Schweizer eMag 50 HD Instructions For Use Manual

Electronic magnifier
Hide thumbs Also See for eMag 50 HD:
Table of Contents

Advertisement

Quick Links

Download this manual
eMag 50 HD
Instructions for use
EN
for the electronic magnifier

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eMag 50 HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schweizer eMag 50 HD

Summary of Contents for Schweizer eMag 50 HD

  • Page 1 50 HD Instructions for use for the electronic magnifier...
  • Page 2 Congratulations on purchasing the eMag 50 HD. This handheld video magnifier enables you to magnify texts and objects from 2 to 14 times the original size. The eMag 50 HD features a 5" (12.7 cm) LCD widescreen (16:9). We hope you enjoy using this high-quality device. The information and data contained in this docu- ment are subject to change without notice.

  • Page 3: Table Of Contents

    Functions Transferring images to a computer Magnifying live images via USB cable Magnifying captured and Transferring images to the eMag 50 HD saved images via USB cable Changing colour modes Troubleshooting Changing between the last colour mode...

  • Page 4: Emag 50 Hd - Overview

    50 HD – overview Intended use This electrical device serves to electronically enlarge objects or for reading printed materials in everyday use. Clinical Use This electrical device contributes significantly to daily tasks, facilitates independence, increases productivity and improves self-esteem.

  • Page 5: Performance Characteristics

    With the reading stand opened, you can place the eMag 50 HD directly on a document and read printed text or images in magazines, catalogues, menus, photos or other printed matter. The eMag 50 HD can save and store up to 80 images, which can be copied to a computer via a simple USB connection.

  • Page 6: Emag 50 Hd Components

    50 HD Components 1 Colour mode scroll up (blue) 2 Colour mode scroll down (blue) 3 Power on / off (green / yellow) 4 Increase magnification (yellow) 5 Decrease magnification (yellow) 6 Capture image (red) 7 LCD screen 8 USB port (micro USB) 9 Power adapter port (5V;...
  • Page 7 11 Handle in closed position 12 LED lights 13 Camera (5 MP)

  • Page 8: Quick Start

    3. Select one of the following options: Turn and extend the handle to hold and use the eMag 50 HD like a magnifying glass. This is useful if you need to magnify and read labels or small print on tins, packaging, medication etc. (Refer to page13).
  • Page 9 (Refer to pagea 21 / 22). You can save and view images and also delete images saved on the eMag 50 HD (Refer to pages 26 / 25). For additional memory space, copy the images from the eMag 50 HD to your computer (Refer to page 26).

  • Page 10: Charging The Emag 50 Hd

    USB port on a computer. 1. Plug one end of the power adapter into the eMag 50 HD and the other end into the wall outlet (1). 2. The battery status LED flashes green to show that the battery is charging (2).

  • Page 11: Battery Status Led

    Battery status LED Green solid: Batteries are charged, power adapter connected. Batteries are charging, power adapter connected. Green flashing: Low battery status. Red flashing: Red solid: Error: disconnect power adapter, wait a few seconds and then reconnect it.

  • Page 12: Description Of Buttons

    Description of buttons On / Off (green / yellow): Press once to switch on, press again to switch off. Magnification (yellow): Press and HOLD for continuous zoom magnification with live view. When viewing captured images, press and release to incrementally increase or decrease magnification.

  • Page 13: Opening And Closing The Handle

    Opening and closing the handle The handle can be opened in 2 positions, allowing you to hold the eMag 50 HD like a magnifying glass.

  • Page 14: Opening The Reading Stand

    Opening the reading stand The eMag 50 HD also has a reading stand, which – as soon as it is positioned on a document – allows you to read an item from a constant and convenient distance. 1. Slide the upper edge of the eMag 50 HD screen...

  • Page 15: Functions

    Functions Magnifying live images When viewing live images, you can use the continuous zoom function to magnify live images from 2x to 14x the original size. Press and HOLD the yellow PLUS button to zoom in. Press and HOLD the yellow MINUS button to zoom out.

  • Page 16: Changing Colour Modes

    If you need to move the eMag 50 HD to a different part of the document, it may be easier for you to switch to full colour mode, move to the new position in the document and then return to the selected colour mode to continue reading.

  • Page 17: Adding / Removing Colour Modes

    Adding / removing colour modes The eMag 50 HD has 5 default colour modes. You can also activate and choose from a variety of 15 other colour modes. As soon as a colour mode is available, you can easily scroll to it using the blue arrow buttons ( or ).

  • Page 18: Restoring Default Colour Modes

    Restoring default colour modes If you have added or removed optional colour modes, you can always reset the eMag 50 HD to its 5 default colour modes: Press and HOLD the green / yellow button and the blue UP arrow simultaneously for 15 seconds.

  • Page 19: Optional Colour Modes

    Optional colour modes Black on yellow Blue on black Black on magenta Green on black Blue on yellow Violet on black Black on green Red on black Black on violet White on blue Black on red Red on white Black on blue Magenta on black Black on light blue...

  • Page 20: Capturing An Image

    Capturing an image on the LCD screen can be useful for reading labels on objects or supermarket shelves. By holding the eMag 50 HD close to an object and capturing the image, you can then hold the eMag 50 HD closer to you to read the information.

  • Page 21: Using Reading Line Or Reading Mask

    Use these features to help you locate and maintain your place while viewing an image. When using the button sequence described below, the eMag 50 HD shows first the reading line, then the reading mask and then neither the reading line nor the reading mask.

  • Page 22: Displaying The Reading Mask

    Displaying the reading mask 1. Press and HOLD the green / yellow button (1) and then press both yellow buttons ( (2 and 3)) again to remove the reading line and display the reading mask on the screen as shown below: 2.

  • Page 23: Storage Mode

    The image will be deleted when you exit Storage mode. Memory full: Indicates that the maximum number of images has been stored on the eMag 50 HD.     You will need to select one or more images for deletion before you can save the current image.

  • Page 24: Viewing Saved Images

    Viewing saved images The eMag 50 HD can store up to 80 images. You can easily scroll through your saved images using the blue arrow buttons ( and ): 1. Press and HOLD the red button for approx. 6 seconds to access Overview mode.

  • Page 25: Deleting An Image In Storage Mode

          The eMag 50 HD can store up to 80 images. If you try to save a further image, the Memory full icon appears on the screen. To save a further image, you first need to delete one or more saved images from the memory.

  • Page 26: Transferring Images To A Computer Via Usb Cable

    50 HD appears as an external device in Explorer (Windows) or Finder (Mac). 3. Open the "eMag 50 HD DCIM" folder and use the "drag and drop" method to move or copy one or more images to a folder or the desktop on your computer. The images are named and numbered in the order saved, for example IMG_0001.bmp, IMG_0002.bmp etc.

  • Page 27: Transferring Images To The Emag 50 Hd Via Usb Cable

    Transferring images to the eMag 50 HD via USB cable Any image transferred from the eMag 50 HD to your computer can be easily transferred back to the eMag 50 HD. Note: Only images saved by the eMag 50 HD can be copied back to the eMag 50 HD.

  • Page 28: Troubleshooting

    Solution The device does not power on. Press the green / yellow power button. If the eMag 50 HD does not power on, charge or replace the battery. Note: The battery does not charge while the eMag 50 HD is connected to the USB port.
  • Page 29 The battery is not charging. Use the supplied power adapter to charge the eMag 50 HD. The battery does not charge when the eMag 50 HD is connected to a USB port. Make sure the barrel end of the power adapter is firmly plugged into the device's power port.

  • Page 30: Technical Data

    5 MP HD auto-focus camera module Battery: Lithium-ion battery, approx. 3 hours continuous operation, approx. 3.5 hours charge time Note: Only use the supplied power adapter to charge the eMag 50 HD battery. Manufacturer Vispero Pesetastraat 5a 2991 XT Barendrecht...

  • Page 31: Safety And Maintenance

    Always operate the eMag 50 HD at an ambient temperature between 10° and 35° C. Never store the eMag 50 HD in places subject to temperature extremes such as a parked car. Do not force any connector into the power port of the eMag 50 HD. The power connector fits easily into the port.

  • Page 32: Cleaning The Emag 50 Hd Housing

    Cleaning the eMag 50 HD housing Make sure the eMag 50 HD is unplugged. Use a slightly dampened, soft, clean cloth with water or a mild detergent. Do not use alcohol, solvents, abrasives or aerosol sprays. Cleaning the eMag 50 HD LCD screen Power off and unplug the eMag 50 HD before cleaning the LCD screen.

  • Page 33: Battery Safety Instructions

    Battery safety instructions We place our batteries on the market in line with legal requirements. Please read the points below for the safe removal and disposal of our batteries: Our product contains a rechargeable battery. To prevent harmful effects to the environment and health, used batteries must be disposed of properly at recycling centres or returned to the point of sale.

  • Page 34: Symbol Guide

    Symbol guide Item no Batch number Serial number Medical device Authorised representative Manufacture Manufacture date Barcode Fragile, handle with care Protect from moisture Warning Consult instructions for use Disposal information Power supply Declaration of conformity CE marking of conformity...
  • Page 36 A. SCHWEIZER GmbH Hans-Böckler-Straße 7, 91301 Forchheim, Germany Phone +49 9191-72100, Fax +49 9191-721072 info@schweizer-optik.de, www.schweizer-optik.de...
