LITTLE THURLOW MULTI-FUEL STOVE
INSTALLATION AND USER INSTRUCTIONS
Read these instructions carefully before installation and use.
These instructions should be retained by the user for future reference.
The Little Thurlow stove has a nominal heat output of 5KW and a weight of 61 kg. The flue
gas mass flow is 4.5g/s for mineral fuel and 3.7 g/s for wood logs. The mean flue gas
temperature directly downstream of the flue spigot at nominal heat output is 294 degrees C.
The stove is designed as a closed appliance and is capable of intermittent operation.
The stove must be installed to comply with Health and Safety at Work Act 1974, and to all
local Building Regulations, including those referring to National and European standards.
These need to be complied with when installing the appliance.
CO Alarms:-Building regulations require that whenever a new or replacement fixed solid
fuel or wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be
fitted in the same room as the appliance. Further guidance on the installation of the carbon
monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer's
instructions.
Provision of an alarm must not be considered a substitute for either installing the appliance
correctly or ensuring regular servicing and maintenance of the appliance and chimney
system.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Little Thurlow and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fires Little Thurlow

Summary of Contents for Town & Country Fires Little Thurlow

  • Page 1 These instructions should be retained by the user for future reference. The Little Thurlow stove has a nominal heat output of 5KW and a weight of 61 kg. The flue gas mass flow is 4.5g/s for mineral fuel and 3.7 g/s for wood logs. The mean flue gas temperature directly downstream of the flue spigot at nominal heat output is 294 degrees C.

  • Page 2: Unpack The Stove

    Remove the bag inside the ashpan, this contains the operating tool, instructions, and a pair of stove gloves. The Little Thurlow is supplied with a rear brick support – this is assembled in the stove during production. Occasionally it can slip forward into the ashpan during delivery/ installation.

  • Page 3: Installation

    J of the Building Regulations, no purpose provided ventilation is required for the Little Thurlow stove. It is important that any inlet grilles are so positioned that they are not liable to blockage. It is essential that the stove has adequate air supply for combustion and ventilation.

  • Page 4: Lighting The Stove

    LIGHTING THE STOVE When ready to light the stove for the first time, make sure that everything is removed from the ashpan, and open the spin wheels at the bottom and top of the stove to let air in under the grate.
  • Page 5 TURBO BURNER There is a turbo burner which brings in air (not pre-heated) ,allowing plenty of oxygen into the rear and top of the stove, thus burning off gases which normally do not ignite. This gives the stove more efficiency and better combustion, less pollution. The vent for the Turbo Burner is positioned on the left hand side of the stove, near the back.

  • Page 6: Troubleshooting

    CLEANING THE STOVE AND FLUE The riddling knob to shake the ashes through is on the front of the stove, left hand side near the bottom corner of the door. Using the tool, or a stove glove, pull the lever in and out to rotate the grate and shake the ashes into the ashpan.

  • Page 7: Warning Note

    maintain a high burning temperature, so try a solid fuel that burns at a lower temperature. There may not be the required flue draught in the chimney/flue. In this case a longer chimney pot may help, or there may be a blockage in the flue. 2.
  • Page 8 Commission Delegated Regulation (EU) 2015/1187 Energy Labelling of Local Space Heaters Town & Country Fires Supplier`s Name or Trademark: Suppliers Model Identifier: Little Thurlow/Little Thurlow SC Energy Efficiency Class of Model: Nominal Heat Output to Room (kW): Nominal Heat Output to Water (kW): 78.9...
  • Page 12 The Town and Country Fires Guarantee Town and Country Fires Ltd guarantee the quality of workmanship of their multi fuel stoves for twelve months from the date of purchase. Stoves must be installed to current Building Regulations, National and European Standards and per our Installation / User instructions supplied with the stove.
