Ultrasonic Anemometer
User Manual
(
Part Numbers 1390-65-X-XXX)
gillinstruments.com
Issue: 8 (Applies to firmware 2387 6.09 onwards)
Document number: 1390-PS-0039

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WindObserver 65 and is the answer not in the manual?

Questions and answers

Related Manuals for Gill WindObserver 65

Summary of Contents for Gill WindObserver 65

  • Page 1 Ultrasonic Anemometer User Manual Part Numbers 1390-65-X-XXX) gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...

  • Page 2: Table Of Contents

    User Manual Revision History ......................5 Product Overview ........................ 6 Pre-Installation ........................6 3.1. Equipment supplied ........................... 6 3.2. WindObserver 65 Part Numbers ....................... 6 3.3. WindObserver Accessories ........................ 7 3.4. WindObserver FCC ..........................7 3.5. Right to change and revise ........................ 8 3.6.
  • Page 3 Appendix F - Configuring ......................50 Appendix G - WindObserver 65 ASCII Data Output ..............58 Appendix H - WindObserver 65 NMEA 0183 Data Output ............59 Appendix I - Polled Mode Commands ..................60 Appendix J - WindView Software .................... 61 Appendix K - WindObserver 65 Status Codes .................

  • Page 4: Welcome To The Windobserver Manual

    1. Welcome to the WindObserver manual. About this manual This manual provides the information needed to get the best results from WindObserver 65. The most recent version of this manual is available at gillinstruments.com. Please read this manual before setting up and installing WindObserver 65.

  • Page 5: General Notes

    1.3. General Notes Before WindObserver 65 is used for the first time it is essential to read and understand this manual. Please keep the manual safe for future reference. Care should be taken with WindObserver 65 at all times. The product should be transported to site in the box, and only removed when ready to install.

  • Page 6: Product Overview

    The WindObserver 65 is available with or without de-icing heating (recommended if icing is likely), The WindObserver 65 can be used in conjunction with a PC, data logger or other device, provided it is compatible with the RS422 output, Multiple units can be networked if required.

  • Page 7: Windobserver Accessories

    Gill Bracket Mounting Adaptors 1771-PK-116 After you have successfully set up the WindObserver 65, we strongly advise that you then go back and read the rest of the manual to ensure that you get the best results from the WindObserver 65.

  • Page 8: Right To Change And Revise

    Gill Instruments. 3.6. Packaging Whilst the WindObserver 65 is being moved to its installation site, the unit should be kept in its packaging. Retain the packaging for use if the unit must be moved or returned to Gill Instruments.

  • Page 9: Requirements & Installation

    The WindObserver 65 can be supplied with a short or long base mount to use with a mounting adaptors The WindObserver 65 can be attached to the bracket via the four tapped holes in the base mount fitted to the unit. The gasket supplied can be fitted between the sensor and its mounting bracket when it is important to minimise the effects of corrosion should two dissimilar metals be used.

  • Page 10: Installation

    Take care not to knock the four Transducer arms. All the time the WindObserver 65 is not in its final location, it should be protected from damage by keeping it in the original packaging as long as possible, treating it as a delicate instrument.

  • Page 11: Bench System Test

    Ultrasonic Anemometer 4.4. Bench system test Prior to physically mounting the WindObserver 65 in its final location, we strongly recommend that a bench system test be carried out to confirm the system is configured correctly, is fully functional and electrically compatible with the selected host system and cabling (preferably utilising the final cable length).

  • Page 12: Power Supplies

    Ultrasonic Anemometer Cabling and junction box If the WindObserver 65 unit is fitted with a flying 9 pair cable attached this must be terminated in a suitable terminal box to IP66 or better, fitted with glands to prevent moisture ingress.

  • Page 13: Mechanical Installation

    Location It is important to ensure that the WindObserver 65 is mounted in a position clear of any structure, which may obstruct the airflow or induce turbulence. Do NOT mount the WindObserver 65 in close proximity of high-powered radar or radio transmitters. A site survey may See Section 5.3)
  • Page 14 Ultrasonic Anemometer WindObserver Sensor and Bracket Mounting Mount the Sensor on to the Bracket so that the Sensor North Marker points to the bracket pole. Secure the sensor to its mount using the three M5 screws and three M5 split wavy washers supplied in the mounting bracket kit box.
  • Page 15 Ultrasonic Anemometer Weight 1.29Kg (without Sensor fitted) Material Anodised Aluminium Bracket with Stainless Steel Mount and fittings. An isolation gasket is fitted between the Stainless Steel mount and the Bracket to reduce corrosion. gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...
  • Page 16 The example shows a long mount fitted to a cable gland unit, a similar Earthing/ mounting arrangement can be used with short mounts and connector based units. A mounting kit (1390-10-164) is supplied with the WindObserver 65 to allow assembly of the mount to the base of the WindObserver.
  • Page 17 Ultrasonic Anemometer Figure 1 gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...
  • Page 18 Ultrasonic Anemometer Pipe mounting (use with Pipe Mount) The Pipe Mount base for the WindObserver 65 has the following dimensions. Included in the supplied mounting kit is an O Ring Seal which must be fitted inside of the Pipe Mount Base.
  • Page 19 Custom Mount (Use with WindObserver No Mount Option) Although it is recommended that customers select a base mount option from Gill Instruments, should a customer wish to design their own mount then the WindObserver base dimension details for this are as follows:-...
  • Page 20 Ultrasonic Anemometer Alignment The anemometer should be set to point North (or to another known reference direction), using the North Spar, which can be identified from the red dot on the base of the instrument or vertical groove on short base, long base or pipe mount adaptor.
  • Page 21 Ultrasonic Anemometer Figure 2a North Marker (Long Base Mount shown for illustrative purposes) Red Dot and Base Mount Vertical Groove. Gasket Mounting Ring (if required). Pipe Mount units do not require the gasket and mounting ring. gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...
  • Page 22 Ultrasonic Anemometer Figure 2b WindObserver 65 outline dimensions Short Base Mount Unit Dimensions Long Base Mount Unit Dimensions Pipe Mount Unit Dimensions gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...
  • Page 23 Ultrasonic Anemometer gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...

  • Page 24: Message Formats & Options

    Ultrasonic Anemometer 5. Message Formats & Options On first applying power to the WindObserver 65, it will be in ‘Measurement Mode’, and it will output wind measurement information within 3 seconds in one of the formats as described below. Setting the output format, units, other parameters, options and the communication settings are all carried out in the alternative ‘Configuration Mode’.

  • Page 25: Units

    Ultrasonic Anemometer 1. Continuous Output: In this mode the unit continuously outputs a burst of RS422 level data (the frequency determined by the output rate setting). After the burst of data and until the next data burst the data lines revert to a high impedance state.

  • Page 26: Averaging (Digital Data)

    Ultrasonic Anemometer 5.5. Averaging (Digital Data) There are two digital averaging options: - 5.5.1. G Command Averaging Using the G Command in association with modes other than M14, M15 and polled modes. The Averaging Period can be set from zero to 3600 secs. (1 hour). The default setting is zero. When averaging is enabled, data is output at a rate determined by the averaging period.
  • Page 27 Ultrasonic Anemometer are: - RWA Default settings P (Output rate Hz RWASHORT = 60 RWALONG = 10 Therefore: Anemometer output period = 60/1 = 60 seconds (the WindObserver will output a reading every 60 seconds). Averaged direction and magnitude reading = 10 x 60 = 600 seconds This is the time the readings will be averaged over).
  • Page 28 Ultrasonic Anemometer The Maximum Gust Direction is the direction of the maximum gust measured over the short term output period. Gust is generated from a rolling 3s average of the short term output period, and reset at the end of short term output period. The maximum Gust Magnitude is the magnitude of the maximum gust measured over the short term output period.
  • Page 29 Ultrasonic Anemometer The polled mode commands available in this mode are: Description Command WindObserver response Enable Polled Mode (None) WindObserver Unit Identifier (N) A…….Z Output generated Disable Polled mode (None) Request WindObserver Unit Identifier & A ….. Z (as configured) Enter Configuration mode *<N>...

  • Page 30: Options

    Ultrasonic Anemometer 5.6. Options Heating (If fitted) Heating is autonomous and requires no set-up once activated. 45° Offset If required, the U axis can be offset +45° to the transducer axis. Vertical Output Padding A dummy W vector is inserted to provide compatibility with any WindMaster that may be in a network. gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...

  • Page 31: Ascii Message Format (Uv, Polar And Tunnel)

    Ultrasonic Anemometer 5.7. ASCII message format (UV, Polar and Tunnel) ASCII UV format U axis wind speed V axis wind speed Units <STX>A,+000.04,-000.02,M,00,<ETX>25 Start of Unit identifier Status End of Check sum string string Where U axis wind speed In increments of 0.01 units (±UUU.UU) V axis wind speed In increments of 0.01 units (±VVV.VV) Value...
  • Page 32 Ultrasonic Anemometer ASCII Polar format Wind direction Wind speed Units <STX>A,121,000.08,M,00,<ETX>06 Start of Unit identifier Status End of Check sum string string Where Wind direction In degrees relative to N (DDD) Wind speed In increments of 0.01 units (±MMM.MM) All other parameters See Section 5.7 ASCII UV format ASCII Polled (UV and Polar)
  • Page 33 Ultrasonic Anemometer It is suggested that in polled mode the following sequence is used for every poll for information. Ensures that the Sensor is enabled to cover the event that a power down has occurred. Appropriate unit designator sent to retrieve a line of data. Sent to disable poll mode and reduce possibility of erroneous poll generation.

  • Page 34: Binary Message Format (Uv,Polar And Tunnel)

    Ultrasonic Anemometer 5.8. Binary message format (UV, Polar and Tunnel) Binary UV format U axis wind speed V axis wind speed Units 0x81 0x81 000.04 -000.02 +022.36 00 1 Start of string Temperature Status Where U axis wind speed In increments of 0.01 units (±UUU.UU) V axis wind speed In increments of 0.01 units (±VVV.VV) Value...
  • Page 35 Ultrasonic Anemometer Binary Polar format Wind speed Wind direction Units 0x81 0x81 006.04 265 +022. 36 00 1 Start of string Temperature Status Where Wind direction In degrees relative to N (DDD) Wind speed In increments of 0.01 units (±MMM.MM) All other parameters See Section 5.8 Binary UV format...

  • Page 36: Nmea Format

    Exclusive OR of all characters between ‘$’ and ‘*’ reported as ASCII hex. A typical WindObserver 65 configuration suitable for NMEA would be: B2, E1, F1, G0, K1, L1, M5, O1, P1, U1. Consult specification NMEA 0183 version 3 (available on the web) www.nmea.org for complete interface details.

  • Page 37: Averaging Format (Modes 14 And 15)

    Ultrasonic Anemometer 5.10. Averaging Format (Modes 14 and 15) See also Para 5.5.2. Max Gust Max Gust Start of Unit Identifier Direction Speed String <STX>A, M15, 270,002.02, M, 253,002.83, 00, <ETX>4D End of Check Wind Wind Status Mode Units String Direction Speed Start of string...

  • Page 38: Appendix A - Technical Specification

    1200, 2400, 4800, 9600, 19200, 38400 Formats 8 data bits, odd, even or no parity, 1 stop bit Weight & Dimensions Size See manual Fig 2b for dimensions WindObserver 65 Weight 1.34kg (no mount or lead) Base Mount Short 0.63kg Base Mount Long 1.05kg Pipe Mount 1.06kg...
  • Page 39 Ultrasonic Anemometer Environmental Moisture protection IP66 (NEMA4X) Operating temperature -55°C to +70°C (heated version) Humidity 0% to 100% RH Precipitation 300mm/hr Humidity 0 to 100% EN 61326-1:2006 EN 60945:2002 FCC CFR47 Parts 15.109 Class A Icing MILSTD810F Method 521.1 Procedure 1 Standards Traceable to UK national standards Lloyds Register Type Approved...

  • Page 40: Appendix B - Connector And Cable Assembly

    Ultrasonic Anemometer Appendix B - Connector and Cable Assembly The WindObserver 65 variant with a connector base is supplied with a mating 19-way connector. (Gill Part 1390-10-163). Open the pack of connector parts supplied A set of assembly instructions are supplied with the connector together with:-.
  • Page 41 Ultrasonic Anemometer Prepare Connector Head (Gill Part 020-04464). Remove the connector thread protector and place the O-ring (part 7) into the groove of the connector head (020-04464). O-Ring to be placed here Remove the thread protector Assemble Connector to the Cable Referring to Page 40 and Page 43 push connector contacts through the red connector head seal into the appropriate location, when in place there should be a click as the contact locks into position.
  • Page 42 Ultrasonic Anemometer 4. Pass parts 3 and 2, the cable seal and cable grip from the connector kit, along the cable to the housing. 5. Now screw in item 1, the clamp nut, over parts 2 and 3 and onto the housing and torque up to a value of 10Nm. Part 1 gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards)

  • Page 43: Appendix C - Connections And Default Setup

    The cable screens must be joined with any cable screen continuing from the unit’s cable via a junction box. The primary earth for the anemometer must be provided via the base screws and not via the cable screens. View of the WindObserver 65 base connector variant Supplied Plug...
  • Page 44 Ultrasonic Anemometer Table 2 - 19-way connector and cable connections 19 Way Connector Cable Gland Option Signal Designation Terminal Letter Conductor Colour Pair 1 Green RS422 TXB (+) Pair 1 Black RS422 TXA (-) Pair 2 White RS422 RXB (+) Pair 2 Black RS422 (RXA (-)
  • Page 45 Ultrasonic Anemometer WindObserver 65 Default Set-up Default Settings The factory default settings are: Non - heated units A0 B3 C1 E1 F1 G0000 J1 K1 L1 M2 NA O1 P1 T1 U1 V1 X1 Y1 Z1 DR0 Plus RWASHORT 10 and RWALONG 60.
  • Page 46 Connecting to a PC with a RS422 or RS485 input The PC requires either an internal RS422 interface card, or an external RS422/485 to RS232 or USB converter, which will plug into the PC or host equipment. WindObserver 65 Converter, PC, or Logger...

  • Page 47: Appendix D - Networking

    • Unit must be set for half duplex mode (E2 setting) see Half Duplex Operation (page 48 ). • It must be configured to a tri-state polled mode or M4. See also Appendix F - Configuring WindObserver 65 Converter, PC, or Logger 19 Way...
  • Page 48 PC with a terminal package installed. Power must not be disconnected from the anemometer throughout this procedure. Configuring WindObserver 65 for Half Duplex Operation: Process: Connect both serial to USB adaptors to the PC and open a terminal connection for each one.

  • Page 49: Appendix E - Windobserver 65 Safe Mode

    WindObserver 65 and change configuration settings. Initial Set Up. The WindObserver 65 RS422 Pair 1 and Pair 2 TX and RX output connections (4 wires) are connected to a PC via an RS422 to RS232/USB Converter.

  • Page 50: Appendix F - Configuring

    The WindObserver 65 can be configured using Terminal emulator software such as HyperTerminal. Alternatively, it is possible to use Gill Wind Software as a Terminal program only (Wizard and Sync Comms not applicable). Wind will run on PC’s up to and including Windows 10 and can be downloaded from:- http://www.gillinstruments.com/main/software.html.
  • Page 51 Type * Enters Configuration Mode (from Continuous mode) Type *N Enters Configuration Mode (from Polled mode) Type D3 and press ENTER The WindObserver 65 responds with the current configuration settings. The factory default settings for a heated unit are: -...
  • Page 52 Ultrasonic Anemometer Configuration Settings Ax – N/A Bx - Baud Rate Setting Configuration code 2400 4800 9600 19200 38400 1200 To change the Baud rate when using HyperTerminal: - Eg. If set to B3 (9600 baud) and it is required to set to Baud rate to B2 (4800 baud). Type * to enter Configuration Mode.
  • Page 53 Ultrasonic Anemometer Dx- Diagnostic and Configuration Command (see Appendix L) (Bench Test) Each of these commands causes a response from the WindObserver 65. Command Item Typical response code *12400001 (where * = E (Unheated unit), F = (Heated unit) Type and serial No.
  • Page 54 Ultrasonic Anemometer Note: If changing to F2, using a terminal program then when in configuration mode Type F2 and press Enter, close the terminal program and open a new one with F2 Even parity settings, then type F and press Enter. Gx to Gxxxx - Averaging (Digital Outputs only) Setting Configuration code...
  • Page 55 Ultrasonic Anemometer Mx to Mxx - Message Format Output format Configuration code ASCII UV Continuous ASCII Polar Continuous ASCII UV Polled (tri-state) * ASCII Polar Polled (tri-state) * NMEA Continuous Binary Tunnel Continuous Binary UV Continuous Binary Polar Continuous ASCII Tunnel Continuous ASCII Tunnel Polled (tri-state) * ASCII Polar Polled Averaged ASCII Polar Continuous Averaged...
  • Page 56 Ultrasonic Anemometer Ox – ASCII Output Format (Output String Padding) Setting Configuration code Comma Separated Variable (CSV) Fixed Field Example data strings: - POLAR NMEA CSV data changing to error status code condition. CSV data changing to error status code condition. A,235,000.77,M,00,0A $IIMWV,191,R,000.55,M,A*19 A,,,M,04,24...
  • Page 57 Ultrasonic Anemometer Ux – Digital Output Units Units metres/sec knots miles / hour kilometre/hour feet / minute (knots) (MPH) (kph) (fpm) (m/s) Configuration code Vx- Vertical Output Padding Setting Configuration code Disable vertical output padding Enable vertical output padding Xx - 45° Alignment Offset/Inverted Operation Setting Configuration Notes...

  • Page 58: Appendix G - Windobserver 65 Ascii Data Output

    Ultrasonic Anemometer Appendix G - WindObserver 65 ASCII Data Output default data WindObserver 65 ASCII NODE, DIR, SPEED, PRESS, RH, TEMP, DEWPOINT, PRT, AN1, AN2, DIG1, VOLT, STATUS <STX>Q,121,000.06,M,+344.66,+21.76,00 <ETX>06 Where:- Start of String Node letter Wind direction 000.06 Wind speed Units +344.66...

  • Page 59: Appendix H - Windobserver 65 Nmea 0183 Data Output

    Ultrasonic Anemometer Appendix H - WindObserver 65 NMEA 0183 Data Output NMEA0183 WindObserver 65 When reporting in NMEA0183 format the following sentences will be used • MWV sentence to report wind direction and speed In each case *hh is a checksum, the 2 digit Hex Checksum sum figure is calculated from the Exclusive OR of the bytes between (and not including) the $ and * characters.

  • Page 60: Appendix I - Polled Mode Commands

    Ultrasonic Anemometer Appendix I - Polled Mode Commands ASCII Polled (UV and Polar) When in the Polled mode, an output is only generated when the host system sends a Poll signal to the WindObserver consisting of the WindObserver Unit Identifier – that is, the relevant letter A – Z. The output formats are otherwise as described above.

  • Page 61: Appendix J - Windview Software

    Appendix J - WindView Software Introduction Gill WindView Software can be downloaded from http://gillinstruments.com/main/software.html Gill Wind View will run on PC’s with Windows XP onwards operating systems. Connect to an Instrument using Gill WindView Software Open WindView Software. gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards)
  • Page 62 The default connection name is Anemometer 1, it can be re-named if required. Select the Output Format to match the Sensor format i.e. the WindObserver default format is Gill Polar (2 axis). If the WindObserver were set for UV or NMEA output then choose the appropriate format setting from the drop down menu.
  • Page 63 Ultrasonic Anemometer From the Port drop down menu select the PC COM Port to which the WindObserver is connected to e.g. COM 9. Select the Baud rate setting from the drop down menu to match that of the Windobserver, the WindObserver default baud rate is 9600 baud.
  • Page 64 Ultrasonic Anemometer WindSock Function Click on the WindSock button to give a Direction display and digital readout of Direction and Wind Speed:- On screen Maximum and Minimum readings of Wind speed and Directions are also displayed digitally and can be reset using the Reset Max/Min button.
  • Page 65 Ultrasonic Anemometer Click on Apply gives the following screen, click on OK:- To Start Logging. From the top menu select Log. Click on Log/Start to commence logging. To Stop Logging. From the top menu select Log. Click on Log/Stop to stop logging. The logged data is saved to a PC text file that can be opened with Notepad or equivalent and the following example illustrates the saved time/date stamped WindObserver data.

  • Page 66: Appendix K - Windobserver 65 Status Codes

    Appendix K - WindObserver 65 Status Codes WindObserver 65 is able to include a status code in each measurement string to confirm the reliability of the data or to highlight any potential issues. A list of the status code is provided below.

  • Page 67: Appendix L - Maintenance & Fault-Finding

    There are no moving parts or user-serviceable parts requiring routine maintenance. Opening the unit or breaking the security seal will void the warranty and the calibration. In the event of failure, prior to returning the unit to your authorised Gill distributor, it is recommended that: ...
  • Page 68 The ICC has been designed to be used in an indoor still air environment with an ambient temperature between 17°C and 23°C. When conducting the test it is important that the ICC is assembled on to the WindObserver 65 head and not touched or moved during the test.
  • Page 69 If there has been no significant changes to The WindObserver 65 head configuration then *PASS* will confirm correct operation. Alterations to the head geometry can result in a *FAIL* or ‘Insufficient Samples’ message. If this occurs please contact Gill Instruments.

  • Page 70: Appendix M - Glossary & Abbreviations

    Ultrasonic Anemometer Appendix M - Glossary & Abbreviations Item Meaning Calibration Carriage Return CRLF Carriage Return Line Feed Comma Separated Variable Engineering ESCape key on keyboard used to stop any process that is being executed End of string character Factory Feet per minute GrouND HEXadecimal...
  • Page 71 Ultrasonic Anemometer Item Meaning RS422 Communications standard RS485 Communications standard Request To Send Road Weather Averaging Receive Received Data SoftWare Speed Of Sound SECond Start of string character TERM TERMinal Transmit Transmitted Data Positive Negative With Respect To gillinstruments.com Issue: 8 (Applies to firmware 2387 6.09 onwards) Document number: 1390-PS-0039...

  • Page 72: Appendix N - Guarantee & Fcc

    Warranty is void if the green security seal covering base nuts is damaged or broken, or the transducer caps have been damaged. WindObserver 65 complies with part 15 of the RCC Rules. Operation is subject to the following two conditions:- This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.

  • Page 73: Appendix O - Principle Of Operation

    Appendix O - Principle of operation The WindObserver 65 measures the times taken for an ultrasonic pulse of sound to travel from the North transducer to the South transducer, and compares it with the time for a pulse to travel from S to N transducer. Likewise times are compared between West and East, and E and W transducer.
