Page 1/4
Connect a Jotron TR7750 to Mimer X-Link
Interface Power Supply
+12VDC / max 0,3A.
See wiring diagram on the following page.
Radio setup
The interface is pre-set for the following radio default settings:
• Rx Config/Audio/Line Output Level/0.0dBm
• Rx Config/Squelch/RxBusyOutput: Closed when busy (default)
• Tx Config/Audio/Input Source/Auto
• Tx Config/Audio/Line Sensitivity/-10dBm
• Tx Config/Keying/Source/Txgnd
See screen shots on following pages.
The radio is connected through one RJ45 to the Tx: REM port.
Jotron TR7750 A
www.lse.se
REE
Advertisement
Table of Contents
Related Manuals for Mimer X-Link
Summary of Contents for Mimer X-Link
- Page 1 Page 1/4 Connect a Jotron TR7750 to Mimer X-Link Interface Power Supply +12VDC / max 0,3A. See wiring diagram on the following page. Radio setup The interface is pre-set for the following radio default settings: • Rx Config/Audio/Line Output Level/0.0dBm •...
- Page 2 Part of the Configuration software window Check/adjust the audio levels in both directions in the interface so that the users hears the X-Link with the same level as when listening to other radios. See the X-Link setup manual for details on setting the audio level.
- Page 3 Page 3/4 Radio Settings Screen shots Select Mic, TxKey and Txgnd. Unselect Line. Jotron TR7750 A www.lse.se...
- Page 4 Page 4/4 Connection Cable: Select the proper configuration below depending on if your radio will be connected as Radio A or Radio B to the X-Link interface. Jotron TR7750 A www.lse.se...
