GGM gastro KSNEOZ User Manual

Potato chipper electrical - industrial type

Advertisement

Quick Links

POTATO CHIPPER
(ELECTRICAL – INDUSTRIAL TYPE)
AUTHORIZED DEALER
SERVICE STICKER WILL
BE ATTACHED HERE.
PRODUCTION YEAR:
MANUFACTURER
•PRODUCTION SITE : GGM Gastro International GmbH Weinerpark 16
Our website: www.ggmgastro.com
Published on
: GGM Gastro International GmbH .
Tel: +49 (0) 2553 / 7220 0
: 05.05.2023
USER'S MANUAL
48607 Ochtrup
Fax: +49 (0) 2553 / 7220 200
e-mail: technik@ggmgastro.com
MODEL: KSNEOZ
SERIAL NO :
1/25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KSNEOZ and is the answer not in the manual?

Questions and answers

Summary of Contents for GGM gastro KSNEOZ

  • Page 1 PRODUCTION YEAR: SERIAL NO : MANUFACTURER : GGM Gastro International GmbH . •PRODUCTION SITE : GGM Gastro International GmbH Weinerpark 16 48607 Ochtrup Tel: +49 (0) 2553 / 7220 0 Fax: +49 (0) 2553 / 7220 200 Our website: www.ggmgastro.com e-mail: technik@ggmgastro.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE NR. TOPICS COVER PAGE TABLE OF CONTENTS INTRODUCTION TECHNICAL DATA ELECTRICAL CIRCUIT DIAGRAM, CONTROL BOARDS MAIN DIMENSIONS WARNING SIGNS SAFETY DETAILS TRANSPORTING AND MOVING 10-19 INSTALLATION OF THE APPLIANCES 20-21 OPERATION OF THE APPLIANCES CLEAN-UP AND MAINTENANCE 23-24 TROUBLE SHOOTING TERMS OF WARRANTY...
  • Page 3: Introduction

    INTRODUCTION Dear User, Thank you for purchasing our appliance and for your reliance upon our company. Our appliances are used in professional kitchens in 100 countries. Our appliances are produced in compliance with international standards. Important notice: Please read and ensure that the users read this user’s manual in order to achieve the desired performance in line with your expectations and to use your appliance for long years.
  • Page 4: Technical Data

    TECHNICAL DATA ☞ KSNEOZ YOUR PRODUCT'S TYPE Potato Chipper 0840.16010.10 PRODUCT CODE 420x660x MAIN DIMENSIONS (mm) 1010 / 930 / 860 0,37 TOTAL ELECTRICAL INPUT (kW) 220 V POWER SUPPLY VOLTAGE WORKING FREQUENCY (Hz) 3x2,5 SUPPLY CABLE Code Comment 2840.16010.03 Blade Group -1 ( 8mm x 8mm) 2840.16010.04...
  • Page 5 ELECTRICAL CIRCUIT DIAGRAM CODE COMPONENTS Upper part switch Blade Switch Stop Stop Button Start Start Button Contactor Main Fuse Motor CONTROL BOARDS Start Button Stop Button 5/25...
  • Page 6: Main Dimensions

    MAIN DIMENSIONS Note: Machine height can adjust in 3 different value by its design. 6/25...
  • Page 7: Warning Signs

    WARNING SIGNS POWER NETWORK GROUNDING GROUNDING POWER POWER SUPPLY CONNECTIONS 220-240 V NPE / 500 Hz VOLTAGE : 220-240 V SUPPLY CONNECTION: 1 PHASE 7/25...
  • Page 8: Safety Details

    SAFETY DETAILS ☞ Do not clean up the device with pressure water ☞ This device should be installed in line with effective regulations and only be operated in well ventilated places. Please refer to the instructions before installing and operating the device. ☞...
  • Page 9: Transporting And Moving

    TRANSPORTING AND MOVING CHANGING THE LOCATION; Machines installed by an authorized service CANNOT BE MOVED ELSEWHERE, ITS POWER SUPPLY CABLES CANNOT BE EXTENDED OR REPLACED except by an authorized service. ☞ Disconnect from power supply before moving ☞ The vehicle can be moved with supplementary vehicle. ☞...
  • Page 10: Installation Of The Appliances

    INSTALLATION OF THE APPLIANCES All of the items mentioned below in connection with the installation of the applıance should be carried out by authorized service personnel. ☞ Feet of the device should be adjustable and the device should be ensured to operate in a leveled position. ☞...
  • Page 11 INSTALLATION OF THE APPLIANCES Installation of the device should be carried out by authorized service personnel. ☞ Feeding Hopper can be deattached by means of hinge mechanism ☞ Deattachable potatoes pusher disc ☞ Feeding Hopper can be ☞ openeded by means of Deattachable blade group locking mechanism 11/25...
  • Page 12 INSTALLATION OF THE APPLIANCE Installation of the device should be carried out by authorized service personnel. ☞ After connecting the cable ends to the main supply, disc rotating way must be checked. ☞ Potato pusher disc must rotate at ccw. 13/25...
  • Page 13 INSTALLATION OF THE APPLIANCES L (mm) S (mm) S (mm) Potato chipper machine capacity depends on cutter drum size which is a main part. Peeled potato sizes should not be bigger than L:120-130mm and S:80mm. Otherwise, big sized potatoes may not be cut by the blades. L (mm) : Max.
  • Page 14 INSTALLATION OF THE APPLIANCES ☞ Some potatoes can remain between blades in case there is no enough potatoes in the aluminium pusher disc drum to push them towards to blade block group. ☞ Feeding hopper should be opened, blade block group should be removed and cleaned carefully.
  • Page 15 INSTALLATION OF THE APPLIANCES • Remove Blade Block Group: [ 1 ] - Loose the screw [ 3 ] – Loose the [ 2 ] – Open the feeding screws and hopper remove the blade block group out. • Remove Pusher Disc Drum: ☞...
  • Page 16 INSTALLATION OF THE APPLIANCES • Remove Feeding Hopper: [ 1 ] – Open the [ 2 ] – Slide the pin of feeding hopper feeding hopper and take the feeding hopper out to upwards carefully. By this way, feeding hopper and main body can be separated from each others easily.
  • Page 17 INSTALLATION OF THE APPLIANCES • Adjusting the feet: [ 1 ] – Remove the [ 2 ] – Remove the feeding hopper Blade Block Group [ 3 ] – Remove the Pusher Disc Drum 18/25...
  • Page 18 INSTALLATION OF THE APPLIANCES • Adjusting the feet(cont.): [ 4 ] – Loose and remove the screws on the feet [ 5 ] – Tilt the machine body according to height what you need and tight the screw on the feet according to your adjust.
  • Page 19 OPERATION OF THE APPLIANCE 1. Potato Chipper machine is used for cutting of potatoes in order to prepare french fries. 2. After placing the machine to the operation area with its package, and then open its package. 3. Before first use, machine should be cleaned thoroughly together with its outer surface and internal boiler with a liquid cleaning material and rinsed with plenty of water.
  • Page 20: Operation Of The Appliances

    OPERATION OF THE APPLIANCES CAUTION! : The appliances should be installed and operated as described in this user’s manual. If any failure is encountered please contact our nearest authorized service dealer. WHEN THE APPLIANCES HAS A FAILURE ONLY AUTHORIZED …………………… SERVICE DEALERS ARE ALLOWED TO HANDLE THE APPLIANCES.
  • Page 21: Clean-Up And Maintenance

    CLEAN-UP AND MAINTENANCE 1. CLEAN-UP: Turn the device off after daily use. Wipe the outer surface of the mixing apparatus and container with a sponge and liquid detergent. Top hood may be opened, to remove the peeler disc and to discharge rests left inside the vessel with help of water.
  • Page 22: Trouble Shooting

    TROUBLE SHOOTING Trouble Probable Cause Corrective Action Check the main fuse and Main fuse may be blown switch on it and ensure electricity on. Turn off the machine by pressing the stop button. Open Aluminium pusher disc drum the feeding hopper and solve may be stucked.
  • Page 23 TROUBLE SHOOTING Trouble Probable Cause Corrective Action It is normal. Throw more There may no enough potatoes into the feeding Last potato remains between blades potatoes in the hopper. aluminium pusher disc drum to push them towards to blade block group.
  • Page 24: Terms Of Warranty

    TERMS OF WARRANTY 1- Documents without sales date, factory and sales company approval on, are not valid. In order to benefit from the warranty, warranty document should be presented. 2- If the appliance is installed and operated following the instructions in the installation, maintenance and user's manual, it is warranted for failures sourcing from materials and workmanship .
