- Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment t: +61 07 3205 1123 www.rotech.com.au e: info@rotech.com.au SafePass KTL Safety Light Curtains User Manual BF2 90 / BF2 180...
- Page 2 Please read the instructions carefully before you start using your device. You fulfill step by step necessary specifications like installing settings, electrical connections and first operate system configurations carefully. After this stage, product owner/user have to keep this manual on known and visible place throughout product life.
-
Page 3: Technical Features
1. DEFINITION Light curtain that we produced works with Photocell infrared communication protocol. They designed to be receiver and transmitter units and usually used for safety purposes. We have two different light curtain models, BF90(Length is 90cm) and BF180(Length is 180cm. The technical features of these products are given below. - Page 4 Do not forget to disconnect the power to change the system operating modes (Lineer, Cross). 2.1. Light Curtain Power Card The power card that will control the Light Curtain receiver and transmitter cards is shown in Figure 1. On this board, there are various terminal connections, 1 trimpot used for transmitter signal strength adjustment, synchronous cable connection to ensure the harmony between the receiver and transmitter Figure 1- BFG - Light Curtian Power Card (K171-01)
- Page 5 The 2 jumpers on the control card have different functions. These functions are shown below; JUMPER JUMPER STATUS JUMPER STATUS Buzzer is active. Buzzer is passive. The system works in linear mode. The system works in cross mode. Response time will be short when the system works in Linear mode. However, the detection sensitivity will not be as good as the cross mode.
- Page 6 Dead Zone and beam range Light Curtains have a dead zone of 7.5cm on the upper part and 2.5cm on the lower part in cross mode. These regions are the parts where the Light Curtain does not detect. The Light Curtain will not be able to detect the hand, arm or any object coming to these areas and will not be able to output.
- Page 7 Use of More Than One Light Curtains Top view of the products is used in this figure TX : Transmitter RX : Receiver...
- Page 8 Led Status There are two LEDs on each of the Receiver and Transmitter Light Curtains cards. These LEDs are explained on the visual below. This LED is used to indicate When an object enters the signal strength of the between the transmitter Receiver Transmitter...
-
Page 9: Connection Schema
3. CONNECTION SCHEMA 6,7cm 3,4cm 5,3cm Dimensions(cm) - Page 10 Dimensions (cm) Fixing the Light curtains on uneven floors with a latch If the system is mounted on bright floors and surfaces, the eyes on the bottom of the product may not detect. t: +61 07 3205 1123 e: info@rotech.com.au www.rotech.com.au...
