- Page 1 INSTALLATION GUIDE Single Lever Pull Out Kitchen Faucet KPF-2230 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. October 25, 2017...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep teh box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement • Turn off the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •... - Page 4 Diagram and Parts List sprayhead 2. faucet assembly 3. mounting hardware A. Rubber Washer B. Metal Washer C. Mounting Nut D.Mounting Screws 4. hose 5. escutcheon 6. hex wrench 7. weight...
- Page 5 Faucet Dimensions 10 3/16" (258.5mm) Ø 2 3/8" (Ø 60mm) 1 1/4"-18UNEF-2A 2-1/2-14NPSM-2A check valve...
- Page 6 Faucet Dimensions 9 3/16" (234mm) 2 1/2" (63.4mm) 11 5/16" (288mm)
- Page 7 Step 1: Remove mounting hardware Remove mounting hardware(3) Step 2A: Installing the faucet with deck plate For three-hole installation, deck plate (5), and silicone sealant are required...
- Page 8 Step 2B: Installing the faucet without deck plate For single-hole installation, deck plate (5), and silicone sealant are NOT required Step 3: Install faucet and mounting hardware Insert the faucet body (2) into the hole on the countertop or deck plate assembly (5). Install rubber washer (3A), metal washer (3B), and mounting nut (3C) on the mounting...
- Page 9 Step 4: Attach spray hose and counterweight Remove the plastic seal cover from the outlet port prior to pushing the hose adapter onto the same port, you will hear a “click” sound once they are joined. Attach metal weight to hose to prevent hose from twisting and returns hose to proper position.
- Page 10 Step 6: Open water Open the water valve and check for leaks at supply line connection. Step 7: Flush faucet After installing faucet, remove pull-down spray and turn on water to remove any left over debris. Re-assemble spout...
-
Page 11: Replacement Parts
Replacement Parts 1. Metal Handle Assembly Locking Nut 3. Ceramic Disc Cartridge 4. Spout Seal Kit 5. Spout Base 6. Spout 7. Hose Guide 8. Hand Spray w/ Check Valve 9. Supply Pipe-Hot 10. Supply Pipe-Cold 11. Supply Pipe 12. Screen Washer 13. -
Page 12: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under the Locking nut (4) has Remove index button... - Page 13 Maintenance - Cartridge Replacement Step 1: Remove the handle button from the handle. Loosen the set screw with a hex wrench. Remove the handle and unscrew cartridge cover by hand Step 2: Unscrew the locking nut with an adjustable wrench. Remove ceramic disc cartridge Step 3: Place the new cartridge in the handle seat.
- Page 14 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 15 Rico shipping charges may apply). International shipping fees are not included. COMMERCIAL WARRANTY Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 16 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
