Thank you for purchasing RGB laser light, for your personal safety and better use of the product, please read this manual
carefully before use, lest incur any personal injury or damage to the projector
Product
App Control Laser Light
name
Net weight
1.05 KG
Product size
133*123*110 mm
Material
Aluminum
Electrical
Power
Max 60W
comsumption
Power supply AC90-240V,50-60Hz±10%
Modulation
TTL modulation
Scanner/Mot
20KPPS high speed scanning
or
Control
DMX512 / Auto / voice /
Control mode
Master-slave
DMX Channel 8/19 CH
Interface
Power con, DMX con
M2 APP Control Dj Laser Light
User Manual
Product picture
Video Link:
https://youtu.be/xngzUfravi4
Product Specification
Product
model
Light color
Gross weight 1.2 KG
Package size
Protection
Rate
Laser Power
Laser
wavelength
Beam size
Beam
divergence
Type of laser
Scanner
Angle
www.newfeellight.com
M2 Series
RGB
340*290*270 mm
IP33
Laser module
RGB300-2000mW
Red 638±5nm, Green
520±5nm, Blue 450±5nm
<6*5mm
<1.3mrad
Imported semiconductor
solid-state laser
Optical/scan
20KKPS
± 20-30 degrees
Features
Black Cube APP Remote Control Laser
Light
The pattern has the effects of broken pen,
strobe, tumbling, moving, stretching,
zooming, gradual drawing, speed, color,
etc. It has the function of pattern size
adjustment, built-in 128 beams and
animation patterns, which can be used for
beam animation performance, laser
advertising, laser Projection laser sky net
beam performance, laser flowing line
effect.
Suitable places: Dj, disco, club, pub, bar,
party, ball room, Stage, concert , wedding ,
theater, event , and any other
entertainment places.
1
Advertisement
Related Manuals for Newfeellight M2 Series
Summary of Contents for Newfeellight M2 Series
- Page 1 Thank you for purchasing RGB laser light, for your personal safety and better use of the product, please read this manual carefully before use, lest incur any personal injury or damage to the projector Product picture Video Link: https://youtu.be/xngzUfravi4 Product Specification Features Product M2 Series Product model App Control Laser Light name Light color Net weight 1.05 KG Gross weight 1.2 KG...
-
Page 2: Additional Information
Motherboard fixed built-in geometric pattern (static pattern) Pattern library 1 (line animation) 8~15 Pattern library 2 (animal animation) 16~23 Pattern library 3 (animations of characters, cars, etc.) 24~31 Pattern library 4 (static patterns and text) 32~39 Pattern library 5 (static geometric patterns) 40~127 www.newfeellight.cocm... - Page 3 4 values. 13 color combinations such as white + red / cyan + blue / colorful. 56 segments for color selection, with 1 color selection for 192~215 every 4 values, including 6 color combinations such as white + red + green + blue. www.newfeellight.com...
- Page 4 Strobe speed selection, from slow to fast 19CH control mode Additional information Channel value Function Turn off the lights 1~255 Turn on the light 0~255 Pattern size selection, with displacement after reduction Motherboard fixed built-in geometric pattern (static pattern) 8~15 Pattern library 1 (line animation) www.newfeellight.cocm...
- Page 5 Choose 1 for every 2 values for every 2 values. 0～26 Default animation and effect speed 27～127 Select the dynamic speed of animations and effects Enter the voice control mode, adjust sensitivity from small to 128～255 large Original color of pattern www.newfeellight.com...
- Page 6 Color writing mode 3, 7 colors in 2 segments from the start 248～252 point outwards Color writing mode 4, 7 colors in 3 segments from the start 253～255 point outwards Color does not flow Color running/writing in counterclockwise direction, speed 1~127 change www.newfeellight.cocm...
- Page 7 Horizontal position selection, the value 128 is the middle CH12 0~255 position The part of the graphic that goes beyond the boundary is hidden and not displayed. Vertical position selection, the value 128 is the middle CH13 0~255 position www.newfeellight.com...
- Page 8 Vertical movement out of bounds mode speed selection 160~223 from bottom to top, from slow to fast Move vertically to the boundary and return mode speed 224～255 selection X direction wave special effect speed selection, from slow to 1～127 fast CH19 www.newfeellight.cocm...
- Page 9 To begin using the product, you will need to download the light library and fonts. Operation: 1. Navigate to Settings 2. Select Download Files →Choose the file type and file you want to download →Click on the Download button www.newfeellight.com...
- Page 10 2: Sequences need to be generated into TF1 files before they can be uploaded to the luminaire for playback. 3: Edited sequences can be saved for future modifications, facilitating easy adjustments for subsequent use (as the app cannot directly edit TF1 files). www.newfeellight.cocm...
-
Page 11: Maintenance
Be careful not to wipe the lens with wet cloth or other chemical solvents. The number of cleaning times depends on the lamp. The frequency of operation depends on the surrounding usage environment; it is recommended to clean it every 15 days. www.newfeellight.com...
