Mimer X-Link Connection Manual

Connect an icom ic-a110 or ic-a120

Advertisement

Quick Links

Page 1/3
Connect an Icom IC-A110 or
IC-A120 to Mimer X-Link
Interface Power Supply
+12VDC / max 0,3A.
See wiring diagram on following pages.
Radio setup
No special programming is needed in the radio
A110: The volume control shall normally be set for "five clicks down"
from max.
A120: The volume control knob shall normally be set for 50%
volume. This is when the knob points straight up (12 o´clock).
Please note that the audio output from the radio in some cases
needs to be even lower when you patch to a radio with a very
sensitive microphone input.
You always need to test and listen so that the audio is at the same
level as between radio-radio and that it is not distorted.
Radio connection
The cable kit is connected through both the microphone connector and
the external speaker connector.
A110/A120 B
www.lse.se
REE

Advertisement

loading
Need help?

Need help?

Do you have a question about the X-Link and is the answer not in the manual?

Questions and answers

Summary of Contents for Mimer X-Link

  • Page 1 Page 1/3 Connect an Icom IC-A110 or IC-A120 to Mimer X-Link Interface Power Supply +12VDC / max 0,3A. See wiring diagram on following pages. Radio setup No special programming is needed in the radio A110: The volume control shall normally be set for “five clicks down”...
  • Page 2 • Radio with AF level sense for Rx detect Part of the Configuration software window See the X-Link setup manual for details on how to set the detect level and the audio level. Check/adjust the audio levels in both directions in the interface so that the users hears the X-Link with the same level as when listening to other radios.
  • Page 3 Page 3/3 Connection Cable: Select the proper configuration below depending on if your radio will be connected as Radio A or Radio B to the X-Link interface. A110/A120 B www.lse.se...
