ASSEMBLY INSTRUCTION FOR ACME FURNITURE
Thank you for purchasing the quality product. Be sure to check all packing material carefully for small part which may
have come loose inside the carton during shipment. Separate, identify and count all parts and metal hardware. Compare
with all parts list to be sure all parts are present. If any part(s) are missing or damaged, please contact your local furniture
dealer. For efficient and speedy service, please indicate the model number and code letter of part(s) needed.
*** Do not fully tighten screws until fully assembled ***
DESCRIPTION
1
2
3
4
5
6
7
8
9
10
MODEL# 21528T-W
COMPONENT PARTS
PART NAME
HEADBOARD
PANEL
HEADBOARD
POST (LEFT)
HEADBOARD
POST (RIGHT)
FOOTBOARD
PANEL
FOOTBOARD
POST (LEFT)
FOOTBOARD
POST (RIGHT)
SIDE RAIL (LEFT)
SIDE RAIL (RIGHT)
SIDE RAIL
CENTER LEG
SLATS
QTY (PCS)
3
1
1
1
1
1
2
2
2
2 SET
PAGE 1/5
