Item #1006596139, 1006596130
Model #SB30, SB36
USE AND CARE GUIDE
SINK BASE CABINET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this base cabinet. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HAMPTON BAY SB30

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this base cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
  • Page 2: Table Of Contents

    Table of Contents Safety Information ........2 Cabinet Assembly .
  • Page 3: Pre-Assembly

    Pre-Assembly BEFORE YOU BEGIN Compare all parts with the Hardware Included and Package Contents sections. If any part is missing or damaged, do not assemble this product. Contact Customer Service. Assemble the cabinet on a soft surface such as carpet or the cardboard container of this product. TOOLS REQUIRED Phillips Rubber...
  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Back Panel Side Panels Face Frame Bottom Panel Toe Kick...
  • Page 5: Cabinet Assembly

    Cabinet Assembly Attaching the posts to the panels □ Align four posts (AA) with pre-drilled holes on each of the panels and frame (A – C) and secure with four screws (BB) on each panel and frame (A – C). Attaching the side panels into the face frame □...
  • Page 6 Cabinet Assembly (continued) Attaching the bottom panel □ Slide the bottom panel (D) into grooves in the sides. □ Snap four corner locks (CC) over the posts to secure the face frame (C) and side panels (B) as shown. At the top of the cabinet, the smooth face of each corner lock (CC) should be facing out.
  • Page 7 Cabinet Assembly (continued) Attaching the back panel □ Assemble the back panel (A) and the four remaining corner locks (CC). NOTE: If installing on a laminate countertop, orient the smooth face of each top corner lock (CC) in the opposite direction. Bottom corner lock assembly will be the same for all countertop types.
  • Page 8 Cabinet Assembly (continued) Securing the bottom corner locks □ Insert a screw (BB) through each hole in the bottom four corner locks (CC), and screw into the bottom panels. Attaching the toe kick □ Slide the toe kick (E) into the grooves of the side panels (B) so that it sits flush with the bottom of the cabinet. □...
  • Page 9 Cabinet Assembly (continued) Securing the back and side panels □ Insert screws (BB) into countersunk holes in the back (A) and side panels (B). Attaching silicone pads □ Peel and stick two silicone pads (DD) onto the inside corners of each door. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10: Care And Cleaning

    Cabinet Assembly (continued) (OPTIONAL) Adjusting the door □ Door hinges are 6-way adjustable. □ Up or down adjustment – Loosen screw 1, align the door, and tighten screw 1. NOTE: It is critical that you do NOT overtighten screw 1. □...
  • Page 11 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
