Panasonic VL-SA74CX Quick Start Manual

Panasonic VL-SA74CX Quick Start Manual

Hide thumbs Also See for VL-SA74CX:

Advertisement

Table of Contents

Door station
This system is an auxiliary system; it is not designed to provide complete protection from property loss. Panasonic
will not be held responsible in the event that property loss occurs while this system is in operation.
Customer care number: (+971) 48007262
Email:customercare@ae.panasonic.com
The images shown are for illustration purposes only and may not be an exact representation of the product.
Model Name
Video Intercom System
Main Monitor Station (7 Inches)
Door Station
Main monitor station
Model No.
VL-SA74CX
VL-MA74CX
VL-VA504CX

Table of Contents

2
4
6
7
11
19
39

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL-SA74CX and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic VL-SA74CX

Summary of Contents for Panasonic VL-SA74CX

  • Page 1: Table Of Contents

    Door station Main monitor station This system is an auxiliary system; it is not designed to provide complete protection from property loss. Panasonic will not be held responsible in the event that property loss occurs while this system is in operation.

  • Page 2: Introduction

    External storage up to 256GB Multi-language option Brightness, melody volume can be adjusted via monitor White LED for color night vision Work with Panasonic SmartWiFi App Remote video intercom with your visitor via your mobile phone Snapshot with built in memory of 100 images...
  • Page 3 ● The available products differ depending on your region. For more information, please consult your dealer ● In this document, the suffix of each model number (e.g., the"CX"in"VL-SA74CX") is omitted unless necessary. When the suffixes are used to describe models (e.g., "CX models"), the suffixes refer to all models in the series ●...
  • Page 4 2.lmportant Information 2.1 For your Safety 2.2 Important Safety Instructions 2.3 For Best Performance...

  • Page 5: Important Information

    2.lmportant Information (For greater than 40 C (For indoor) & 70 C outdoor). System reset General setting 2.4 Other Important Information 2.5 Cleaning...

  • Page 6: Preparation

    3. Preparation 3.1 Operation buttons Indoor unit / monitor Microphone Microphone Camera lens Power LED White LED Micro SD card slot Speaker Call button and indicator RFID reader Back side of door station explanation Back side of monitor explanation Camera Angle Adjustment NO / COM / NC BELL Switch(DOOR1/DOOR2)

  • Page 7: Use On Smart Phone

    If the device is paired on a smart phone, it can't be paired on other smart phones. (You can pair again in case the device is removed on other smart phone.) 1)Sign Up -Install and run the “Panasonic SmartWiFi” App on your smart phone. -Select “Sign up” -Select your country -Enter “Email Address (ID)”...
  • Page 8 4. Use On Smart Phone Step 2: Please make sure your phone is connected with WiFi or mobile data and scan the QR code to pair it. - Click “Add Device” in App, then press VDP icon “ ” (Method 1) or directly select scan icon “ ”...
  • Page 9 4. Use On Smart Phone Step 3: Wait for the pairing process to be finished Please be patient, it will take about 120s. When finished, try to see the live preview.
  • Page 10 4. Use On Smart Phone 3) How to Share with Family Members Select “Me” at the bottom of the App. -Select “My Home” from the “Home Management” setting menu. -Click “Home Name” to set the home name. -Select the home (name) you created. -Select “Add Member”.

  • Page 11: Main Functions

    5. Main Functions Main Screen Menu Details Click to start intercom between monitor and mobile APP. Monitor View the door camera (You cannot use it if door camera is not connected) CCTV Monitoring CCTV. (You cannot use it if CCTV is not connected) Intercom For Monitor-to-Monitor Intercom (This function needs at least 2 monitors) Playback...
  • Page 12 The device supports intercom between monitor and smartphone APP. To use this function, please make sure your monitor is connected to network and pair on Panasonic SmartWiFi APP. Please refer to Wi-Fi setting (page no. 8) to finish network setting and APP instruction to pair on APP.
  • Page 13 5. Main Functions Selected camera: Selected camera will be shown on the screen. Back: Back to previous screen. Switch DOOR2 if you connect two door stations. Siren: Activate the siren alarm on outdoor camera (The siren can only be activated during monitoring) Gate lock release: Click to release the gate lock, which is connected on door station.
  • Page 14 5. Main Functions Recording format: The monitor will record a photo/video automatically if auto recording is enabled. The monitor will record a photo automatically. The monitor will record a video automatically. If auto recording is disabled, this place will be blank. Call Transfer When multiple monitors are connected, call from the door station can be transferred to another monitor.
  • Page 15 5. Main Functions Note: If you are using only one door station in monitoring mode, you can’t switch to other channels. If you use two monitors, you can also simultaneously start monitoring mode in extension monitor, the same images will be displayed on the screen of the different monitor. If a conversation with door station is in monitoring mode, during this time if a visitor presses the call button on either of door stations, the monitoring mode will be switched off, just the visitor's image will appear on the screen and continuous ringing will be heard.
  • Page 16 5. Main Functions Intercom For more than 2 monitors connected, you can use this function to call and talk between monitors. Note: Before using this function, please set the extension ID of extra monitors in setting page. Max. 4 monitors can be set. By enter correct monitor ID number, you can call the extension monitors.
  • Page 17 5. Main Functions Regarding The Recording: ●Video cannot be stored when Micro SD card is not inserted. ●The images can be stored in the monitor's embedded memory. (Max.100 images). ●You can operate as below when you need back-up of images which are stored in the monitor's embedded memory.
  • Page 18 5. Main Functions Recorded Video Door 2 [001/073] 240507_134949_11.AVI 00:10 00:13 00:13 Door station that has recorded the video Play: Play the current video. During playing, the play icon will change into pause button. Left/Right: Move to previous/next file. Date & Time: When the video is saved Volume: Adjust volume when playing recorded videos.

  • Page 19: Settings

    6. Settings When you touch “ ” icon, the below screen will be shown. - When you select each item, the corresponding sub item is displayed. - If you do not take any actions for 60s, the screen will be off. 1.
  • Page 20 6. Settings ① Enable motion detection: Enable/disable motion detection function. ② Camera selection: Select camera for motion detection (select from Door1/2). ③ Recording format: Select file recorded as photo/video. ④ Sensitivity setting: Sensitivity for motion detection can be set as high/middle/low. Screen ON when motion detected: When camera detects motions, the monitor will show the image of the ⑤...
  • Page 21 6. Settings 2. Wi-Fi ● Wi-Fi setting: Click the check box to turn the Wi-Fi ON or OFF (enable or disable) You can search surrounding network and connect to selected wireless network. Select the Wi-Fi from the network list and enter the password to connect it. ●...
  • Page 22 6. Settings 3.2 Touch Sound Tone Turn ON / OFF the touch sound. 3.3 Intercom Ring Tone - You can select ring tone of intercom. - Only inbuilt ringtones can be used for intercom. 4. Storage When you click on the Storage icon, the below screen will be shown. Here you can view the usage and capacity of Micro SD card, and you can format the Mircro SD card, delete files, or synchronize images stored in the built-in memory to the Micro SD card.
  • Page 23 6. Settings Video: To delete call, motion detection recorded videos for monitor playback saved in SD card Panasonic1. SD card Photos: To delete photos saved in SD card. Local Photos: To delete photos saved in monitor. Iot Playback: To delete call, motion detection recorded videos saved for phone APP playback in SD card Panasonic2.
  • Page 24 6. Settings When Screen Control is enabled, you can select “List of Display” ON/OFF to play/don't play the image(s) inside the folder (name “picture”) of Micro SD card. Note: If the user inserted a Micro SD card and there are customized photos in the picture folder, the monitor will play customized photos and local photos.
  • Page 25 6. Settings 6. General 6.1 Language Language can be switched between English and Arabic. 6.2 IOT Settings wlan 2023-06-15 00375 satdea295900a05sbe0 Mobile Message Push: Enable/disable this function to send call/motion detection notification to your mobile phone or not. Delay Notification: You can choose mobile phone notification delay time from 0-25s. Network Connection: The default setting is WLAN.
  • Page 26 6. Settings 6.3 Advanced Setting To enter this page, security password is needed. The default password is 1234. 6.3.1 Device Information Device number / extension No. and IP information will be shown here. Click “ ” to set the items below; after setting, click “...
  • Page 27 6. Settings 6.3.2 Doorbell Settings This door station can work with indoor station properly without any configuration when it is correctly powered ON, please follow page no.6&7 of the installation guide to finish wiring and power. Door station ID The system can connect max 2 door stations. If you want to connect 2 door stations, please switch the door station ID into different one to avoid conflict as the below left image.
  • Page 28 6. Settings How to connect and use door sensor to outdoor unit Door Sensor Door Station Terminals Gate is open Door 2 07 May 2024 12:04 Door 2 07 May 2024 12:04 If the lock is still open, the gate lock icon will turn red and a notice “Gate not closed” will be shown. Gate is closed Door 2 07 May 2024 12:04 If the lock is closed, the gate lock icon will return from open to closed.
  • Page 29 6. Settings Tamper alarm: Enable/disable tamper alarm on outdoor station. IP Address: The IP address setting is generally the same with indoor station. 192.168.100.20 192.168.100.20 192.168.100.20 IP Allocation: The device will detect network when starting, if the network is detected, the device will work on default IP address.
  • Page 30 6. Settings How to add ID cards Step 1: Click the “ ” and it will show this page. 0011940262 0011951900 0011941212 0011941210 0011958301 Card List Step 2: Swipe the new ID card on the reader of the outdoor unit for around 1s, and you will hear “di di di” which indicates the card is added successfully.
  • Page 31 6. Settings 6.3.4 Security Setting Each monitor can connect max. 8 alarm sensors. (Note: The alarm sensor should be wired on the monitor correctly. Then you need to check and config the sensor type as NO/NC correctly on the setting menu.) Alarm trigger When a sensor triggers the alarm, the following page will be shown, and the monitor will continue to deliver alarm sound.
  • Page 32 6. Settings When: The security sensor will be functional under At home/Leave home/Sleep mode. Click each sensor and you can edit its status (ON/OFF), name, working mode (NC/NO) and alarm delay when sensor is triggered(0-90s). Click the “ ” on the upper right to check and delete sensor records. 6.3.5 CCTV Management 2 IP cameras can be added in the monitor.
  • Page 33 6. Settings Step1: In CCTV manage page, click the “ + ” icon and select “Wired connection”. Step 2: Select available cameras in Discovered Device. Step 3: Enter the IP camera's account (admin) password and then click Refresh. rtsp：//admin:**********@192.168.xxxx.xxx... rtsp：//admin:**********@192.168.xxxx.xxx... Note : Mentioned information details is just for customer reference only.
  • Page 34 6. Settings Step 4: Select a code stream and click Register, then choose CCTV 1 or CCTV 2 to finish setup. Wireless Connection To connect wireless camera, both the camera and monitor should connect to the same Wi-Fi(2.4GHz). Router 2.4GHz Wi-Fi Monitor IP CCTV 1 IP CCTV 2...
  • Page 35 6. Settings Step 4: Enter the IP camera's password and click Refresh. Step 5: Select a code stream and click Register, then choose CCTV 1 or CCTV 2 to finish setup. Note : It will display the Camera settings are OK. Click Register and select CCTV1 or CCTV2 to finish set up.
  • Page 36 6. Settings Caution: Before connecting the third party camera, please do preparation as below: ● Please wire the IP camera to the router and connect the PC to the same router. (Please make sure the camera and PC are under the same internet) ●...
  • Page 37 6. Settings 6.3.7 Security Password This password is for entering advanced settings, enable and disable security and stop alarm. The default password is 1234. If you change the password and forget it, please restore factory setting to recover password to default 1234. 6.4 System Time Click to set system date and time manually.
  • Page 38 6. Settings 6.5 System Reset Click and confirm to restore factory setting. Note: To restore factory setting, it will also unbind the monitor from mobile APP. Please make sure the monitor and your phone is connected with Network. 6.6 Reboot Click to restart device.

  • Page 39: Specifications

    7. Specifications Main Monitor Station (VL-MA74CX) Power Source Power Consumption Dimensions (cm)(L x B x H) Approx. 20x2.7x14.3 (excluding protruding sections) Operating Environment to +40 Relative Humidity 10% to 90% (RH) Approx. 17.8 cm (7.0 inches wide color display) Talking Method Flash Memory Max.
