Assembly - HAMPTON BAY RIVERBROOK S44-0003A Use And Care Manual

Assembly

1
Attaching the arms to the seat panel
□
Attach the left arm (C) and right arm (B) to the seat panel (A) with
M6x20 bolts (AA).
NOTE: Please ensure all bolts are aligned and assembled
correctly. Fully tighten bolts with M6 hex wrench (G G ).
A
B
AA
2
AA
C
4
Attaching the back panel
□
Attach the back panel (D) to the arms (B and C) with
M6x3 5 bolts (BB).
NOTE: Please ensure all bolts are aligned and assembled
correctly. Fully tighten bolts with M6 hex wrench (G G ).
D
BB
