Mimer X-Link Quick Start Manual

Connect kirisun m50

Advertisement

Quick Links

Page 1/3
Connect Kirisun M50 to
Mimer X-Link
Interface Power Supply
+12VDC / max 0,3A.
See wiring diagram on following pages.
Programming Kirisun M50
No special programming is needed in the radio.
The radio is connected through both the front microphone
connector and the on-top speaker connector.
Volume setting
The volume of the M50 shall be set to "half" volume.
Cable kit X-Link to Kirisun and connections to the radio
