SubSurface Instruments AML PRO Series Operator's Manual page 10

STATUS MESSAGES FLOW CHART
ERFACE
TC 16 27 57
44 27 4494N
88 07 6298 W
Status Messages - Close-Up
GENERA L ST
STATUS MESSAGES
POWER EVENTS
10
AML PRO SERIES
sats 09
Status Messages
DEG 86
Angle º
SEN 17
Sensitivity
A TUS MESSAGES
OPERATE RF transmitter on
STANDBY RF transmitter off
HOST PC Transfering data to PC
USB PWR
External battery plugged in
BAT PWR
Internal battery plugged in
LOW BAT
Low battery warning
AUTO OFF
AML OFF
LOW BAT
SLEEP AUTO SLEEP
CLK BAT Internal clock battery low
5 seconds to shutdown
5 seconds to shutdown
Wake up by moving the unit
GENERAL STATUS MESSAGES
All status messages are displayed on the
top right corner of the LCD Display. Every
time there is a new event, a message will be
displayed for 4 seconds and then it goes
back to OPERATE status.
POWER EVENTS
Directly related to power consumption,
power source and auto shut off setting in
the AML Pro. The unit will emit a sound and
display the related message.
Use the POWER EVENTS flow chart as a
reference for all events descriptions. The low
battery event applies only to the internal 9v
battery pack.
A rechargeable coin battery is located
within the unit, the CLK BAT message
indicates low voltage on it. Keep a fresh
9v battery pack in the unit to recharge the
internal battery.
