- Page 1 5GF DETECTOR USER MANUAL FJC-DL001 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment T: +61 7 3205 1123 www.rotech.com.au e: info@rotech.com.au SAFEPASS 5GF DETECTOR USER MANUAL V2 (0221) Page 1...
- Page 2 5GF DETECTOR USER MANUAL FJC-DL001 INTRODUCTION Providing pedestrian and vehicle safety in car parks is essential, in the past inground loop detectors and safety beams mounted on the boom gate were used to prevent accidents. Both of these devices require a substantial amount of time consuming labour to install them.
- Page 3 5GF DETECTOR USER MANUAL FJC-DL001 Technical Specifications Specification 5GF Detector Construction Material Black ABS Material Size 72mm x 22mm Installation location 600 mm to 700 mm from ground Working 5.8GHz frequency band Temperature -20℃～70℃ Humidity 95% no condensation Voltage DC12V Current ≤0.15A...
- Page 4 5GF DETECTOR USER MANUAL FJC-DL001 2. WIRING INSTRUCTIONS Wiring col- Output Connection Note Yellow Output switch - 12v- 5G detector output signal n/o Brown Output switch + 12V+ Pedestrian Green Output switch - 12v- 5G detector output signal n/o Blue...
- Page 5 5GF DETECTOR USER MANUAL FJC-DL001 Wiring Diagram Page 5...
- Page 6 5GF DETECTOR USER MANUAL FJC-DL001 3. INSTALLATION INSTRUCTIONS Mounting Detector The normal installation height from the roadway is 600 mm - 700 mm, the ideal height is 700 mm as this gives the best coverage. Under no circumstances exceed 800 mm from the ground as low profile sports cars may not be detected.
