Hommpa SKUJ21468 User Manual

Bedside table
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the SKUJ21468 and is the answer not in the manual?

Questions and answers

Related Manuals for Hommpa SKUJ21468

Summary of Contents for Hommpa SKUJ21468

  • Page 2 BEDSIDE TABLE SKUJ21468 SKUJ31878...
  • Page 3 ASSEMBLY INSTRUCTIONS 1 OF 26...

  • Page 4: Board Identification

    BOARD IDENTIFICATION 2 OF 26...

  • Page 5: Parts List

    PARTS LIST MAIN PANEL BOTTOM BACK PANEL LEFT SIDE PANEL MIDDLEPANEL RIGHT SIDE PANEL SKIRTING BOARD STANDING PLATE PULL PLATE QTY:2 QTY:2 QTY:2 UPPER DRAWER FRONT FRONT PANEL LOWER DRAWER FRONT 3 OF 26...
  • Page 6 PARTS LIST DRAWER LEFT DRAWER RIGHT DRAWER BACK QTY:2 QTY:2 DRAWER BACK DRAWER BOTTOM PULL ACRYLIC SHEETS ACRYLIC SHEETS DRAWER BOTTOM DRAWER BOTTOM 4 OF 26...
  • Page 7 CAM BOLT CAM LOCK OUTER TRACK INNER TRACK F7*30 F15*11 F20*300 F20*300 SCREW SCREW BOLT WOOD DOWEL F3.5*14 F4*35 F8*30 SCREWDRIVER LIGHT STRIP 5 OF 26...
  • Page 8 STEP 1 -Screw the cam bolt (A) into the panel (1) & (8). (Attention:Cam bolt & Insert nut need to be put together) 6 OF 26...
  • Page 9 STEP 2 -Screw the cam bolt (A) into the panel (4) & (5) & (6). -Insert wood dowels (H) into panel (4) & (5) & (6). (Attention:Cam bolt & Insert nut need to be put together) 7 OF 26...
  • Page 10 STEP 3 WARNING How To SEPARATE BALL BEARING SLIDE. 1) Pull toward arrow to open the slide until its stops and then flip it over. 2) Push plastic lever down and pull apart. OUTER TRACK INNER TRACK Align the outer track with the center of the inner track and push in. Three-section track installation video 8 OF 26...
  • Page 11 STEP 4 -Install drawer track (C) to panel (4) & (5) & (6) with screws(E). Front Fasten the screws in the second hole in the front and the second hole in the rear of the drawer rail. Front The direction of the arrow is that the front is fixed on the plate.
  • Page 12 STEP 5 -Stick LED band to the side of the back panel. -Fasten the LED band with buckles 10 OF 26...
  • Page 13 STEP 6 -Attach panel (4) & (5) to (3) and lock with cam (B). 11 OF 26...
  • Page 14 STEP 7 -Attach panel (6) to (7) and lock with cam (B). 12 OF 26...
  • Page 15 STEP 8 -Attach panel (7) to (4) and lock with cam (B). 13 OF 26...
  • Page 16 STEP 9 -Attach panel (1) to (3) & (4) & (5) & (6) and lock with cam (B). 14 OF 26...
  • Page 17 STEP 10 -Screw cam bolts (A) into panel (11). -Attach panel (19) to (11) with screw (G). (Attention:Cam bolt & Insert nut need to be put together) 15 OF 26...
  • Page 18 STEP 11 -Attach panel (11) to (1) & (5) and lock with cam (B) . 16 OF 26...
  • Page 19 STEP 12 -Screw cam bolts (A) into panel (2). (Attention:Cam bolt & Insert nut need to be put together) 17 OF 26...
  • Page 20 STEP 13 -Attach panel (8) to (9) and lock with cam (B) . -Attach panel (8) & (9) to (2) and lock with cam (B) . 18 OF 26...
  • Page 21 STEP 14 -Attach panel (2) to (3) & (4) & (5) with cam locks (B). 19 OF 26...
  • Page 22 STEP 15 -Screw cam bolts (A) into panel (12). -Attach panel (18) to (12) with screw (G). (Attention:Cam bolt & Insert nut need to be put together) Lower 20 OF 26...
  • Page 23 STEP 16 -Screw the cam bolt (A) into the panel (10) & (16). -Insert wood dowels (H) into panel (13) & (14). (Attention:Cam bolt & Insert nut need to be put together) Upper 21 OF 26...
  • Page 24 STEP 17 - Attach panel (17) to (16) with cam locks (B). - Attach panel (13) & (14) to (15) & (16) with screw (F). 22 OF 26...
  • Page 25 STEP 18 - Insert panel (20) & (21) into the grooves. - Attach panel (10) & (12) to (13) & (14) & (17) with cam locks (B). Lower Upper 23 OF 26...
  • Page 26 STEP 19 -Install drawer track (D) to panel (13) & (14) with screws(E). Fasten the screws in the second hole in the front and the second hole in the rear of the drawer rail. 24 OF 26...
  • Page 27 STEP 20 -Connected power adapter to the RGB control box as below. -Specifications of battery:cr2025 3v -LED lamp with effective remote control distance of 5 meters √ CORRECT INCORRECT 1.Connect the light strip plug to the adapter socket correctly 2.Take out the remote control gasket 3.Align romote controller to the RGB Control box to adjust the color mode 25 OF 26...
  • Page 28 STEP 21 - Insert the drawers. Align the outer track with the center of the inner track and push in STEP 22 -Installation complete. 26 OF 26...

This manual is also suitable for:

Skuj31878
