- Page 1 DSR 9500A FTA, CI, EM VIA, VIA CI Instructions for use “REV 1.0” DIGITAL SATELLITE RECEIVER MF68-00247A...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS This STB has been manufactured to satisfy international safety standards. Please read the following recommended safety precautions carefully. MAINS SUPPLY AC 100-240V ~, 50/60Hz OVERLOADING Do not overload wall outlets, extension cords or adapters as this can result in fire or electrical shock. LIQUIDS Keep liquids away from the STB. -
Page 3: General Features
CONTENT GENERAL FEATURES Safety Instructions ........1 1. - Page 4 CONNECTING YOUR "DSR 9500A" CONNECTING YOUR "DSR 9500A" 1. LOCATION OF THE RECEIVER 7. INSERTING SMARTCARDS FOR VIACCESS SERVICES Your DSR 9500A should be placed under proper ventilation. In order to view a scrambled service, you need to have the appropriate Don’t put in completely enclosed cabinet that will restrict the flow of air, conditional Access Module and a valid Smartcard.
-
Page 5: Front Panel
DESCRIPTION DESCRIPTION Front Panel Rear Panel POWER DISH INPUT Pmax 40W 13/18V AC 100-240V ~, 50/60Hz 500mA max. Fuse:250V T2A (EXT) ANT.IN CAUTION 0/12V OUT DIGITAL S-VIDEO RS-232 50mA max. AUDIO OUT AUDIO RISK OF ELECTRIC SHODCK. DO NOT OPEN. (TV) AVIS RIQUE DE CHOC ÉLECTRIQUE... -
Page 6: Remote Control Unit
DESCRIPTION DESCRIPTION 5. MUTE This key is used to toggle between normal & muted audio. Remote Control Unit 6. FAV Use the key to switch between favorite lists. 7. EPG Electronic Program Guide button displays the TV/Radio Program guide. POWER TV/RADIO 8. -
Page 7: Basic Functions
BASIC FUNCTION BASIC FUNCTIONS 3. Select Soundtrack 1. Display Screen Before you can view the television program, you must perform the installation. Press Yellow ( ) key to see Therefore you will see only menu images at first. the soundtrack list. After the television channels have been programmed, you will see the following Press key to select one. - Page 8 BASIC FUNCTION BASIC FUNCTIONS 5.1 Service Favorites 6. Program Information Press the Green ( ) key on the control unit to select EPG-Electronic Program Guide the Favorites list. The electronic program guide gives you a channel list for the channels. Use the keys to select a favorite group that you want.
-
Page 9: Operating The Receiver
BASIC FUNCTION OPERATING THE RECEIVER 8. Teletext OSD Main Menu When the current broadcasting program provides After installing your antenna system and DSR 9500A with appropriate connectors. Teletext OSD, press the Green ( ) key twice to see the current Teletext OSD list. Plug in the AC main power and switch on the receiver. -
Page 10: Lnb Setting
OPERATING THE RECEIVER OPERATING THE RECEIVER 1.1 LNB Setting Select from Menu Mode: "User" mode : Enables control of basic positioner function You can select the satellite and LNB setting conditions recommended for beginners. General user uses “User” mode. to execute channel search and you can alter the settings "Installer"... -
Page 11: Auto Scanning
OPERATING THE RECEIVER OPERATING THE RECEIVER 1.2.2 Installer Mode 1.4 Auto Scanning After checking the positioner’s state, installer should use The sub menu “Auto Scanning” will enable download this menu. He should set the “Disable Limits” before the channels automatically from the preprogrammed satellites. using User mode. -
Page 12: Channel Organising
OPERATING THE RECEIVER OPERATING THE RECEIVER Select the FEC(Forward Error Correction)of the transponder 2. Channel Organising you want to find. You can select the value of 1/2, 2/3, 3/4, 5/6, 7/8 or Auto. The "Channel Organising" menu has seven Select the polarization of the transponder you want to find. functions: (Horizontal/Vertical/Circular Left/Circular Right) The "Channel Organising"... -
Page 13: Delete All Channel
OPERATING THE RECEIVER OPERATING THE RECEIVER 2.3 Delete Channel 2.7 Move & Edit Channel Select the desired channel you want to delete by pressing Red ( ) key. Select the desired list with keys. Press key for confirmation. Select channel by pressing Red ( ) key. -
Page 14: Parental Lock
OPERATING THE RECEIVER OPERATING THE RECEIVER 3. Parental Lock 3.2. Change PIN Code To change the PIN code, select the second option "Change PIN Code". This "Parental Lock" feature sets viewing restrictions and prevents unauthorized access to your DSR 9500A This will take you to the following menu: through the PIN (Personal Identification Number), In this option, you need to enter the current PIN... -
Page 15: System Setup
OPERATING THE RECEIVER OPERATING THE RECEIVER 4. System Setup 4.3 Media Settings You can set the various media settings you want. This option enables you to change the factory Place the cursor on this sub menu and press preset system settings as per your requirements. Select the TV system : PAL, SECAM. -
Page 16: Common Interface
2. Change Parental Rating: 4.8 Copy Channel Data (Only for DSR 9500A CI, DSR 9500A FTA) Change the setting for the family filter, if necessary. If you want to copy the channel data from one receiver to another, please follow the instruction below. -
Page 17: Troubleshooting
TROUBLESHOOTING TECHNICAL SPECIFICATIONS 1. User section Problem Possible cause Solution of the problem 4000 programmable channels, 7 segment LED display, software download via satellite & PC, auto and manual scan facility, No display LED on Power cord Power cord plug in correctly advanced Electronic Program Guide, channel organizing (programmable), the front panel;... - Page 18 TECHNICAL SPECIFICATIONS Video decoder Serial data interface System decoding: MPEG 2 ISO/TEC 13818 Standard: RS232C, Max. 115.2 kB (transport stream) Connector type: 9 pin D-type female Profile and level: MPEG 2 MP@ML (4:2:2) Data rate: 1~ 15 Mb/s Embedded descrambler Video formats: 4:3 (normal) &...
