- Page 1 C NPC Interface CPCUS /embedded ser manual...
- Page 2 1.07 Documentation date: June 21st, 2024 No part of this document or the software described herein may be reproduced in any form without prior written agreement from EMS Dr. Thomas Wünsche. For technical assistance please contact: EMS Dr. Thomas Wünsche Sonnenhang 3 D-85304 Ilmmünster...
- Page 3 CPC-USB/embedded User Manual 1.1 Attributes 1.2 General Description 1.3 Ordering Information 2.1 Absolute Limiting Values 2.2 Nominal Values 3.1 Pin Configuration of CAN Connector 3.2 Pin Assignment of USB connection cable 3.3 Dimensions 3.4 Installation 3.5 socketCAN 4.1 Instruction for Disposal 4.2 FCC Statement 4.3 CE Conformity Dr.
- Page 4 User Manual CPC-USB/embedded THIS PAGE INTENTIONALLY LEFT BLANK Dr. Thomas Wünsche...
- Page 5 CPC-USB/embedded User Manual • Powerful Cortex M3 microcontroller with internal CAN controller • Extended temperature range • Supports CAN protocols 2.0A and 2.0B • Supply over USB Optional galvanic isolation between CAN and USB • • Firmware flashable over USB •...
- Page 6 User Manual CPC-USB/embedded 10-08-241-xx CAN-PC interface for internal USB ports with Cortex M3 microcontroller and galvanic separation of the CAN transceiver 10-08-440-xx CAN-PC interface for internal USB ports with Cortex M3 microcontroller xx denotes language of delivery: german english Dr. Thomas Wünsche...
- Page 7 CPC-USB/embedded User Manual Any (also temporary) stress in excess of the limiting values may cause permanent damage on CPC-USB/embedded and connected devices. Exposure to limiting conditions for extended periods may affect the reliability and shorten the life cycle of the device. Storage temperature °C °C...
- Page 8 User Manual CPC-USB/embedded THIS PAGE INTENTIONALLY LEFT BLANK Dr. Thomas Wünsche...
- Page 9 CPC-USB/embedded User Manual Pin 1 Not connected CAN_L Pin 2 CAN bus line, dominant low Pin 3 CAN Ground Pin 4 Not connected Pin 5 Not connected Pin 6 Not connected Pin 7 CAN_H CAN bus line, dominant high Pin 8 Not connected Pin 9 Not connected...
- Page 10 User Manual CPC-USB/embedded DIMENSIONS ARE IN MILLIMETERS GENERAL TOLERANCES ISO 2768-1 c DRAWINGS ARE NOT COMPLETELY TRUE TO THE ORIGINAL Dr. Thomas Wünsche...
- Page 11 If you are not sure about the installation please contact EMS Dr. Thomas Wünsche. CPC-USB/embedded needs a driver to operate on Windows operating systems. This driver is part of the ´CPC-Series Runtime Kit for MS-Windows Environment´, which is part of the delivery.
- Page 12 User Manual CPC-USB/embedded With a recent Linux kernel the socketCAN driver for the CPC-USB/ ARM7 (ems_usb.ko) is already included. It supports the following interface versions: CPC-USB/ARM7 v1.0 and v2.0, also low speed variants CPC-USB/ARM7-GTI v1.0 and v2.0, also low speed variants CPC-USB/embedded After the device is attached to the USB connector the driver will be loaded automatically.
- Page 13 CPC-USB/embedded User Manual EMS is selling its products exclusively to commercial customers. This is the reason why all devices are designed for commercial use and have to be disposed appropriately. In accordance to § 10 para. 2 clause 3 Electronic Equipment Act (WEEE) the disposal of EMS products is regulated the following way.
- Page 14 User Manual CPC-USB/embedded Dr. Thomas Wünsche...
