Rippton CatchX BLACK SAMURAI Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

CATCHX BLACK SAMURAI
QUICK START GUIDE
Edited on 2023/05/23
Please visit
https://rippton.com/tutorial
to watch the video tutorial of CatchX BLACK SAMURAI.
PLEASE READ SECTION 6 AND 7 IN THE USER MANUAL
BEFORE READING THIS GUIDE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CatchX BLACK SAMURAI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rippton CatchX BLACK SAMURAI

Summary of Contents for Rippton CatchX BLACK SAMURAI

  • Page 1 CATCHX BLACK SAMURAI QUICK START GUIDE Edited on 2023/05/23 Please visit https://rippton.com/tutorial to watch the video tutorial of CatchX BLACK SAMURAI. PLEASE READ SECTION 6 AND 7 IN THE USER MANUAL BEFORE READING THIS GUIDE.
  • Page 2 You can control BLACK SAMURAI either by our app named “Rippton Boat” (no social function) or “Rippton”, or by the remoter control. Hope you will enjoy every fishing journey with company of BLACK SAMURAI. Before we start learning how to use it, please download “Rippton Boat” or “Rippton”...

  • Page 3: Installation Of The Batteries

    1. Installation of the Batteries Use your hand or your own screwdriver to unlock the battery compartments. Open battery compartments place two fully-charged batteries in respectively. 2. Control of LED Light Belt Double click the power button of the remote control to switch on/off both of the head LED light belt and the tail light belt.

  • Page 4: How To Use The Remote Control

    Press the button shown in square above to open hook release mechanism which will be open for 5 seconds and close automatically. And attach the fishing line when it is open. SAMURAI Note: CatchX Basic/BLACK Version has one antenna, and CatchX Pro Version has two antennas.
  • Page 5 4.2 Preparation of the Remote Controller Step 1 Unfold the rack Step 2 Unfold the antennas. Step 3 Attach your mobile device to the mobile device holder clamp 4.3 Operation of the Joystick TIP: Move the joystick to the right to the maximum extent for 3 seconds to unlock.
  • Page 6 4.4 Releasing Burley and Hooked Fishing Line by the remote If you intend to use the remote to release burley and/or fishing line，please make sure the screen on the remote shows M (manual mode). If you intend to release hopper 1, press the button HOPPER1, and long press the CONFIRM button, or long press the button Shortcut A to open...

  • Page 7: Operation

    Notice: Preloading the map on the APP When using BLACK SAMURAI in any new area, before connecting the boat to your mobile device, it is always necessary to enter the “Rippton Boat” or “Rippton” app first with internet connection, enter the operation interface (refer to 5.2 below) to finish preloading the map where you...
  • Page 8 Download and open “Rippton”, tap “Device” on the top to select CatchX Black. Before setting a mission, please check the image below to understand what each icon stands for.
  • Page 9 The Learner Mode (sailing range limited within 300m) is automatically on the first time you enter the page. It can be turned off in Common Set. Step 3: Calibration After the boat connected with the APP, please tap the cog icon on top right of the APP interface to enter “COMMON SETTINGS”.
  • Page 10 Note: It’s always necessary to calibrate BLACK SAMURAI at new locations where are 3km away from the last you have used the boat at. Step 4: Set a Route for Casting Mission 4.1 Tap the “Mission Management” button (in square 1) on the top of left side to start setting a route for your casting mission.
  • Page 11 4.3 After the home point has been set, long press the point you want in the green circle until the prompt box pops up. 4.4 Tap “Confirm”. Repeat the above-mentioned process if you want to add more waypoints (but no more than 2 waypoints). 4.5 If you want to delete the selected waypoint, tap it and then select “Delete”...
  • Page 12 Step 6: Perform the Mission Tap “Start” in the right bottom corner.
  • Page 13 Slide to start. NOTE: BLACK SAMURAI will return to the home point automatically after the mission is completed. If you intend to cancel the ongoing mission, there are two methods: tap the “Return to Home Point” button. The boat will go back to the home point set previously;...
  • Page 14 Step 8: Reset the Hoppers and Hook When a mission has been completed, indicator color of the used hopper(s) and hook will turn gray from green as shown at the bottom of the left picture. Please tap “Reset” button to have the status of all the hoppers and hook become available again.

  • Page 15: Remote Control

    6. Charging 6.1 Bait Boat Direct charging ： 5.5/2.5 DC charging port (please refer to Picture1). Please note that both batteries must be inside the boat together when direct charging. It takes 4-6 hours to be fully charged; or Charging the batteries separately (please refer to Picture2) after taking those out of the battery compartment.
  • Page 16 Catch and e plore the Future For digital User Manual and video tutorials, please visit https://www.rippton.com/ If you have any questions, please contact support@rippton.com...
