Newfeellight LaserCube M5 User Manual

Thank you very much for purchasing the M5 full-color animation series laser shower. For your personal safety and better
Before using this product, please read this manual carefully and strictly abide by the warnings stated in this manual.
precautions and operating instructions to avoid misuse that may cause personal safety and damage to the lamp.
Please check whether the following items are present when you
open the packaging box of the laser presenter:
Laser light *1
Installation pendant/triangle *1
support bracket Battery *1
charging adapter *1
Instruction manual*1
Unboxing instructions:
After opening the packaging box, carefully check whether the
laser performer is damaged due to transportation, such as
whether the screws are loose and whether the reflective lens is
Whether it is broken, etc. If there is any damage caused by
transportation, please do not use this lamp and contact the dealer
or manufacturer as soon as possible.
Safety warning:
1.This lamp has a built-in battery and is a laser lamp for low-
voltage 12V input. Please be sure to connect the power adapter
delivered with the lamp.
Or use the internal battery directly to power the device! ! Do not
connect high voltages above 14V directly! ! ! !
2.Please do not install the lamp directly on the surface of ordinary
combustible materials.
3.The lamp should be installed in a well-ventilated place, keeping
the distance from the wall more than 10 cm, and please check
whether the fan hole is unobstructed.
4.Do not project the lamp directly on combustible objects. Please
keep the distance between the lamp and the illuminated object at
least 12 meters.
M5 LaserCube APP laser light
Video Link:
Packing list:
User Manual
Product picture
https://youtu.be/94p_vvth5oI
Input voltage: DC12V 4A
Built-in: 3 joints 18650 rechargeable batteries (full charge
endure is about 2 hours)
Power: Max 50W
Laser power: RGB 300mw-5W
Laser wavelength: Green/ 520nm Red/ 638nm Blue/450nm
Laser type: Imported semiconductor solid-state laser
Laser light outlet beam size: <7*6mm
Laser beam divergence angle: <1.3mrad
Laser color: RGB
Scanning system: 15kpps, scanning angle ±20°
Modulation signal: TTL modulation or analog modulation
Operation interface: The color display screen can set the
working mode, and the mobile phone APP (LightElf) or WeChat
Applet can be directly edited and controlled to play (support
Apple and Android systems)
Laser pattern: Built-in 180 geometric figures + 60 groups of
animation effects (mobile
groups each)
Control mode: automatic running/mobile phone APP control
DMX control/ILDA control (only available in M7 series)
Cooling system: fan
Installation way: hanging installation/triangle bracket
installation (optional)
Working environment: Indoor
protection level: IP20
Suitable places: home entertainment, travel, KTV package
room, small bar, family party, etc.
www.newfeellight.com
Technical parameters
phone APP control can only call 50
