff) Module Installation Guide (X470D4U Only)

    X470D4U / B450D4U-V1L 2.12 M.2_SSD (NGFF) Module Installation Guide (X470D4U only) The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2_SSD (NGFF) Socket 3 (M2_1) can accommodate either a M.2 PCI Express module up to Gen 2 x4 (20Gb/s).
  • Page 48 Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location D by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand.

  • Page 49: Chapter 3 Uefi Setup Utility

    X470D4U / B450D4U-V1L Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer.

  • Page 50: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 51: Main Screen

    X470D4U / B450D4U-V1L 3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date.

  • Page 52: Advanced Screen

    3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, H/W Monitor, PSP Firmware Versions, AMD CBS, AMD PBS and Instant Flash. Setting wrong values in this section may cause the system to malfunction.

  • Page 53: Cpu Configuration

    X470D4U / B450D4U-V1L 3.3.1 CPU Configuration PSS Support Enable/disable the generation of ACPI _PPC, _PSS, and _PCT objects. AMD fTPM Switch To select .0: Auto (Depend on Tcg module). 1: Disabled fTPM. 2: OnBoard SPI TPM2.0 SVM Mode Enable/disable CPU Virtualization. CPB Mode Enable/disable CPB.

  • Page 54: Chipset Configuration

    3.3.2 Chipset Configuration Onboard VGA To enable or disable Onboard VGA. Above 4G Decoding Globally Enables or Disables 64bit capable Devices to be Decoded in Above 4G Address Space (Only if System Supports 64 bit PCI Decoding). SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.

  • Page 55: Storage Configuration

    X470D4U / B450D4U-V1L 3.3.3 Storage Configuration PT SATA Port Enable Enable/disable the SATA controllers. PT SATA Mode Select Promontory SATA Type. SATA Hot Plug Enable/disable the SATA Hot Plug Function.

  • Page 56: Acpi Configuration

    3.3.4 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. RTC Alarm Power On Use this item to enable or disable RTC (Real Time Clock) to power on the system.

  • Page 57: Usb Configuration

    X470D4U / B450D4U-V1L 3.3.5 USB Configuration Legacy USB Support Use this option to enable or disable legacy support for USB devices. The default value is [Enabled].

  • Page 58: Super Io Configuration

    3.3.6 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the serial port. Serial Port Address Use this item to select an optimal setting for Super IO device. SOL Configuration Use this item to set parameters of SOL.

  • Page 59: H/W Monitor

    X470D4U / B450D4U-V1L 3.3.7 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. Fan Control If [Auto] is selected, the fan speed will controlled by BMC.
  • Page 60 FAN 6 This allows you to set the front fan 6’s speed. The default value is [Smart Fan]. Smart Fan Control This allows you to set the Smart fan’s level speed. Smart Fan Duty Control Smart Fan Duty x (x means 1 to 11 stage) This allows you to set duty cycle for each stage.

  • Page 61: Amd Cbs

    X470D4U / B450D4U-V1L 3.3.8 AMD CBS Zen Common Options Use this item to configure Zen Common options. DF Common Options Use this item to configure DF Common options. UMC Common Options Use this item to configure UMC Common options. NBIO Common Options Use this item to configure NBIO Common options.

  • Page 62: Amd Pbs

    3.3.9 AMD PBS AMD Firmware Version Show all of AMD Firmware Version. BIOS PSP Support Enable/Disable BIOS PSP driver execution (including all C2P/P2C mailbox, Secure S3, fTPM Support). MITT/WITT Selection Use this item to configure MITT/WITT Selection. LAN Power Enable Enable or disable LAN Power.
  • Page 63 X470D4U / B450D4U-V1L Clear CMA at warm rst Enable or disable clearing MCA errors at warm reset. If Enabled, just clear MCA status including that MC0: MSR0000_0401, MC1: MSR0000_0405, MC2: MSR0000_0409, MC4: MSR0000_0411 and MC5: MSR0000_0415. Win7 USB Wake Support This option enables USB devices to wake up the system (work with Win7 only).
  • Page 64 AMD Fan Policy [Air Cooling] follows platform defined policy, [Water Cooling] forces PWM 100%; Selecting [Fan Control] to [Manual] in CBS will override this option. PcieLanes_4_7_Switch [PT] Pcie Lanes route to PT CHIP; [CPU] Pcie Lane route to CPU PCIE. Above 4GB MMIO Enable Enable or disable Above 4GB MMIO.

  • Page 65: Instant Flash

    X470D4U / B450D4U-V1L 3.3.10 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems ® first like MS-DOS or Windows . Just save the new UEFI file to your USB flash drive, floppy disk or hard drive and launch this tool, then you can update your UEFI only in a few clicks without preparing an additional floppy diskette or other compli- cated flash utility.

  • Page 66: Server Mgmt

    3.4 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces.

  • Page 67: System Event Log

    X470D4U / B450D4U-V1L 3.4.1 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 68: Bmc Network Configuration

    3.4.2 BMC Network Configuration Lan Channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If you prefer using a static IP address, toggle to [Yes], and the changes take effect after the system reboots. The default value is [No].
  • Page 69 X470D4U / B450D4U-V1L The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/faq.asp...

  • Page 70: Security

    3.5 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 71: Key Management

    X470D4U / B450D4U-V1L 3.5.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Provision Factory Defaults Allow to provision factory default Secure Boot keys when System is in Setup Mode. Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time you use secure boot.
  • Page 72 d) EFI_CERT_SHA256, 384, 512 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed, Test Key Exchange Keys Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256, 384, 512 2.
  • Page 73 X470D4U / B450D4U-V1L a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256, 384, 512 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed, Test Authorized TimeStamps Enroll Factory Defaults or load certificates from a file: 1.

  • Page 74: Boot Screen

    3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order. Boot Option Filter This option controls Legacy/UEFI ROMs priority.
  • Page 75 X470D4U / B450D4U-V1L Boot Beep Select whether the Boot Beep should be turned on or off when the system boots up. Please note that a buzzer is needed. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled]. AddOn ROM Display Use this option to adjust AddOn ROM Display.

  • Page 76: Csm Parameters

    3.6.1 CSM Parameters Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows Server 2012 R2 or later ver- sions 64-bit UEFI and all of your devices support UEFI, you may also disable CSM for faster boot speed.
  • Page 77 X470D4U / B450D4U-V1L PCIE6 Slot OpROM Use this item to select slot storage and Network Option ROM policy. In Auto option, the default is Disabled with NVMe device, but it is Legacy with other devices. (This item can't select Video Option ROM policy.)

  • Page 78: Exit Screen

    3.7 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...

  • Page 79: Chapter 4 Software Support

    4.2.4 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 80: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 81 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 82: Technical Support Procedures

    5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.
