ROSEDALE SMOKE CONTROL STOVE
INSTALLATION AND USER INSTRUCTIONS
Read these instructions carefully before installation and use.
These instructions should be retained by the user for future reference.
The Rosedale SC stove has a nominal heat output of 7.5kW. and a weight of 90 kg. The
flue gas mass flow is 5.8 g/s for mineral fuel and 5.4 g/s for wood logs. The mean flue gas
temperature directly downstream of the flue spigot at nominal heat output is 338
degrees C.
The Rosedale SC has been approved by Hetas Ltd. as a closed appliance and
is capable of intermittent operation.
CO Alarms:-Building regulations require that whenever a new or replacement fixed solid
fuel or wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be
fitted in the same room as the appliance. Further guidance on the installation of the carbon
monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer's
instructions.
Provision of an alarm must not be considered a substitute for either installing the appliance
correctly or ensuring regular servicing and maintenance of the appliance and chimney
system.
WARNING
The stove must be installed to comply with Health and Safety at Work Act 1974to British
Standard BS 8303 and to all local Building Regulations, including those referring to
National and European standards. These need to be complied with when installing the
appliance.
Ensure that the flue pipe diameter is not less than the 150mm diameter outlet on the
appliance.
There must not be an extractor fan fitted in the same room as the Rosedale SC.
If there is a possibility of disturbing asbestos during the installation it is necessary to take
the appropriate steps to protect the installer. Fire cement is caustic and protective gloves
should be worn.
The chimney must be swept and examined for soundness and suitability before the stove is
installed. Remedial action should be taken if required, seeking expert advice if necessary.
Where the chimney is believed to have previously served an open fire installation, it is
possible that the higher flue gas temperature from a closed appliance may loosen deposits
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rosedale and is the answer not in the manual?

Questions and answers

Summary of Contents for Town & Country Fires Rosedale

  • Page 1 These instructions should be retained by the user for future reference. The Rosedale SC stove has a nominal heat output of 7.5kW. and a weight of 90 kg. The flue gas mass flow is 5.8 g/s for mineral fuel and 5.4 g/s for wood logs. The mean flue gas temperature directly downstream of the flue spigot at nominal heat output is 338 degrees C.
  • Page 2: Unpack The Stove

    (e.g. load distributing plate) shall be taken to achieve it. As referred to in document J in the Building Regulations, the Rosedale SC requires 1375 sq mm of fixed ventilation (this equals ventilation of approximately 37mm x 37mm - see above example).
  • Page 3: Lighting The Stove

    (see figure 1). A flat-bladed screw driver and 8mm spanner will be required. The Rosedale SC requires a Class 1 chimney of it’s own, a shared chimney will not be suitable. The chimney must be sound, free from leaks and swept before installation. If the chimney requires lining, a lining must be used which is suitable for wood and solid fuel, with a minimum of 150mm internal diameter.
  • Page 4: Air Controls

    When these are burning well the primary air slider (on the front of the stove) can be closed leaving the secondary air spin wheels fully open. Once a good bed of glowing embers has formed a normal load of approximately 2 to 3 kgs of wood logs can be added. A stove handle cover is included with the stove –...
  • Page 5 20% moisture content, maximum log length up to 380mm. The Rosedale SC stove is only exempt for use in a smoke control area if it is burning clean, dry, (no more than 20% moisture) and seasoned logs of maximum length 380mm. No fuel that contains halogenated organic compounds or heavy metals as a result of treatment with wood preservatives or coatings must be burnt in the appliance.
  • Page 6: Troubleshooting

    This appliance should be regularly maintained by a competent service engineer. There must be no unauthorised modification of the appliance. Any replacement parts must be recommended by the Manufacturer. If the stove is to be left unused for a prolonged period of time then it should be given a thorough clean to remove ash and unburned fuel residues.
  • Page 7 WARNING NOTE Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes from de-ashing and re-fuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, then the following immediate action should be taken:- (a) Open doors and windows to ventilate the room and then leave the premises.
  • Page 8 Commission Delegated Regulation (EU) 2015/1187 Energy Labelling of Local Space Heaters Town & Country Fires Supplier`s Name or Trademark: Rosedale / Rosedale SC Suppliers Model Identifier: Energy Efficiency Class of Model: Nominal Heat Output to Room (kW): Nominal Heat Output to Water (kW): 77.4...
  • Page 12 The Town and Country Fires Guarantee Town and Country Fires Ltd guarantee the quality of workmanship of their multi fuel stoves for twelve months from the date of purchase. Stoves must be installed to current Building Regulations, National and European Standards and per our Installation / User instructions supplied with the stove.
