EXP-101 - PALLET WRAPPER MANUAL
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXP-101 and is the answer not in the manual?

Questions and answers

Related Manuals for Get Packed EXP-101

Summary of Contents for Get Packed EXP-101

  • Page 1 EXP-101 - PALLET WRAPPER MANUAL OPERATION MANUAL...

  • Page 2: Table Of Contents

    GENERAL 1.1 Notice of installment ..2 1.2 Notice of operation ..2 2.SPECIFICATION 2.1 Spec. table ..

  • Page 3: General

    1. GENERAL 1.1 Notice of installment To make sure of a safe and correct operation, please check the below items before installing the machine: 1) Power source capacity must be larger than the machine need. 2) A shorter ground wire is better. 3) Machine standard power is 110V/220V (-15% - +10%).

  • Page 4: Specification

    2. SPECIFICATION 2.1 Spec. table model EXP-101 Turntable speed 0-10 RPM Turntable dia. 1500mm Tower height 2100mm Max. wrapping height 2000mm Max. wrapping size 1050x1050mm Max. loading weight 1500Kgs Film stretch (%) Film tension Adjustable Elevator unit speed Adjustable Max. film spec.

  • Page 5: Machine Dimension

    2.2 Machine dimension...
  • Page 6 � 1 - ------ [� ______ � ----�� � ..--- bCJr:11 050.(_J 27.Q_} ..--- :;::; ,-.._ (PALLET SIZE) - � -- 7 , -- - ,-.._ CX) (/) '--"' � m' \ � !:::: � � � □ 0� ____ �...

  • Page 7: Machine Description

    2.3 Machine description...
  • Page 8 CONTROL BOX ELEVATOR MOTOR BOX PHOTO SENSOR ELEVA TOR ELECTRIC BOX SEAT ADJ. BAR TURNTABLE...

  • Page 9: Operation Description

    3. OPERATION DESCRIPTION 3.1 Installment 1) Apart all the wooden package. Avoid damaging the machine. 2) Move the machine to an installment position by fork lift. 3) Lift up the tower. 4) Fix and tighten the tower by M10 screws. 5) Fix and tighten the low limit plate by M6 screws.

  • Page 11: Operation Of Control Panel

    3.2 OPERATION OF CONTROL PANEL...
  • Page 12 MODEL: EXP-101 START RE-SET WRAP CNT. WRAP CNT. UP-SIDE DOWN-SIDE to· ' C D TURNTABLE ELEVATOR □ □ ©· - MANU MANU � ,-� TURNTABLE ELEVATOR SPEED ADJ. SPEED ADJ. <c) ,CJ� WRAP TENSION TOP PRESSURE □ MANU MANU �...

  • Page 13: Operation Description

    3.3 Operation description OPERATION PANEL 1)LAMP POWER As the main power switch is〝ON〞, the power lamp should be on too. While the lamp is on, it indicates the machine is ready to be running. 2)START Press the button to get automatic or manual program running. As machine is set on 〝AUTO RUN 〞, please make sure TURNTABLE and ELEVATOR knob is set on〝AUTO〞position.
  • Page 14 5)WRAP CNT. (LOW-SIDE) Turn the knob to set cycles of wrap on the low-side of item from 2 to 4 . 6)ELEVATOR KNOB As machine is set on〝AUTO RUN〞, please set this knob on 〝AUTO〞position and then press 〝START〞button to wrap package.
  • Page 15 elevator and turntable are set on 〝AUTO〞before pressing 〝START〞button to finish the wrapping. In 〝MANU RUN〞, please set this knob on〝MANU↑〞or〝MANU ↓〞position and press 〝START〞button to up or down the pressure pad. If the machine is running, no need to press 〝START〞button, just set the knob on 〝UP〞or 〝DOWN〞...
  • Page 16 2) Wrapping tension on the package edge and side are same. 3) When wrap tension is settled, it can suits any kind size package no need adj. The wrap tension again. 12)EMG. STOP Press the button to get emergency stop. Due to a good security consideration, the turntable will not be stopped instantly as the EMG.
  • Page 17 ELEVATOR UNIT PRE-STRETCH PERCENTAGE CHANGE 1) Release the adjust sprocket gear(C). 2) Release the chain. 3) Release the chain sprocket gear(A) by release the nut. 4) Change the needed chain sprocket gear(A). 5) Adjust the chain on suitable tightness by tighten the adjust sprocket gear(C).
  • Page 18 M10X4PCS M10 BOLT M12 NUT FIG. 5-1 FIG.5-2...
  • Page 19 Illustration for film threading Place the film on the〝film fixing seat〞. Refer to the below drawing, pull film out through IDLE ROLLER (C) and PRE-STRETCH shafts (A) & (B). After pulling film around PRE-STRETCH shafts (A) & (B) as the picture shown below, continue pulling the film clockwise around the dancing bar then passing the button of IDEL ROLLER (D) to the door of the elevator.

  • Page 20: Electric

    4. ELECTRIC 4.1 Electric capacity 1)Power consumption Turntable motor 0.185KVA Elevator motor 0.185KVA Pre-stretch motor 0.185KVA Control & wiring box 0.2KVA Machine power use 0.75KVA Power socket need 1KVA 2)Power cable ..1.25mm² 3)Machine in put .

  • Page 21: Electric Diagram

    4.2 Electric diagram Sensor/limit switch location...
  • Page 30 ELECTRIC PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 7150BW02 AUTO RUN GREEN LAMP SEAT 7150CE24 LAMP 7150BW01 COVER 71500001 POWER LAMP 7160BD01 SELECTOR SWITCHS 7158BZ01 BUTTOM SEAT CONTACTOR Nox1 7160BD02 SELECTOR SWITCHS 7158BZ03 BUTTOM SEAT CONTACTOR Nox2...
  • Page 31 ELECTRIC PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 7580IC01 CONTROLLER CARD 7355N102 PROXIMITY SWITCH PS-05N-3M 7350TZ02 LIMIT SWITCH TZ-7110 7350TM01 LIMIT SWITCH TM-1307 7350TZ04 LIMIT SWITCH TZ-8108 7350TZ03 LIMIT SWITCH TZ-7100 7365P002 SECURITY SWITCH & KEY (PB400400)

  • Page 32: General Adjustment

    5.TROUBLE SHOOTING 5.1 General adjustment 1) Turntable belt adjust: Please see the illustration 5-1 and then loosen the motor seat fix screw (M10) 4 pcs. Turn the nut (M10) on the seat until get enough tension. Turn and tight the motor seat fix screw 4 pcs again.
  • Page 33 KBIC Installation and Operation Instructions *KBIC adjustment for PRE-STRECTCH motor. *Install the correct Plug-in Horsepower Resistor according to input voltage and motor horsepower. *Adjustment of KBIC must be done by technicians. 1. Connection points: (L1,L2) Input AC100-120V/AC200-240V. (A+,A-) Output DC. (P1,P2,P3) Speed adj. Knob on control panel.
  • Page 34 *KBIC adjustment for TURNTABLE motor. *Install the correct Plug-in Horsepower Resistor according to input voltage and motor horsepower. *Adjustment of KBIC must be done by technicians. 1. Connection points: (L1,L2) Input AC100–120V/AC200-240V. (A+,A-) Output DC. (P1,P2,P3) Speed adj. Knob on control panel.
  • Page 35 *KBIC adjustment for ELEVATOR motor. *Install the correct Plug-in Horsepower Resistor according to input voltage and motor horsepower. *Adjustment of KBIC must be done by technicians. 1. Connection points : (L1,L2) Input AC110–120V/AC200-240V. (A+,A-) Output DC. (P1,P2,P3) Speed adj. Knob on control panel.
  • Page 36 FILM FEED CONTROLLER CARD INSTALLATION AND OPERATION: * Switch off power . * Take off old controller card: (A) Pull 3pcs connector off (B) Take the old controller card apart by loosen 4pcs M3 screws * Install the new controller card: (A) Install the new controller card and fix 4 pcs M3 screws tightly.
  • Page 37 The two yellow lamps are always extinguish when the pre-stretch motor is running. If they are lighted “ON” during the pre-stretch motor is running, mean is the film feed controller card is problem or the card adjust is wrong.
  • Page 38 5.2 Trouble shooting Machine trouble Possible Problem Solution Machine can not work 1. Fuse burn. 1.Change fuse. 2. Door security s/w is 2.Release or change blocked or broken. security s/w. 3. PLC RUN lamp not ON. 3.Check PLC. 4. Foot security is 4.Release the broken.
  • Page 39 Pre-stretch motor 1. Fuse burn 1. Change fuse. can't work 2. Motor control 2. Change motor broken control. 3.Motor broken. 3. Change motor. Pre-stretch 1. Too much glue on the 1. Clean the pre- percentage isn't pre-stretch roller. Stretch roller by cleaner enough.

  • Page 40: Parts List

    6. PART LIST 6.1 Seat...
  • Page 41 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 74600106 MOTOR VP3310D 1/4HP 1.5M 74600202 MOTOR VP3330D 1/2HP 1.8M 10110820 SCREW M8X20L & W. 10111020 SCREW M10x20L & S.W. & W. 32902002 SPEED REDUCER 1/4HP 1.5M 32904002 SPEED REDUCER 1/2HP 1.8M...
  • Page 42 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 2010B172 BELT B-172 1.5M 2010B183 BELT B-183 1.8M 10140825 SCREW M8x25L PA100200 TURNTABLE PLATE 1.5M PA100210 TURNTABLE PLATE 1.8M 10100820 SCREW M8x20L PA100700 WHEEL 22” PA100600 LOCATING PLATE 10130510 SCREW M5x10L & W.

  • Page 43: Tower

    6.2 Tower...
  • Page 45 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY PB20010A TOWER 2.1M PB20011A TOWER 2.6M 74600107 ELEVATOR UNIT MOTOR VP3310D 10110820 SCREW M8x20L & S.W. 10101025 SCREW M10x25L & S.W. & W. 32802004 ELEVATOR UNIT SPEED REDUCER VTM-40 10100825 SCREW M8x25L &...
  • Page 46 PARTS LIST FOR EXP-101 KEY NO PRAT NO. DESCRIPTION Q’TY PD200500 UP & DOWN DRIVING WHEEL PD200600 UP & DOWN DRIVING WHEEL SHAFT PB200300 CHAIN WHEEL SEAT 10301000 NUT M10 & S.W. & W. PB200400 ELEVATOR UNIT SEAT (INNER) 10100820 SCREW M8x20L &...

  • Page 47: Elevator

    6.3 Elevator...
  • Page 48 82,..• ,107 107- ·109 ·110 ·128 116--- 1211- --128 - 127 112· 119- 110· 117· 116-- ·,181...
  • Page 49 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY PB20200A ELEVATOR UNIT SEAT (OUTER) 10100820 SCREW M8x20L & S.W. & W. PB207100 FILM SEAT SHAFT PM302400 SPRING 30361730 BEARING NTB/AS1730 PM30050A FILM FIX SEAT PM302300 WASHER 10101020 SCREW M10x20L & S.W. & W.
  • Page 50 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 10190408 SCREW M4x8L 74600105 PRE-STRETCH MOTOR GPP7453 75510002 VARIOUS RESISTOR 5K PB206000 RESISTOR FIX SEAT PB204700 PLATE 10100540 SCREW M5x40L PB205900 10180406 SCREW M4x6L 11300900 RING STW-9 30306090 BEARING 609ZZ...
  • Page 51 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 10100001 SCREW 1/4”X3/4”L 10180610 SCREW M6x10L PA311500 CHAIN GEAR 18 TEETH 3240S351 CHAIN 10100612 SCREW M6x12L & W. PB20480A COVER 10200616 SCREW M6x16L & S.W. & W. 10100620 SCREW M6x20L & S.W. & W.
  • Page 52 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 10330800 NUT M8 & W. 10300800 NUT M8 & W. 10331000 NUT M10 10101020 SCREW M10x20L PB20550A ROLLER SET PA311400 AXLE RING 11314200 RING RTW-42 30300040 BEARING 6004ZZ PA310900 BEARING BLOCK...
  • Page 53 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY 10130412 SCREW M4x12L & W. 10140616 SCREW M6X16L PB204300 SECURITY KEY PB204900 LOCKER 10130316 SCREW M3x16L & W. 10300600 NUT M6 PA315200 DOOR HANDLE 10190406 SCREW M4x6L S.W:SPRING WASHER W:WASHER...

  • Page 54: Control Box

    6.4 Control box...
  • Page 55 C) • _/� � '----- > � •✓ ��7...
  • Page 56 PARTS LIST FOR EXP-101 KEY NO PART NO. DESCRIPTION Q’TY PB400300 CONTROL BOX DOOR 10190425 SCREW M4x25L 10300400 NUT M4 PB400400 CIRCUIT BEAKER KEY PA202100 SPRING 10330400 NUT M4 & W. 10130435 SCREW M4x35L & S.W. & W. 7365P002 CIRCUIT BEAKER SWITCH XCS-PA791...
