1.8 TABLES EQUIVALENT LENGTHS.
Concentric pipe m 1
Concentric bend 90°
Concentric bend 45°
Terminal complete with concentric horizontal
intake-exhaust Ø 60/100
Concentric horizontal intake- exhaust
terminal Ø 60/100
Terminal complete with concentric vertical
intake-exhaust Ø 60/100
Concentric vertical intake-exhaust terminal
Ø 60/100
Terminal complete with concentric horizontal
intake-exhaust Ø 80/125
Terminal complete with concentric vertical
intake-exhaust Ø 80/125
TYPE OF DUCT
Equivalent length in m of
concentric pipe Ø 60/100
m 1
m 1.3
m 1
m 2.3
m 1.5
m 2.5
m 1.4
- - -
- - -
8
Equivalent length in m of
concentric pipe Ø 80/125
m 1
m 1.4
m 1
- - -
- - -
- - -
- - -
m 1.3
m 1.7
