- Page 1 USER MANUAL RGB MOVING HEAD STAGE LIGHT Please read this manual carefully before using the product...
-
Page 2: Table Of Contents
CONTENT 1.Safety Guidance ................... 3 2.Packing List ................... 4 3.Installation Notes ................. 4 4.Technical Parameter ................5 5.Light Control Panel ................6 6.Light Setting ..................8 6.1TFT LCD display control panel function menu setting....8 7.Light Control Mode ................13 8.DMX512 Control ................. -
Page 3: Safety Guidance
1. Safety Guidance Thank you for choosing our products. For your safety, please read this manual carefully before operation. This manual includes installation and use information. The equipment is packaged in good condition when leaving the factory. Please operate according to the user manual. The machine failure caused by man-made reasons is not covered by the warranty. -
Page 4: Packing List
11． Avoid operating the light in a dirty and dusty environment, and clean and maintain the light regularly. 12． Do not touch the wire when the light is running to prevent electric shock. 13． Avoid entanglement of the power cord with other wires. 14．... -
Page 5: Technical Parameter
Before installation, please confirm whether the power supply voltage you are using matches the voltage marked by the light. Make sure that the ventilation fan and exhaust passage are not blocked by other equipment or decorative materials, such as newspapers, tablecloths, curtains, etc. -
Page 6: Light Control Panel
5. Light Control Panel Interface Name DMX512 interface ILDA interface Power switch Fuse Power input interface... - Page 7 6. Light Setting Using the touch button and LCD menu display function, the menu operation is simple and easy to use, and the system software is automatically loaded when the system is turned on, and the main menu interface is displayed. Use the UP and DOWN buttons to select the required function menu icon.
-
Page 8: Light Setting
TFT LCD display control panel function menu setting ,as following ： Secondary Menu Third Level Menu Menu DMX-512 Channel value view DMX-512 CH1—CH40 Show（1-3 show effect） Auto mode Sound ON/OFF Operation Mode Value setting (CH1-CH40Customizable The User mode value of each channel of the luminaire ) DMX-512 DMX Address... - Page 9 X axis invert(ON/OFF) Y axis invert(ON/OFF) Replace XY（ON/OF） Color setup（RGB/G） Dimmer(1-100) Color setup red(1-100) green(1-100) blue(1-100) Channel （6ch/40ch） Master/slave ×/√ Scanner Kpss（20K~40K） Sound Sense 0-100 Scan safety ×/√ System Config Easy ILDA（OFF/ON） LOGO（OFF/ON） screen protect（OFF/ON） screen invert（OFF/ON） Motor reset ON/OFF Reset factory setting （OFF/ON）...
- Page 10 (on/off) Overall brightness （0-255） Testing pattern test pattern(1-4) Black White LED color Green Blue Channel Current device channel value Current device address Current device running mode EFFEC XXX effect version Temp XXX house current Device Info device temp HdV XXX hardware version SV AXXX software version CV BXXX control panel version...
- Page 11 Operation mode ——only one mode can be run at the same time (ILDA signal has the highest priority) Console mode ： Select the console mode to display the number of channels currently in use for DMX control according to the desired effect. After the setting is completed, if you need to see the value of each channel, you can press the ok key to enter the channel view.
- Page 12 lamp; green brightness, set the green brightness of the lamp; blue brightness, set the blue brightness of the lamp. System setup：Channel mode 6CH/33CH selection; master-slave setting selection; galvanometer K number setting to set the scanning rate of the galvanometer; the higher the value of voice control sensitivity from 0 to 255, the stronger the sensitivity;...
-
Page 13: Light Control Mode
Chassis temperature Internal temperature of lamps Hardware version number Batch of lamp program board Software version number Lamp program version Control panel Control panel program version number (you can judge whether the control board information is read) Motor mode motor mode program version number (you can judge whether the control board information is read) The scanner detection error reporting function: power ON the machine and △... -
Page 14: Dmx512 Control
Auto mode When the lamp is not connected to an external signal, the device can choose to run automatically. User mode： The numerical value lamps of each channel of the lamps can be controlled through the operation interface 8. DMX512 Control 8.1 DMX512 Connect... -
Page 15: Dmx512 Chanel Setting
In order to reduce signal errors and avoid signal weakening or interference during transmission, a 120Ω resistance loop can be inserted between the 2 cores and the 3 cores of the DMX output terminal of the last machine. Connect the lamp with XLR signal, one end is connected to the output port of the lamp, and the other end is connected to the input port of the next lamp. -
Page 16: Dmx512 Chanel Display
complete the connection ,As following : When using any controller, each controller must have its own address. Therefore, the address of the first light fixture is set to 1, the address code of the second light fixture is set to 7 or 34 (address code 1 of the first light fixture plus 6 or 33 channels), and the third light fixture is set to 13 or 67. - Page 17 0～255 Y axis motor (X motor position) 0～255 Y motor Fine-tuning 0～255 XY motor speed choose XY motor reset 0～255 (When the value is 255, after 20S ,reset) (off) 0～31 Blackout 32～63 Manual play 64～95 Auto play macro function 96～255 reserved 0～255 Dimmer Brightness 0% ～...
- Page 18 CH22 0～255 From bottom to top(Y rotation) Choose color 0～7 Default color 8～63 7 pcs different color 64～127 Each 8 value be one effect，total 8 effect CH23 128～143 Macro function 1 144～159 Macro function 2 160～175 Macro function 3 176～191 Macro function 4 192～207 Macro function 5...
- Page 19 function 1 127～ Strobe mode( from slow to fast) X horizontal position ( when value=0 Invalid ) Invalid 1～32 Macro function 1 33～64 Macro function 2 Macro 129～ 65～96 97～128 Macro function 4 Macro function 5 CH28 function 3 161～ Macro 225～...
- Page 20 161～ Macro 225～ 193～224 Macro function 7 Macro function 8 function 6 X Rotation ( when value=0 Invalid ) Invalid 1～32 Macro function 1 33～64 Macro function 2 Macro 129～ 65～96 97～128 Macro function 4 Macro function 5 CH32 function 3 161～...
-
Page 21: Built In Effect Pattern
9. Built in effect list... -
Page 23: Maintenance
10. Maintenance 1. Maintenance should be performed every 15-day period, by using a sponge which is dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror.Always disconnect from the power when the device is not in use or before cleaning it. -
Page 24: Warning And Declaration
11.Warning and Declaration Do not look directly at the light source with your eyes when turning on the light. Before any installation and maintenance work, please make sure that the power has been cut off. Electrical safety Optical security Product common breakdown comparative chart breakdown cause Major breakdown analysis and solution 1. - Page 25 controlled by the 2.Check whether the XLR signal is damaged. controller Master-slave 1.Confirm that there is only one host, and the host is not synchronization mode, connected to the DMX console, and set to voice control the master is normal, or auto-propelled mode.
