2515367
Please read all instructions carefully before use and
retain for future reference.
CAUTION Do not immerse in water.
Wear a dust mask.
Protect your eyes.
Protect your ears.
Protect your hands.
A5P | 01
Please read all instructions carefully before use and retain
for future reference.
INTENDED USE Only operate the power tool/machine
for its intended purpose and within the parameters
specified in this manual.
This power tool/machine is for domestic use only. This
power tool/machine is not intended for use by persons
with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless supervised or
given appropriate instruction concerning the product's
use by a person responsible for their safety.
GENERAL PRECAUTION Do not allow to be used as a
toy. Children should be supervised to ensure they do not
play with the power tool/machine.
If the power tool/machine is not functioning properly,
has been dropped, damaged, left outdoors, or immersed
in liquid, do not use, contact DOMU Brands Customer
Services.
Do not use the power tool/machine if any parts appear to
be faulty, missing or damaged.
Ensure all parts are securely attached before use.
RISK OF PERSONAL INJURY Avoid body contact with
earthed or grounded surfaces such as pipes,radiators,
ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
Prevent unintentional starting. Ensure the switch is in the
off position before connecting to the power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch, or energising
power tools that are switched on, invites accidents.
Do not operate power tools in explosive atmospheres
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
Always wear eye protection. Any power tool can throw
foreign objects into your eyes and cause permanent
eye damage. Always wear safety goggles (not glasses)
that comply with ANSI safety standard Z87.1. Every day
glasses have only impact resistant lenses.
Do not expose power tools to rain or wet conditions.
Water entering the power tools will increase the risk of
electric shock.
Stay alert, watch what you are doing and use common
sense when operating a power tool/machine. Do not
use a power tool/machine while you are tired or under
the influence of drugs, alcohol or medication. A moment
of inattention while operating power tool/machine may
result in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to power source and/or
battery pack, picking up or carrying the tool.
Carrying power tool/machine with your finger on the
switch or energizing power tool/machine that have the
switch on invites accidents.
Remove any adjusting key or spanner before turning the
power tool/machine on. A spanner or a key left attached
to a rotating part of the power tool/machine may result in
personal injury.
Do not overreach. Keep proper footing and balance at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2515367 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VonHaus 2515367

  • Page 1 2515367 Please read all instructions carefully before use and retain for future reference. INTENDED USE Only operate the power tool/machine for its intended purpose and within the parameters specified in this manual. This power tool/machine is for domestic use only. This...
  • Page 2: Technical Specification

    all times. This enables better control of the power tool/ bind and are easier to control. machine in unexpected situations. Regularly check external nuts and fixings to ensure Dress appropriately. Do not wear loose clothing or vibration caused by normal use has not begun to loosen jewellery.
  • Page 3 COMPONENTS 22 23 24 25 1. Auxiliary Handle/Secondary Handle . 16. Brush Cutter Disc. 2. Auxiliary Handle Locking Screw. 17. Spool Assembly. 3. Spring Pin. 18. Spool Locking Nut (pre-assembled into 17). 4. Locking Grip (not pictured). 19. Brush Cutter Locking Plate. 5.
  • Page 4 HANDLE / STRAP ASSEMBLY Adjust the Secondary Handle (1) to the left or right position using the Hex Key (27) supplied. Position the Auxiliary Handle (1) to the Main Unit Pole (5) between the 2 foam grips or where the appropriate po sition is to obtain the best balance.
  • Page 5: Trimmer Assembly

    TRIMMER ASSEMBLY 23/22/24 Align the Gear Box (12) and Lower Pole (13) with the 3 holes on the Inner Mounting Plate (14). Secure in place from the inside using 3 Small Hex Bolts (24), 3 Washers (23) and 3 Spring Washers (22) in the order shown on the right.
  • Page 6 TRIMMER ASSEMBLY With the Coupling Plate (20) in position, place the Spool Assembly (17) over the drive shaft and turn counter- clockwise to secure. IMPORTANT! Ensure the Spool Assembly is completely secure before initial use. NOTE: The Gearbox shaft is a reverse thread. Counter- clockwise to tighten, clockwise to loosen.
  • Page 7: Power On/Off

    USEAGE POWER ON/OFF To operate, press the Safety Switch (6) forwards whilst at the same time pressing the ON/OFF Trigger (7). Release the Safety Switch (6) once powered on. NOTE: When the Trimmer starts up there may be some kickback, always ensure you are stood firmly and have a firm grip.
  • Page 8: Replacing The Spool

    REPLACING THE SPOOL Protect your hands. Detach the Spool Locking Nut (18) by twisting clockwise to release. Once removed, lift the Spool Assembly (17) off the Gear Box drive shaft. To access the Spool thread, gently push the cover down and twist clockwise to unlock.
  • Page 9 REPLACING THE SPOOL NOTE: If the Spool Line is too long, it will automatically be cut down by the Small Blade attached to the plastic trimmer guard once the tool is switched on. Once wound, hook one end into the outer eyelet ( fig 2 ) and insert the other end through one of the eyelets on the Spool Assembly (17).
  • Page 10 BRUSH CUTTER ASSEMBLY Next, place the Brush Cutter Locking Plate (19) over the drive shaft. NOTE: Ensure the flat side of this plate sits against the Brush Cutter Disc (16). Secure all plates together using the Hex Nut (21) supplied. Tighten using the Maintenance Tool (28). Finally, insert the Split Pin (26) into the small hole of the drive shaft and bend around the Nut.
  • Page 11: Part Maintenance

    BRUSH CUTTER ASSEMBLY WARNING! Ensure the area you are cutting is completely free any stones or debris. These can cause serious damage to the Garden Tool, the user and any passers-by. Just like operating the Trimmer, ensure you are holding the equipment firmly in both hands when using the Brush Cutter attachment, with one hand on the rear handle and the other holding the Auxiliary Handle.
  • Page 12: Cleaning And Maintenance

    BRUSH CUTTER ASSEMBLY SHARPENING THE BRUSH CUTTER DISC Never attempt to sharpen the Disc (16). The Brush Cutter Disc is reversible, so should be turned over when one side is blunt (see page 11 for fitting). The Disc must remain balanced when fitted. An unbalanced Disc will cause excessive vibration through the tool.
  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION Ensure the tool is switched on and connected to mains power. Tool does not power on Activate the ON/OFF Trigger Switch. Check the fuse and replace if necessary. Driver gear may be broken. Contact DOMU Brands Disc does not move Customer Services.
  • Page 14: Vielen Dank

    VonHaus es una marca registrada de DOMU Brands Ltd. this manual, and all other instructions have been followed accurately. Any abuse of the product or the manner in Hecha en China para DOMU Brands.
