- Page 1 VACUUM AUTOMATIC DUSTPAN Please read this user manual in its entirety before use and keep it for future reference...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ·······································································02 SPECIFICATIONS ····················································································03 COMPONENTS ·······················································································03 PRODUCT USAGE ··················································································04 CLEANING AND MAINTENANCE ··························································07 TROUBLESHOOTING ············································································09 LIMITED WARRANTY ··············································································10... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS: To avoid the risk of serious injury when using your Vacuum Automatic Dustpan, basic safety precautions must be followed, including but not limited to the following. Always turn off the unit before unplugging the vacuum. Always unplug the appliance before cleaning or servicing it. Do not unplug by pulling the cord;... -
Page 4: Specifications
SPECIFICATIONS Model Voltage AC120V 60Hz Power 700W Max. Suction Power 140W ≤ ≤ Noise (dBA) High 78dBA Low 69dBA ≥ Dust Capacity Power cord 8.2ft (2.5m) COMPONENTS Product LED Display Control Panel Dust Bin Touch Sensor Tool Mode Connector Air Inlet/Infrared Sensor (packed inside the dustbin) Hose Connector HEPA Filter... -
Page 5: Product Usage
PRODUCT USAGE Indicator State Floor Mode Tool Mode Sensing Mode Infrared induction & Touch sensitive Suction Power Low/Max Error Code The dustbin is full - red light There are obstacles in the airflow - red light The dust bin is not installed properly - white light Button State Power Button... - Page 6 OPERATION Plug in the unit Turn on the unit Choose the working mode that suits you IMPORTANT!!! The suction hole is small. Please do not vacuum paper or cloth rags. This will jam the pipe and cause damage to the machine. Function Button Indicator...
- Page 7 Mode In Floor Mode - when the hose connector is inserted in the cuff. There are two sensing modes in floor mode: 1. Infrared Induction: Sweep the garbage to the Infrared sensor port, the garbage can automatically start to suck in the garbage within the sensing range. 2.
-
Page 8: Cleaning And Maintenance
NOTE: Regularly empty the dust bin to prevent debris buildup, ensuring optimal performance. The red indicator light flashes to signal a full bin or air channel blockage. If the light continues flashing without manual intervention, the vacuum will automatically power off after 10 seconds to prevent damage. - Page 9 * We recommend replacing the filter element every six months Error Code blinking Blink red light The dustbin is full or the pipe is blocked. 1. Clean the garbage in the dustbin. 2. Pull the hose from the unit and straighten the pipe, turn on the vacuum in Max pow to clear the blockage.
-
Page 10: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Corrective Action 1. Plug in firmly on the power socket 1. Not firmly plugged in 2. Press the power button 2. Unit is in the OFF position to standby Unit won't run 3. Dustbin is not installed 3. -
Page 11: Limited Warranty
This limited warranty is only effective for the original purchaser. It is non-transferable. How to request warranty services? To obtain the benefit of this warranty, please email support@airthereal.com. Our customer service team will address your issue as soon as possible! - Page 12 Always here to help you www.airthereal.com WARNING Cancer and Reproductive Harm www.p65warnings.ca.gov Produced for: West Ryder Technology LLC 2330 Paseo Del Prado STE C304 Las Vegas, NV 89102 V 20240607...
