SIGNIFY HADCO ML4D3 Installation Instructions

Advertisement

Quick Links

Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873
Telephone 855-486-2216
ML4D3/ML4DW3
Installation Instructions
1.
Make sure power is turned OFF before installing or servicing this fixture.
2.
Attach fixture to a junction box or mounting stake that is UL listed for low voltage and wet locations.
Mounting stakes S1, S6, S7, S8, or canopy MC1, M0040, or junction box TM1H may be used.
3.
Wire fixture following the instructions for low voltage cable connector.
Input voltage (VAC): 10.8-17 @ 60 Hz
Fixture load: 6.5W max
4.
Turn fixture ON.
This fixture is intended for installation in accordance with the National Electrical Code and local code
specifications. Failure to adhere to these codes and instructions may result in serious injury and/or damage
to the ballast and void the warranty. These instructions do not purport to cover all details or variations in
equipment, nor to provide for every possible contingency related to installation, operation, maintenance,
or mounting situation. Should specific problems occur that are not addressed by these instructions, contact
your Sales Representative or distributor for assistance. Retain these instructions for future reference.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR INJURY TO PERSONS-IMPORTANT SAFETY INSTRUCTIONS
Lighted lamp is HOT! WARNING- To reduce the risk of FIRE OR INJURY TO PERSONS: Turn off/unplug and
allow to cool before replacing lamp. Lamp gets HOT quickly! Contact only switch/plug when turning on.
Do not touch hot lens, guard, or enclosure (see diagram/picture). Keep lamp away from materials that
may burn. Do not touch the lamp at any time. Use a soft cloth. Oil from skin may damage lamp. Do not
operate the luminaire fitting with a missing or damaged shield. SAVE THESE INSTRUCTIONS.
Xenon lamps do not require additional shielding.
32001460, revision E
Signify Canada Ltd.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Telephone 800-668-9008
ROOF
STEM
1/2-14 NPS
RL9D3/RL9DW3
INSTALLATION INSTRUCTIONS:
ML4D3/ML4DW3/AL4D3/AL4DW3/
AL41D3/AL41DW3/TRL4D3/TRL4DW3
RL9D3/RL9DW3 - PATHLYTES
AL4D3/AL4DW3/
AL41D3/AL41DW3
TRL4D3/TRL4DW3
page 1 of 2
