- Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment T: +61 7 3205 1123 www.rotech.com.au e: info@rotech.com.au SafePass RD6 Radar Detector User Manual (V09/23)
- Page 2 How to install the radar detector Use a power adapter output 8-4OVDC IA. When using a gate for power supply, please ensure that the output current is not less than 200ma. When applied to lanes, the best height between the radar center and the ground is 50-60cm. ...
- Page 3 Menu 2: Sensitivity content details (The indicate light was the blue LED, The indicator LED has three states: 1. ON 2. OFF) Menu 2 Low sensitivity Middle sensitivity High sensitivity Factory default FLASH FLASH FLASH Menu 3: Details of closing speed (The indicate light was the blue LED, the indicator LED has three states: 1.
- Page 4 How program and save the parameters Step 1: Press the function key (do not release) until the menu number to be set is selected and release the key, the corresponding parameter light will be on. Step 2: Edit parameters: Change the current parameter by function key. Step 3: Save parameters: Press the function key momentarily, and then release.
- Page 5 How to debug on site? Straight lane mode: After the barrier pole is raised, the palm of the hand triggers the radar at a close range, and the gate will automatically close after removing. Within the set detection distance, the pole reverses when the human body approaches the pole. The response speed of the radar can be adjusted.
