GETTING TO KNOW THE MONITOR AND CAMERA

Receiver
(Back view)
SD slot
Reset Button
AC Power
Connection
WHAT THE LIGHTS MEAN
Light
Power status
Link status
Pull-Out
Stand
Ethernet Jack
State
On
(Red)
Off
Flashing
On
(Green)
Off
Receiver
(Front view)
Antenna
What it means
The camera is on.
The camera is off.
The camera is in pairing mode.
The camera is connected to the receiver.
The camera is in standby.
10
Power
On/Off
