WoMaster WR302G User Manual

Command line interface industrial secure cellular router (serial server)
Hide thumbs Also See for WR302G:
Table of Contents

Advertisement

Quick Links

Download this manual

COVER

Command Line Interface
WR302G/WR312G/WR322GR
Industrial Secure Cellular Router (Serial Server)
Aug.29.2018 V.1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WR302G and is the answer not in the manual?

Questions and answers

Related Manuals for WoMaster WR302G

Summary of Contents for WoMaster WR302G

  • Page 1: Cover

    COVER Command Line Interface WR302G/WR312G/WR322GR Industrial Secure Cellular Router (Serial Server) Aug.29.2018 V.1...
  • Page 2 Disclaimer WoMaster reserves the right to make changes to this Manual or to the product hardware at any time without notice. Information provided here is intended to be accurate and reliable. However, it might not cover all details and variations in the equipment and does not claim to provide for every possible contingency met in the process of installation, operation, or maintenance.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS COVER ..................................1 TABLE OF CONTENTS ............................. 3 COMMAND LINE INTERFACE (CLI) INTRODUCTION ................4 UNDERSTANDING ALL COMMANDS ......................6 CLI COMMANDS ............................8 3.1 CLI COMMANDS FOR SHOW ....................8 3.2 CLI COMMANDS FOR SET ..................... 19 3.3 CLI COMMANDS FOR BACKUP RESTORE ................

  • Page 4: Command Line Interface (Cli) Introduction

    WoMaster managed switch supports Telnet console. User can connect to the switch by Telnet and the command lines are the same as what user sees by RS232 console port. Below are the steps to open Telnet connection to the switch.
  • Page 5 In the Session configuration, choose the Serial protocol then enter the Serial line and Speed. For the serial line, please check the device manager to make sure the serial line name. The speed should be 115200. Then click on Open to start the SSH session console. 2.

  • Page 6: Understanding All Commands

    2. UNDERSTANDING ALL COMMANDS There are some different command modes which are show, set and list. Each command mode has its own access ability, available command lines and uses different command lines to enter and exit. Privileged EXEC Mode: As long as user login the router by CLI. User can show some basic information, set some configuration and list all of the command line lists.
  • Page 7 SWITCH(config)# password Alert message when multiple users want to configure the switch. If the administrator is in configuration mode, then the Web users can’t change the settings. Womaster router allows only one administrator to configure the router at a time.

  • Page 8: Cli Commands

    3. CLI COMMANDS This chapter will show the main CLI Command for Show, Set, List and some other main CLI Commands. The Show commands are used to display device settings, statistics and other information, The Set commands are used to do the configuration and for the List command to show all of the command lists that available in the telnet mode.
  • Page 9 started. 9 2018-08-28 00:18:17 syslog br0 ip is 192.168.10.1 10 2018-08-28 00:18:17 syslog dns1 is 8.8.8.8 11 2018-08-28 00:18:17 system TZ: GMT0 12 2018-08-28 00:18:18 wifi :service stopped. 13 2018-08-28 00:18:18 cellular Repower Cellular Module 14 2018-08-28 00:18:21 cellular Cellular watchdog start.
  • Page 10 interface serial1 idle_timeout interface serial1 alive_check interface serial1 term_resistor : Disable interface serial1 tty2net_delimiter0 : interface serial1 tty2net_delimiter1 : interface serial1 tty2net_delimiter2 : interface serial1 tty2net_delimiter3 : interface serial1 tty2net fush time(ms): 0 interface serial1 net2tty_delimiter0 : interface serial1 net2tty_delimiter1 : interface serial1 net2tty_delimiter2 : interface serial1 net2tty_delimiter3 : interface serial1 net2tty fush time(ms): 0...
  • Page 11 interface serial2 force TX interval time(ms): 0 interface serial2 force TX length(bytes): 1024 interface cellular1 sim current index : 2 interface cellular1 provider : NONE interface cellular1 service-type : No Service interface cellular1 imei : 000000000000000 interface cellular1 signal : 0 dBm interface cellular1 sim-status: SIM not inserted interface cellular1 status : Disconnected...
  • Page 12 interface wlan1 802.11mode : 802.11G/N interface wlan1 HTprotect : Disable interface wlan1 Currentfrequency/channel: Auto interface wlan1 Noise Floor : -256 dBm interface wlan1 power : Half interface wlan1 rate : Auto interface wlan1 antenna number : Two Antenna interface wlan1 wmm : Enable interface wlan1 Isolation : Disable...
  • Page 13 interface wlan1 radius port : 1812 interface wlan1 vap profile1 active : Enable interface wlan1 vap profile1 profileName: Profile1 interface wlan1 vap profile1 ssid : WR322_1 interface wlan1 vap profile1 ssidhided: Disable interface wlan1 vap profile1 vlanID interface wlan1 vap profile1 Isolation: Disable interface wlan1 vap profile1 wmm : Enable interface wlan1 vap profile1 MaxStaNum: 64...
  • Page 14 interface wlan1 vap profile3 default : 1 interface wlan1 vap profile3 wpa interface wlan1 vap profile4 active : Disable interface wlan1 vap profile4 profileName: Profile4 interface wlan1 vap profile4 ssid : WR322_1 interface wlan1 vap profile4 ssidhided: Disable interface wlan1 vap profile4 vlanID interface wlan1 vap profile4 Isolation: Disable interface wlan1 vap profile4 wmm : Enable...
  • Page 15 interface wlan1 vap profile6 encryption: None interface wlan1 vap profile6 default : 1 interface wlan1 vap profile6 wpa interface wlan1 vap profile7 active : Disable interface wlan1 vap profile7 profileName: Profile7 interface wlan1 vap profile7 ssid : WR322_1 interface wlan1 vap profile7 ssidhided: Disable interface wlan1 vap profile7 vlanID interface wlan1 vap profile7 Isolation: Disable interface wlan1 vap profile7 wmm...
  • Page 16 Dropped Packets: Packet Count: Byte Count: interface statistics WAN ==================== ==================== Packet Count: Byte Count: interface statistics LAN Received Transmitted ==================== ==================== Packet Count: 1582 1619 Byte Count: 267355 546232 interface statistics cellular ==================== ==================== Packet Count: Byte Count: interface gps radio : Enable interface gps information : status: Retry(516)
  • Page 17 longitude: altitude: spkm: nsat: 0 router# show ip ip networkmode : Bridge ip bridge iptype : fixed ip bridge ipaddr : 192.168.10.1 ip bridge netmask : 255.255.255.0 ip bridge gateway : 0.0.0.0 ip bridge dns1 : 8.8.8.8 ip bridge dns2 : 0.0.0.0 ip router wan accesstype : Static...
  • Page 18 ping-watchdog deferred : 120 ping-watchdog failcounter : 30 Spanning Tree router# show spanning-tree spanning-tree enable : Enable spanning-tree forward-time : 15 spanning-tree hello-time spanning-tree max-age : 20 Static Route router# show static_route String format : Destination mask Netmask gw Gateway metric Metric dev Interface Ex : set route 192.168.20.0 mask 255.255.255.0 gw 192.168.20.254 metric 0 dev ( dev : LAN, WAN Cellular)

  • Page 19: Cli Commands For Set

    3.2 CLI COMMAND FOR SET This chapter provides the Set CLI Commands; all of the features are covered in this chapter. By using set command user can do the configuration. Feature Command Line Set – Global Configuration Mode (router# configure terminal) Clock router(config)# set clock manual ip...
  • Page 20 interface ethernet1 DataRate : Auto router(config)# set ip bridge dhcpserver networkmode proxy-arp router router(config)# set ip bridge dns1 dns2 gateway ipaddr iptype netmask router(config)# set ip router router(config)# set ip dhcpserver active gateway ipend ipstart leasetime netmask primary-DNS-Server secondary-DNS-Server wins1 wins2 router(config)# set ip networkmode Bridge...
  • Page 21 Enable Password router(config)# set password old password: ***** new password: ***** confirm password: ***** Ping Watchdog router(config)# set ping-watchdog deferred failcounter interval ip-address1 ip-address2 ping-ip1 ping-ip2 router(config)# set ping-watchdog deferred Integer[120-9999] router(config)# set ping-watchdog failcounter Integer[1-9999] router(config)# set ping-watchdog interval Integer[1-9999] router(config)# set ping-watchdog ip ip-address1 ip-address2...
  • Page 22 router(config)# set spanning-tree enable Disable Enable router(config)# set spanning-tree enable Disable Enable router(config)# set spanning-tree forward-time invalid parameter: Integer[1-30] router(config)# set spanning-tree enable forward-time hello-time max-age router(config)# set spanning-tree hello-time invalid parameter: Integer[1-10] router(config)# set spanning-tree enable forward-time hello-time max-age router(config)# set spanning-tree max-age invalid parameter: Integer[6-40] Static Route...

  • Page 23: Cli Commands For Backup Restore

    3.3 CLI COMMAND FOR BACKUP RESTORE This chapter provides a detailed explanation of the Backup and Restore the configuration by using CLI commands. Feature Command Line Backup Startup router# copy startup-config tftp: 192.168.10.100 router.conf Configuration file Writing startup-config to tftp: 192.168.10.100/router.conf [OK]! Restore Configuration router# copy tftp: startup-config EXEC commands :...

  • Page 24: Cli Commands For Logout

    3.7 CLI COMMAND FOR LOGOUT This chapter is about the CLI Command for log out from the switch CLI interface. Feature Command Line Logout router# exit/end Bye! 3.8 CLI COMMAND FOR LIST ALL OF THE COMMANDS This chapter is about the all of the command lists from CLI Command by type list. Feature Command Line List all of CLI...
