Town & Country Fires BRANSDALE SC ECO Installation And User Instructions Manual

Hide thumbs

Advertisement

Table of Contents

BRANSDALE SC ECO
MULTI-FUEL STOVE
INSTALLATION AND USER INSTRUCTIONS
Read these instructions carefully before installation and use.
These instructions should be retained by the user for future reference.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRANSDALE SC ECO and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fires BRANSDALE SC ECO

Summary of Contents for Town & Country Fires BRANSDALE SC ECO

  • Page 1 BRANSDALE SC ECO MULTI-FUEL STOVE INSTALLATION AND USER INSTRUCTIONS Read these instructions carefully before installation and use. These instructions should be retained by the user for future reference.
  • Page 2 The Bransdale SC ECO stove has a nominal heat output of 8kW and a weight of 100 kg. The flue gas mass flow is 5.4g/s for mineral fuel and 6.7g/s for wood logs. The mean flue gas temperature directly downstream of the flue spigot at nominal heat output is 316 degrees C (wood) 342 degrees C (solid fuel).
  • Page 3 The Clean Air Act 1993 and Smoke Control Areas Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed boiler if located in a designated smoke control area.

  • Page 4: Unpack The Stove

    CLEARANCES If the Bransdale SC ECO needs to be sited next to and on a non-combustible surface. A recommended minimum clearance of 150mm at the sides, and at least 300mm above and 50mm from the back of the stove body will allow air circulation and not impede the performance of the stove.

  • Page 5: Lighting The Stove

    and must be installed to manufacturers’ instructions and to relevant Building Regulations. The length of the chimney or flue must be at least 4.5 meters from the top of the stove, and must finish in a down draught free area. A stove must not be installed into a room where there is an extractor fan, or fumes could be pulled down the chimney.
  • Page 6 TURBO BURNER There is a Turbo Burner which brings air in allowing plenty of oxygen into the rear and top of the stove, thus burning off gases which normally do not ignite. This gives the stove more efficiency and better combustion, less pollution. The turbo burner is built in and needs no adjustment.
  • Page 7 TO RE-FUEL THE STOVE Open all air vents and then open the stove door gently, using the stove gloves. Put more logs or solid fuel on the stove and close the door. Do not over fill the firebox, maximum filling height 100mm. Allow the fire to burn through before closing the bottom spin wheels and then close the top spin wheels as much as required.

  • Page 8: Troubleshooting

    may be used if required. The body of the stove can be brushed with a soft brush, do not use water on the paint work. If, in time, the body of the stove needs touching up, a touch-up aerosol of paint, the same as originally used in the factory, can be obtained from you supplier.

  • Page 9: Warning Note

    WARNING NOTE Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes from de-ashing and re-fuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, then the following immediate action should be taken:- (a) Open doors and windows to ventilate the room and then leave the premises.
  • Page 10 Commission Delegated Regulation (EU) 2015/1187 Energy Labelling of Local Space Heaters Town & Country Fires Supplier`s Name or Trademark: Bransdale SC ECO Suppliers Model Identifier: Energy Efficiency Class of Model: Nominal Heat Output to Room (kW): Nominal Heat Output to Water (kW): 77.1%...
  • Page 11 DECLARATION OF PERFORMANCE According to Regulation (EU) 305/2011 Ref No. BRANSDALE SMOKE CONTROL ECO Point No. Product Type Bransdale S/C ECO Freestanding room heater burning wood without hot water supply Model Bransdale S/C ECO Freestanding, Serial No.BRAECO…________ Intended use Room heater burning wood without hot water supply for intermittent use Manufactured By Town and Country Fires Ltd...
  • Page 14 The Town and Country Fires Guarantee Town and Country Fires Ltd guarantee the quality of workmanship of their multi fuel stoves for twelve months from the date of purchase. Stoves must be installed to current Building Regulations, National and European Standards and per our Installation / User instructions supplied with the stove.
