LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015
LANGDALE SMOKE CONTROL
MULTI-FUEL STOVE
INSTALLATION AND USER INSTRUCTIONS
Read these instructions carefully before installation and use.
These instructions should be retained by the user for future reference.
The Langdale Smoke Control stove has a nominal heat output of 7.96kW (wood),
8.09kW(solid fuel) and a weight of 92 kg. The flue gas mass flow is 5.1 g/s for mineral fuel
and 7.31 g/s for wood logs. The mean flue gas temperature directly downstream of the flue
spigot at nominal heat output is 238.97 degrees C (wood), 283.80 degrees C (solid fuel).
The Langdale Smoke Control has been tested as a closed appliance and is capable of
intermittent operation.
CO Alarms:-Building regulations require that whenever a new or replacement fixed solid
fuel or wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be
fitted in the same room as the appliance. Further guidance on the installation of the carbon
monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer's
instructions.
Provision of an alarm must not be considered a substitute for either installing the appliance
correctly or ensuring regular servicing and maintenance of the appliance and chimney
system.
WARNING
The stove must be installed to comply with Health and Safety at Work Act 1974 to British
Standard BS 8303 and to all local Building Regulations, including those referring to
National and European standards. These need to be complied with when installing the
appliance. Ensure that the flue pipe diameter is not less than the 150mm diameter outlet on
the appliance.
There must not be an extractor fan fitted in the same room as the Langdale Smoke Control.
If there is a possibility of disturbing asbestos during the installation it is necessary to take
the appropriate steps to protect the installer.
Fire cement is caustic and protective gloves should be worn.
Advertisement
Related Manuals for Town & Country Fires LANGDALE SMOKE CONTROL
Summary of Contents for Town & Country Fires LANGDALE SMOKE CONTROL
- Page 1 Ensure that the flue pipe diameter is not less than the 150mm diameter outlet on the appliance. There must not be an extractor fan fitted in the same room as the Langdale Smoke Control. If there is a possibility of disturbing asbestos during the installation it is necessary to take the appropriate steps to protect the installer.
- Page 2 Order made and signed by the Secretary of State or Minister in the devolved administrations. The Langdale Smoke Control have been recommended as suitable for use in smoke control areas when burning dry seasoned wood logs and approved smokeless fuels.
-
Page 3: Unpack The Stove
LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 UNPACK THE STOVE Carefully cut the straps and lift the box up over the top of the stove. Remove the packing from round the outside of the stove, leaving the plastic cover on if building work is still in progress it is important to protect the paint finish from any damage, water, dust or fire cement. - Page 4 LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 The Langdale Smoke Control requires a Class 1 chimney of its own, a shared chimney will not be suitable. The chimney must be sound, free from leaks and swept before installation. If the chimney requires lining, a lining must be used which is suitable for wood and solid fuel, with a minimum of 150mm internal diameter.
-
Page 5: Lighting The Stove
LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 Place the 9v battery into the handset. To open the air vent press the smallest button on the handset at the same time as the button next to the arrow pointing upwards. To close the air vent, just press the button next to the arrow pointing downwards. - Page 6 LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 lit for a while, the chimney should be checked for blockages before lighting. When ready to light the stove, put a small piece of fire lighter, about 25mm square is big enough, and then add small sticks, taking care not to smother the flames. When the sticks are well alight add small logs, gradually increasing the size.
- Page 7 If the Remote Control option is installed on your stove – the remote controls the secondry air intake on the Langdale Smoke Control and is operated by 4 x AA batteries in the control box and a 9V battery in the handset (batteries included).
-
Page 8: Troubleshooting
LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 CLEANING THE STOVE AND FLUE It is important to remove the ashes regularly, if the ash builds up through the grate, the grate could overheat and distort. Open the fire door with the stove glove provided and, using the tool, gently pull out the ashpan a little way. - Page 9 LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 maintain a high burning temperature, so try a solid fuel that burns at a lower temperature. There may not be the required flue draught in the chimney/flue. In this case a longer chimney pot may help, or there may be a blockage in the flue.
- Page 10 LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 The most common cause of fume emission is flueway or chimney blockage. For your own safety these must be kept clean at all times. COMMISSIONING AND HANDOVER INSTRUCTIONS Ensure all parts are fitted in accordance with the instructions.
- Page 11 LANGDALE SMOKE CONTROL ISSUE 1 07/07/2015 The Town and Country Fires Guarantee Town and Country Fires Ltd guarantee the quality of workmanship of their multi fuel stoves for twelve months from the date of purchase. Stoves must be installed to current Building Regulations National and European Standards and per our Installation / User instructions supplied with the stove.
