- Page 1 Installation manual M A N U E L D ' I N S T A L L A T I O N I N S T A L L A T I E H A N D L E I D I N G I N S T A L L A T I O N S A N L E I T U N G M A N U A L E I N S T A L L A Z I O N E...
-
Page 3: Table Of Contents
Shell chairs 2023-07 Contents Contents Contents ........................1 Preface........................2 This product ....................3 Scope of delivery ..................5 Assembly and adjustments ................. 5 Tools ....................... 5 Seat height (not for E-versions) ..............6 Drum brakes (only Coraille types) ..............6 Table B12 (optional, not for XXL versions) ............ -
Page 4: Preface
To support you on the installation and repairs of this shell chair, we provide you with this installation manual. Please read it carefully. If you still have questions after reading this manual, do not hesitate to contact Vermeiren. The information in this manual applies to the following shell chair(s): •... -
Page 5: This Product
5. Push bar 6. Tilt lever (Altitude, Altitude XXL) 7. Removable upholstery cover 8. Footplate 9. Calf rest 10. Table supports 11. Wheels with brake 12. Footrest lever 13. Handset (Altitude-E) 14. Identification plate Important parts Altitude, Altitude-E, Altitude XXL... - Page 6 Shell chairs 2023-07 This product 1. Shell chair 2. Head cushion 3. Body belt 4. Seat cushion 5. Brake lever 6. Footplate 7. Calf rest 8. Steering wheel 9. Table supports 10. Rear wheel 11. Footrest lever 12. Push bar 13.
-
Page 7: Scope Of Delivery
• Apply all brakes before assembly, adjustment or operation. • Make sure all screws are firmly secured before using the chair. Important remarks • For more information, contact your nearest Vermeiren office. Tools To set up the chair, the following tools are needed: •... -
Page 8: Seat Height (Not For E-Versions)
Shell chairs 2023-07 Assembly and adjustments Seat height (not for E-versions) The seat height can be altered by using a seat cushion of different height, or by adjusting the seat frame height. The seat-frame height is adjustable in 3 height positions in steps of 25 mm: 1. - Page 9 – can be mounted in the sockets (9) at the right side of the lower shell chair frame. The (dis)mounting of the table is similar for the Coraille and Altitude chairs, except that the Altitude chairs have two tube sockets and the Coraille has only one.
- Page 10 Vermeiren GROUP Vermeirenplein 1 / 15 2920 Kalmthout website: www.vermeiren.com Instructions for specialist dealer This instruction manual is part and parcel of the product and must accompany every product sold. Basic UDI: 5415174 122103Altitude GQ Version: B, 2023-07 5415174 122103Coraille CV...
