Operation
Manual
INVERTER-DRIVEN
MULTI-SPLIT SYSTEM
HEAT PUMP
AIR CONDITIONERS
Type
Ducted
(
)
High Static
Pressure Type
Ducted
(
)
Medium Static
Pressure Type
IMPORTANT:
READ AND UNDERSTAND
THIS MANUAL BEFORE
USING THIS HEAT PUMP
AIR CONDITIONER.
KEEP THIS MANUAL FOR
FUTURE REFERENCE.
Model
RPI-2.0FSN3
RPI-2.5FSN3
RPI-3.0FSN3
RPI-4.0FSN3
RPI-5.0FSN3
RPI-6.0FSN3
RPIM-0.8FSN3
RPIM-1.0FSN3
RPIM-1.5FSN3
RPIM-2.0FSN3
RPIM-2.5FSN3
RPIM-3.0FSN3
RPIM-4.0FSN3
RPIM-5.0FSN3
RPIM-6.0FSN3
P5417020
Advertisement
Table of Contents
Related Manuals for Hitachi RPI-2.0FSN3
Summary of Contents for Hitachi RPI-2.0FSN3
- Page 1 Operation Manual INVERTER-DRIVEN MULTI-SPLIT SYSTEM HEAT PUMP AIR CONDITIONERS Type Model RPI-2.0FSN3 RPI-2.5FSN3 Ducted RPI-3.0FSN3 High Static RPI-4.0FSN3 Pressure Type RPI-5.0FSN3 RPI-6.0FSN3 RPIM-0.8FSN3 RPIM-1.0FSN3 RPIM-1.5FSN3 Ducted RPIM-2.0FSN3 Medium Static RPIM-2.5FSN3 Pressure Type RPIM-3.0FSN3 RPIM-4.0FSN3 RPIM-5.0FSN3 RPIM-6.0FSN3 IMPORTANT: READ AND UNDERSTAND...
- Page 3 Important Notice ● HITACHI pursues a policy of continuing improvement in design and performance in its products. As such, Johnson Controls Inc. reserves the right to make changes at any time without prior notice. ● HITACHI cannot anticipate every possible circumstance that might involve a potential hazard.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. Introduction ..............................1 2. Safety Instructions ............................1 3. Before Operation .............................9 3.1 Working Range ............................9 3.2 Efficient Use of Indoor Unit ........................9 3.3 Efficient Use of Cooling and Heating ......................9 4. Names of Parts .............................10 4.1 Ducted Type ............................10 4.2 Wired Controller (PC-ARF1) ......................... -
Page 5: Introduction
● This system should be installed by personnel certified by HITACHI. Personnel must be qualified according to local, state and national building and safety codes and regulations. Incorrect installation could cause leaks, electric shock, fire or explosion. In areas where "Seismic Performance" requirements are specified, the appropriate measures should be taken during installation to guard against possible damage or injury that might occur in an earthquake if the unit is not installed correctly, injuries may occur due to a falling unit. - Page 6 This unit is the pressurized system. Never loosen threaded joints while the system is under pressure and never open pressurized system parts. ● HITACHI will not assume any liability for injuries or damage caused by not following steps outlined or described in this manual. Unauthorized modifications to HITACHI products are prohibited as they… ◦...
- Page 7 ▫ Damp or uneven areas: Use a raised concrete pad or concrete blocks to provide a solid, level foundation for the unit to prevent water damage and abnormal vibration. ▫ An area with high winds: Securely anchor the outdoor unit down with bolts and a metal frame. Provide a suitable air baffle.
- Page 8 As originally manufactured, this unit contains refrigerant installed by HITACHI. HITACHI uses only refrigerants that have been approved for use in the unit’s intended home country or market. HITACHI distributors similarly are only authorized to provide refrigerants that have been approved for use in the countries or markets they serve.
- Page 9 ● Clamp electrical wires securely with a cable band after all wiring is connected to the terminal block. In addition, run wires securely through the wiring access channel. ● When installing the power lines, do not apply tension to the cables. Secure the suspended cables at regular intervals, but not too tightly.
- Page 10 ● Proper handling of this unit requires two-people. Safe handling and installing the indoor unit requires the strength of two people. Mounting the unit alone may cause injury due to fall of the unit. Although the unit may be girded with steel banding, do not use it for transportation. Avoid contact with finned surfaces of the heat exchanger as sharp edges can cause severe injury to hands and fingers.
- Page 11 Operation ● Do not insert fingers or objects into an air inlet/outlet. Injury can result from rotating fan blades or energized electrical components. ● Do not touch the wired controller with wet hands. It can result in a malfunction of the wired controller or an electrical shock.
- Page 12 Repair / Relocation ● When the air conditioner is to be repaired or transported to a new location, contact your distributor or contractor. If the repair and the installation are not completed correctly, it may cause an electric shock or fire.
-
Page 13: Before Operation
Before Operation NOTICE Power is turned on. Apply power to the outdoor unit(s) at least 12 hours prior to operation of the system for preheating of the compressor oil. Make sure that the outdoor unit is not covered with snow or ice. If it is, remove it by using hot water that is approximately 122 F (50 If the water temperature is higher than 122 F (50... -
Page 14: Names Of Parts
Names of Parts Ducted Type Air Filter The mounting position may Air Inlet Duct Canvas Duct be different depend on the (Field-Supply) (Field-Supply) (Field-Supply) installation condition Air Outlet Duct (Field-Supply) Air Outlet Grille (Field-Supply) Air Inlet Grille Canvas Duct (Field-Supply) (Field-Supply) Indoor Unit Location of Indoor... -
Page 15: Wired Controller (Pc-Arf1)
Wired Controller (PC-ARF1) The example below references the control panel and all adjustable settings. The wired controller display may be Display Part different during actual operation. Fan Speed Indicator Schedule Timer Indicator It is indicated when the schedule timer function is set. (*) Operation Mode Indicator Operation Lock Indicator... -
Page 16: Operation Method
Operation Method Basic Operation By pressing “ ”or “ ”, the icon “ ” will move between “MODE”, “SPEED”, Menu “LOUV.” and “TEMP”. Item Back/Help Selection With (“MODE”, “SPEED”, “LOUV.” or “TEMP”) selected, press “ ” or “ ”. Menu The setting will be changed. -
Page 17: Cooling / Heating / Fan Operation
Cooling / Heating / Fan Operation Heating Operation is for VRF system only and is not available for other systems. <Function> * Cooling Operation: To decrease the room temperature. * Heating Operation: To increase the room temperature. * Dry Operation: To decrease the humidity in the room. -
Page 18: Temperature Setting
Temperature Setting Press “ ” or “ ” and select “TEMP”. Menu Back/Help By pressing “ ”, the temperature is increased by 1 F (0.5 (Max. 86 F (30 Menu By pressing “ ”, the temperature is decreased by 1 F (0.5 Back/Help COOL, DRY, FAN operation: Min. -
Page 19: Fan Speed
Fan Speed Press “ ” or “ ” and select “SPEED”. Menu Back/Help By pressing “ ” or “ ”, the fan speed will be changed as follows. Menu Back/Help HIGH 2 HIGH AUTO ● During the dry operation, the fan speed is automatically changed to “LOW” and cannot be changed to any other fan speed. -
Page 20: Motion Sensor
Motion Sensor This setting is available only for the motion sensor kit. <Function> * The motion sensor detects a human activity by the change of the infrared light. This function saves the air conditioning capacity (adjusting the set temperature and the air flow volume) automatically depending on a situation. -
Page 21: Details For Motion Sensor Control
5.6.1 Details for Motion Sensor Control The motion sensor control adjusts automatically the following items depending on a situation. ● Setting Temperature: The temperature is adjusted 1 C or 2 C for saving capacity. ● Air Flow Volume: The air flow volume is adjusted to lower one volume or to “Slo” (except during the dry operation). 5.6.2 Descriptions for Setting Items ●... -
Page 22: Setting Of Motion Sensor
5.6.3 Setting of Motion Sensor Press “Menu”. Menu 15:10(Fri) Select “Motion Sensor Setting” from the Adjusting Date/Time Daylight Saving Time menu by pressing “ ” or “ ” and press Menu 15:10(Fri) Screen Display Setting Function 19 Individual Louver Setting “OK”. - Page 23 Press “ ” or “ ” and select “Check Menu Motion Sensor Setting interval”. Sensor ALL MODES Back/Help If absent Check interval 30min Sel. Adj. Entr Back Rtrn The display is switched “30min”, “60min”, Menu Motion Sensor Setting “90min”, “120min” and “180min” in order Sensor ALL MODES by pressing “...
-
Page 24: Comfort Setting
(3) The setting confirmation screen will be Comfort Setting displayed. Select “Yes” with “ ” or “ ” This function is used to control cooling of the and press “OK” to confirm the setting. The discharged air when in the cooling mode. screen will return to normal mode. -
Page 25: Automatic Control
Automatic Control This air conditioner automatically starts the following operations according to the indoor conditions. The system is equipped with the following functions. ▪ Enforced Stoppage: The compressor remains off for at least three minutes once it has stopped. If the system is started within approximately three minutes after it has stopped, the RUN indicator is activated. -
Page 26: Maintenance
Maintenance ● Turn OFF the power source before the maintenance work. If the power source is not turned OFF, the result may be an electric shock or fire. ● Perform the maintenance work with a stable foothold or foundation. This may prevent falling or injury. ●... -
Page 27: Maintenance
(3) Reset the filter sign. NOTE If the accumulated operation time is shorter than the filter sign setting, the indication “ ” is turned ON and “Setting Disabled” will be displayed. • Press “Menu”. Select “Reset Filter Sign Time” from the menu and press “OK”. The confirmation screen will be displayed. -
Page 28: Troubleshooting
Troubleshooting This is Not Abnormal Phenomenon Cause All indication lights on the The micro-computer is activated to protect the wired controller are turned device from electromagnetic waves. Restart the OFF. operation. It is because “If absent: Stop” is selected in the motion sensor setting and the operation is “Motion Sensor ON”... -
Page 29: Before Contacting A Contractor
Before Contacting a Contractor Refer to the information below before contacting a contractor. Trouble Check Point Action Check that the main power Turn ON the main power source for the air source is turned ON. conditioner. Check that the fuse is not Operation Unavailable Replace the fuse or reset the circuit breaker. -
Page 30: Contact Distributor
Contact Distributor If problem still remains even after checking previous issues or other problems not mentioned in the previous issues occur, stop using the product and contact your distributor or contractor. If an abnormality such as a burnt odor or something similar occurs, stop the operation and turn OFF the main power source immediately. -
Page 31: Alarm Code
Alarm Code Code Category Content of Abnormality Code Category Content of Abnormality Indoor Unit Incorrect Setting of Indoor Unit No. Activation of Protection Device Activation of Protection Device Outdoor Unit Incorrect Indoor Unit Combination System (High Pressure Cut) Operational Irregularities between Problem with Protective Pickup Circuit in Outdoor Unit Indoor and Outdoor... - Page 32 © 2017 Johnson Controls-Hitachi Air Conditioning Technology (Hong Kong) Ltd. P5417020, 2017 Printed in Japan...
