CONTROL PANEL

AML Pro Control Panel Keypad Functions
1 2
Control Panel Keypad
Press and hold the On/Off Button until the SSI Logo
appears on the screen. It takes about 3 seconds for the
AML Pro to perform a self-check; after that it will display the
current revision on the start up screen.
Current
Ver 429
Revision
Opening Screen - Current Firmware Installed
When the self-check is completed, the MAIN SCREEN will
appear.
8
AML PRO SERIES
3 4 5 6
CONTROL PANEL FUNCTIONS
There are six function buttons on the AML
Pro control panel:
1
On/Off - Press and hold the On/Off Button
to turn the unit On or Off.
2
TX (Transmitter) - Press the TX Button to turn
the transmitter On or Off.
3
Menu - Press the Menu Button to bring up
the Menu Screen. There are two pages of
Menu Screens.
4
Down Arrow - Use the Down arrow to either
adjust the sensitivity level down or to move
the cursor down once inside of the menu
screens.
5
Up Arrow - Use the Up arrow to either
adjust the sensitivity level up or to move the
cursor up once inside of the menu screens.
6
SEL - Press the SEL button to either activate
the GPS Functions or to Select the Menu
option once inside of the menu screens.
