Failure to comply with any of the above requirements may result in injury to personnel or damage to equipment. Redx shall not be liable for any loss of life or damage caused by failure to comply with the requirements of this document and user manual.
Dimension 210mm 210mm 750mm 1540mm Installation Location No direct sunlight No rain exposure No snow exposure Direct sunlight Rain exposure Snow exposure...
: Connect PV to MPPT ports . ② Step : Turn on the battery isolation circuit breakers. ③ Step : Turn on the inverter power button. ④ Step ⑤ : Open the Redx Power App, complete all Installation steps in the App.
Page 6
Installation Avoid water and electricity when drilling, bit size φ8mm, drilling depth 40mm. Expansion 2.8 N.M Bolts 5 N.M Expansion Bolts 5 N.M Refer to the electrical connection section for wiring...
Page 7
Port Instruction Items Name GRID BACKUP DRMO / METER PARALLEL ON-OFF PV SW GRID BREAKER BACKUP BREAKER WIFI / 4G BAT BREAKER PE Wiring 2.8 N.M PE Cable 3 PE Cable 2 PE Cable 3...
Page 8
PV Connection Positive metal terminal Positive connector PV-CZM-22100/19100 Ensure that the cable Negative connector Negative metal terminal cannot be removed Measuring voltage Use the open spanner to tighten the lock nut. If the spanner slips during tightening, it indicates that the lock nut is PV-MS-HZ tightened open spanner...
The dry contact is connected based on customer requirements Dry Contact Connect with weak current Group Definition DRY_1_NC 1 2 3 4 5 6 7 8 DRY_1_COM RJ45 DRY_1_NO CT / Smart meter / DRM0 Smart meter 485,DRM0 signal, external CT Group Definition I_CT_IN-...
Page 12
Network cable (8pin) ① The parallel function determines whether to install according to customer requirements ② The parallel ports are RJ45 terminals and areconnected using conventional 8pin network cables CT / Meter Installation RX- 5000Plus / 7000Plus L-Line GRID Backup Loads Inverter The CT with the "GRID"...
LED Indicator Display Logic LED2 LED3 Bi-colour LED1 System Status System Information Grid/Gen Battery LED4(Green/RED) Wifi/Ethernet/Fault ▲ ▲ ▲ ▲ Power on ■ ■ ■ ■ Power off Normal information Promote update Promote update success ★ ★ ★ ★ ■ ■...
Page 14
SOC Led lndicate Charging ● ● ● ● ● flash 0-20% 21-40% flash 41-80% flash 61-80% flash 81-100% flash Normal ● ● ● ● ● 0-20% 21-40% 41-80% 61-80% 81-100% Notice If the startup fails, refer to "Troubleshooting" in the user manual. For details about LED indicators, refer to the user manual.
Description Of Energy Storage Capacity Power Installation Method List 6kWh Inverter*1 (5006Plus / 7006Plus) Battery*2 Base*1 10kWh Inverter*1 (5010Plus / 7010Plus) Battery*3 Base*1 Inverter*1 13kWh Battery*4 (5013Plus / 7013Plus) Base*1...
Page 16
Redx App Download Redx.com.au Downloads Redx Power App Installer Manual 5000HY/7000HY User Manual 5000HY/7000HY Quick Installation Guide 5000HY/7000HY Warranty Card Redx Power App User Manual RX-0050 User Manual The size and parameters of the product are subject to change without notice.
