  • Page 2: Regulatory And Safety Information

    About this Concise User Guide This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual disc supplied with your computer.

  • Page 3: Instructions For Care And Operation

    Instructions for Care and Operation Safety Information • Only use an AC/DC adapter approved for use with this computer. The computer is quite rugged, but it can be damaged. To pre- • Use only the power cord and batteries indicated in this manual. vent this, follow these suggestions: Do not dispose of batteries in a fire.

  • Page 4: Polymer/Lithium-Ion Battery Precautions

    Polymer/Lithium-Ion Battery Precautions Note the following information which is specific to Polymer/ Lithium-Ion batteries only, and where applicable, this over- rides the general battery precaution information. • Polymer/Lithium-Ion batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.

  • Page 5: System Start-Up

    System Startup 1. Remove all packing materials.  2. Place the computer on a stable surface. 3. Securely attach any peripherals you want to use with the computer Shut Down (e.g. keyboard and mouse) to their ports. Note that you should always 4.
  • Page 6 System Map: Front View with Display Open (Model A) Figure 2 Front View with Display Open (Model A) 1. Webcam 2. *Camera LED *When the camera is in use, the LED will be illuminated. 3. Built-In Array Microphone (Factory Option) Built-In Microphone 4.
  • Page 7 System Map: Front View with Display Open (Model B) Figure 3 Front View with Display Open (Model B) 1. Webcam 2. *Camera LED *When the camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. Display 5.

  • Page 8: Led Indicators

    LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description  *Powered USB Port (Factory Option) The powered USB 3.2 Gen 2 port (see page 11) may be toggled on /off by means of the Fn + Power Button key combination.

  • Page 9: Keyboard (Model A)

    Keyboard (Model A) The keyboard has a numeric keypad for easy numeric data input. Pressing Fn + Num Lk turns on/off the numeric key- pad. It also features function keys to allow you to change operational features instantly. Num Lk & Function Keys Scr Lk Numeric...

  • Page 10: Keyboard (Model B)

    Keyboard (Model B) The keyboard has a numeric keypad for easy numeric data input. Pressing Num Lk turns on/off the numeric keypad. It also features function keys to allow you to change operational features instantly. Num Lk & Function Keys Scr Lk Numeric Keypad...

  • Page 11: Function Keys & Visual Indicators

    Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations, some visual indicators are available when the Control Center driver is installed. Keys Function/Visual Indicators Keys...

  • Page 12: System Map

    Front, Left & Right Views System Map: (Model A) Front Left Right Figure 9 - Front, Left & Right Views (Model A) 1. Security Lock Slot 8. USB 3.2 Gen 2 Type-C Port 2. RJ-45 LAN Jack (Factory Option) USB 3.2 Gen 2 Type-C Port with DisplayPort and Power 3.
  • Page 13 Front, Left & Right Views System Map: (Model B) Front Left Right  Figure 10 - Front, Left & Right Views (Model B) USIM Card Ejection 1. Security Lock 8. USB 3.2 Gen 2 Type-C Port Slot Or (Factory Option) USB 3.2 Gen 2 Type-C Port with DisplayPort If you do eject the card while a 4G connection is ongoing, and Power Delivery (DC-In)*...

  • Page 14: System Map: Bottom & Rear Views

    System Map: Bottom & Rear Views Model B Model A  Figure 11 Bottom Cover Removal Warning Bottom & Rear Views 1. Vent Do not remove any cover(s) and/or screw(s) for the purposes of device upgrade as this may violate the terms of your warranty. If you need to replace/remove 2.

  • Page 15: Control Center

    Control Center Run the Control Center from the Start menu in Windows . You can also press the Fn + Esc key com- bination, or double-click the icon in the notification area of the taskbar to access the Control Center. The Con- trol Center provides quick access to Power Modes, Fan settings and LED Keyboard configuration (for the optional LED keyboard).

  • Page 16: Power Modes

    Power Modes Fan Speed Control Power Modes allows you to adjust the power mode by clicking the appropriate icon. Figure 14 - Fan Speed Control You can set the fan speed to Maximum (full power) or Automatic/Slient. The fan speed will adjust itself auto- Figure 13 - Power Modes matically to control the heat of the CPU/GPU.
  • Page 17 White-LED Keyboard (Option - Model A Only) The LED Keyboard application can be accessed by clicking LED Keyboard in the Control Center or from the Start menu in Windows Figure 15 - LED Keyboard Application KB Sleep Timer Enable and then select the amount of time for which the system is idle before the keyboard LED enters sleep mode (i.e. the LED keyboard illumination will turn off to save power).
  • Page 18 Multi-Color LED Keyboard (Option - Model B Only) Color Swatch The LED Keyboard application can be accessed by click- ing LED Keyboard in the Control Center (or by press- The color swatch in the middle of the screen allows you to ing the Fn plus key) or from the Start menu in select a range of colors for your keyboard backlight by...

  • Page 19: Windows 10 Start Menu, Context Menu, Taskbar, Control Panel And Settings

    Windows 10 Start Menu, Context Menu, Taskbar, Control Panel and Settings Figure 17 Most of the apps, control panels, utilities and programs within Windows 10 can be Start Menu, accessed from the Start Menu by clicking the icon in the taskbar in the lower Context Menu, left corner of the screen (or by pressing the Windows Logo Key on the key-...

  • Page 20: Video Features

    Video Features Display Devices Note that you can use external displays connected to the The system features an Intel integrated GPU. You can HDMI-Out port and/or USB 3.2 Gen 2 Type-C port with switch display devices, and configure display options, DisplayPort (Factory Option).
  • Page 21 To configure the displays using the Display control panel: 1. Attach your external display(s) to the appropriate port, and turn it (them) on. 2. Right-click the desktop and select Display settings from the menu. 3. Click the Detect button. 4. The computer will then detect any attached displays. 5.

  • Page 22: Audio Features

    Audio Features Power Options You can configure the audio options on your computer The Power Options (Hardware and Sound menu) con- from the Sound control panel in Windows. trol panel icon in Windows allows you to configure power management features for your computer. You can con- The volume may be adjusted by means of the Fn + F5/F6 serve power by means of power plans and configure the key combination.

  • Page 23: Driver Installation

    Driver Installation The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper operation of the computer. This setup will probably have already been done for you. If this is not the case, insert the disc and click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu.

  • Page 24: Wireless Lan Module (Option)

    Bluetooth Module (Option) Wireless LAN Module (Option) Make sure the Wireless LAN module is turned on (and not Make sure the Bluetooth module is turned on (and not in in Airplane Mode) before configuration begins. Airplane Mode) before configuration begins. WLAN Configuration in Windows Bluetooth Configuration in Windows 1.

  • Page 25: Fingerprint Module Configuration

    Fingerprint Reader 7. You will be instructed to Touch the fingerprint sensor a number of times (this may be in excess of 20 times). (Option - Model A Only) 8. Try to present different parts of your finger in different positions similar to the various positions you may use when using it, and Enroll your fingerprints as instructed below before use.

  • Page 26: Activating Tpm

    TPM (Option) 3. Click TPM Administration. Figure 25 Before setting up the TPM (Trusted Platform Module) BitLocker Drive functions you must initialize the security platform. Encryption (TPM Admini- Activating TPM stration) 1. Restart the computer. 4. The TPM Management window allows you to configure the TPM 2.

  • Page 27: Troubleshooting

    Troubleshooting Problem Possible Cause - Solution The Wireless LAN/Bluetooth The modules are off as the computer is in Airplane Mode. Use the Fn + F11 key modules cannot be detected. combination to toggle Airplane Mode on/off (see Table 2 on page 10).

  • Page 28: Specifications

    Specifications BIOS Audio 128Mb SPI Flash ROM High Definition Audio Compliant Interface Insyde BIOS 2 * Built-In Speakers  Memory Built-In Array Microphone Latest Specification Information Dual Channel DDR4 (Factory Option for Model A) Built-In Two 260 Pin SO-DIMM Sockets Supporting The specifications listed in this sec- Microphone DDR4 3200MHz Memory...
  • Page 29 Interface Security Power One USB 3.2 Gen 2 Type-C Port* Security (Kensington® Type) Lock Slot Full Range AC/DC Adapter BIOS Password AC Input: 100 - 240V, 50 - 60Hz (Factory Option) One USB 3.2 Gen 2 Intel PTT for Systems Without TPM Hard- DC Output: 19V, 2.37A (45W) Type-C Port with DisplayPort and Power ware...
