- Page 1 INSTALLATION MANUAL Oletto™ Single Handle Pull Down Kitchen Faucet KPF-2820 KPF-2821 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing LLC I Rev. March 29, 2023...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: DO NOT RETURN TO STORE...
-
Page 3: Prior To Installation
Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Read all instructions and safety warnings and ensure you have all tools, ·... - Page 4 Diagram and Parts List F. Screws A. Faucet Body G.Weight B. Flange H.Weight Clip C. Rubber Washer I. Quick Connector D. Metal Washer J. Hex Wrench E. Mounting Nut...
- Page 5 Faucet Dimensions (For KPF-2821) 12 1/2" [318.9mm] 3 1/2" 10 7/8" [90.1mm] [275.0mm] Ø2 1/4" [57.0mm] 3/8” compression Installer Tip: Shut off main water supply before installing new faucet.
- Page 6 Faucet Dimensions (For KPF-2820) 10 5/8" [270.7mm] 8 7/8" 3 1/2" [227.0mm] [90.1mm] Ø2 1/4" [57.0mm] 3/8” compression Installer Tip: Shut off main water supply before installing new faucet.
- Page 7 Step 1. Installing the faucet Shut off the water supply. Place the faucet (A) through the hole in the sink or countertop. Secure the faucet (A) to the countertop or sink using the rubber washer (C), metal washer (D) and mounting nut (E) provided.
-
Page 8: Step 3. Installing The Counterweight
Step 3. Installing the counterweight Install the weight clip (H) at the point of the hose marking "weight here". Insert the weight (G) onto the weight clip (H) by sliding it down onto the weight clip (H). Step 4: Connect waterlines to main valve Attach waterlines to angle stops and tighten until snug. - Page 9 Step 5: Flush faucet Pull the hose assembly out of the spout and remove the spray head by unscrewing it from the hose in a counterclockwise direction. Be sure to hold the end of the hose down into the sink and turn the faucet on to the warm position where it mixes hot and cold water.
-
Page 10: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # SFS, MB, SFSB, 1. Sprayer Head KP27207 SFACB, BB, CH** 2. Sprayer Washer KP27208 KP27209 GRSFS, BLMB, (For KPF-2820) 3. Sprayer Hose BLSFACB, BLBB, KP27233 BLSFSB,GRCH* (For KPF-2821) 4. O-ring KP27210 5. -
Page 11: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Leakage under faucet handle Bonnet nut (7) has Remove the cover button (11). Loosen the come loose screw (10) with the hex wrench (21). - Page 12 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
- Page 13 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 14 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
