Summary of Contents for Leader SC502
- Page 1 User Manual...
-
Page 2: Notice
Notice The illustrations in this user’s manual are for reference only. Actual product specifications may vary with territories. The information in this user’s manual is subject to change without notice. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL. -
Page 3: Table Of Contents
TABLE OF CONTENTS Notice ....................2 Preface .....................5 1.1 Regulations Information ...........5 1.2 Safety Instructions............6 1.3 Notes for this Manual ............7 1.4 Release History ..............7 Getting to know the basics ...............8 2.1 Product Specification ............8 2.2 Preparing your Computer ..........11 2.3 Product Overview ............12 2.3.1 Top-Open View ............12 2.3.2 Bottom Side View ..........14 2.3.3 Right Side View ............15... - Page 4 3.2.1 Windows 8.1 / Windows 10 for keyboard users ....20 3.3 Using the ClickPad ............22 3.3.1 Windows 8.1 Touchpad Usage ......23 3.3.2 Windows 10 Touchpad Usage ......25 3.4 Using the touch panel (Optional) ........26 BIOS SETUP ..................27 4.1 About BIOS Setup ............27 4.1.1 When to Use BIOS Setup ?........27 4.1.2 How to Run BIOS Setup ?........27...
-
Page 5: Preface
Preface 1.1 Regulations Information CE compliance • This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. CAUTION: Any changes or modifications not expressly approved by the guarantee of this device could void the user's au- thority to operate the equipment. -
Page 6: Safety Instructions
1.2 Safety Instructions The following safety precautions will increase the life of the Computer. Follow all Precautions and instructions. Do not place this device underneath heavy loads or in an unstable position. Do not use or expose this device around magnetic fields as magnetic interference may affect the performance of the device. -
Page 7: Notes For This Manual
1.3 Notes for this Manual CAUTION! Important information that must be followed for safe op- eration. NOTE : Information for special situations. 1.4 Release History Date Version Revision Note 03.2016 First Released... -
Page 8: Getting To Know The Basics
Getting to know the basics 2.1 Product Specification This User’s Manual provides instructions and illustrations on how to operate this notebook. It is recommended to read this manual carefully before using this notebook. ・Physical Characteristic Dimension 380 x 263.8 x 25.1~26.35 mm (w/o rubber foot) Weight 1.90~2.14kg w/4-cell (depend upon the actually shipping product) -
Page 9: Optical Device
・Optical Device 9.5 mm SATA ODD support ・I/O Port (Optional) DC-in USB2.0 x 2 + USB3.0 x 1 RJ45 Phone jack x 1 (Microphone/ Headphone) Card Reader Socket x 1 (SD/MS/MS pro) HDMI ® Kensington Lock ・Audio Audio Codec Azalia standard support, D3 mode support Build-in one speaker as default, two as option Speaker internal MIC support... -
Page 10: Communication Port
・Display Integrated HD Graphics 15.6" HD 16:9 LED type, resolution 1366 x 768 Touch panel (Optional) ・Communication Port Supports 10/100/1000 Mb/Sec. LAN Controller Supports S3/S4/S5 wake ON LAN (WOL) feature Network Proxy-Remote Wake Sleep mode or LPM <10W Wireless LAN IEEE802.11b/g/n support Wireless LAN+Bluetooth IEEE802.11b/g/n support, BT 4.0, USB interface... -
Page 11: Preparing Your Computer
2.2 Preparing your Computer Plug the AC adapter cable into the DC power connector. Connect one end of the power cable to the supplied power adapter, and the other end to a wall outlet. To open your notebook computer. Press the power button to turn on your notebook computer. -
Page 12: Product Overview
2.3 Product Overview This section provides the description of basic aspects of the notebook. NOTE: The product’s color, I/O port, indicator location, and specifi- cation will depend upon the actually shipping product. 2.3.1 Top-Open View The figure of top-open view and description shown below will lead you to browse the main operating area of your notebook. - Page 13 Top Side Components Function Description The Camera indicator shows the Camera Camera Status LED status. The built-in Webcam allows picture taking Webcam or video recording. LCD screen Displays of your notebook computer. Built-in microphone. Microphone Turns on the power of your notebook Power Button computer.
-
Page 14: Bottom Side View
2.3.2 Bottom Side View Refer to the following illustration to identify the components on this side of the computer. NOTE : The product’s thermal vent will depend upon the actually shipping product. Top Side Components Function Description Stereo speakers Produce stereo sound. -
Page 15: Right Side View
2.3.3 Right Side View Refer to the following illustration to identify the components on this side of the computer. Top Side Components Function Description Optical drive Slot for inserting a disc. Eject button Ejects the CD/DVD disc. Kensington To be secured using Kensington ®... -
Page 16: Left Side View
2.3.4 Left Side View Refer to the following illustration to identify the components on this side of the computer. Function Description Top Side Components Connects the AC adapter into this Power Connector connector. HDMI Port Connects an external monitor. Network Jack Connects network. -
Page 17: Front Side View
2.3.5 Front Side View Refer to the following illustration to identify the components on this side of the computer. Top Side Components Function Description Connects amplified speakers, Headphone and headphones or microphone into Microphone jack this jack. Connects an USB device. (such as USB Zip drive, keyboard USB 2.0 Port or mouse) into this jack. -
Page 18: Getting Started
Getting Started 3.1 AC Adapter Please be noted that it is strongly recommended to connect the AC adapter and use the AC power while using this notebook for the first time. When the AC adapter is connected, the battery is being charged immediately. -
Page 19: Knowing The Keyboard
3.2 Knowing the Keyboard The following defines the colored hot keys on the Keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. • Keyboard for Windows 8.1 / Windows 10: ... -
Page 20: Windows 8.1 / Windows 10 For Keyboard Users
3.2.1 Windows 8.1 / Windows 10 for keyboard users To activate these functions, press and hold down <Fn> together with the keys described below: Function Keys Keypad Function Description Press this key combination (Fn+F1) to Suspend: enter sleep mode. Press this key combination (Fn+F2) Power to enter power saving mode (CPU will... -
Page 21: Function Keys
Function Keys Keypad Function Description Press this key combination (Fn+F6) Touch pad: to enter Touch pad mode. Press this key combination (Fn+F7) Webcam to enter Webcam on/off mode. on/off: Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Press this key combination (Fn+F9) Volume to enter Volume down mode. -
Page 22: Using The Clickpad
3.3 Using the ClickPad is a rectangular electronic panel located just below ClickPad your keyboard. You can use the static-sensitive panel of the and slide it to move the cursor. You can use the buttons ClickPad below the ClickPad as left and right mouse buttons. Press the left and right buttons located on the edge of... -
Page 23: Windows 8.1 Touchpad Usage
3.3.1 Windows 8.1 Touchpad Usage Windows 8.1 Touchpad Usage Finger gesture Function Description Mouse cursor manipulation Single-finger Slides Single/two-finger tap, Primary button click, double double tap click at cursor location Horizontal or vertical scroll Two-finger Slides (mouse wheel) Zoom Two-finger Pinch + mouse wheel ) - Page 24 Finger gesture Function Description Toggle the charms Swipe in from the right edge Toggle the app commands Swipe down from the top edge Swipe in from Switch to last application the left edge...
-
Page 25: Windows 10 Touchpad Usage
3.3.2 Windows 10 Touchpad Usage Finger gesture Function Description Mouse cursor manipulation Single-finger Slides Single/two-finger tap, Primary button click, double double tap click at cursor location Horizontal or vertical scroll Two-finger Slides (mouse wheel) Zoom Two-finger Pinch + mouse wheel ) -
Page 26: Using The Touch Panel (Optional)
3.4 Using the touch panel (Optional) Using the touch panel on selected models can operate following gestures. Gestures allow you to launch programs and access the settings of your Notebook. Touch panel CAUTION: Keep your fingers dry and clean while using the touch- panel. -
Page 27: Bios Setup
BIOS SETUP 4.1 About BIOS Setup The default BIOS (Basic Input/Output System) is already properly configured and optimized, there is normally no need to run this utility. 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・... - Page 28 ・ When OS support is Windows 8.1 : 1. Press the Windows key + C, or swipe in from the right edge of the screen to open your Charms. 2. Click Settings. 3. Click Change PC Settings or Click Power and press the Shift key and Click Restart to go to step 6.
