- Page 1 IC-Series Cooler Instruction Manual IC-150 IC-150/IC-150L Models: Listed on Inside Cover IC-150L NSF/ANSI7 SA44689...
-
Page 2: Table Of Contents
IC-150/IC-150L IC -Series Cooler Instruction Manual Includes Models: Table of Contents IC-150 IC-150-0-2-3-5-B-1 IC-150/IC-150L Parts & Identification List ......4 IC-150-L Safety Instructions . -
Page 3: Parts & Identification List
13. Do not adjust the temperature control. The temperature control is factory set between levels 4 and 5 for maximum performance. Innovative DisplayWorks, Inc. Innovative DisplayWorks offi ce 909.447.8254 • fax 909.305.8756 • toll free 877.307.2665 • www.idw.global Last Revised: January 18, 2024 11:27 AM... -
Page 4: Installation
• Remove plug and cord from inside the carrier if there is damage. IDW is not ment à la réglementation fédérales ou locales. Réfrigérant inflammable utilisé. lower rear of the Cooler. responsible for damage incurred during... -
Page 5: Maintenance
IC-150/IC-150L Instruction Manual MAINTENANCE Accessing Cooler Components: MAINTENANCE * A CERTIFIED TECHNICIAN IS REQUIRED TO REPAIR ALL REFRIGERATION COMPONENTS FOR WARRANTY PURPOSES. Condenser For convenient repair, the refrigeration components (compressor, evaporator, condenser, It is essential to keep the condenser coils clean and free of dust and debris at all times. Periodically evaporation fan, condensation fan and fi lter) are designed using a split system;... -
Page 6: Troubleshooting
IC-150/IC-150L Instruction Manual TROUBLESHOOTING CIRCUIT DIAGRAM The following are NOT malfunctions: Model: IC-150-0235B-1 IC-150-0235B-1 Situation Causes Liquid fl owing noise within Cooler • This is the sound of the cooling agent fl owing through the pipes. Refrigeration system is shutdown for longer periods •... - Page 7 IC-150/IC-150L Instruction Manual CIRCUIT DIAGRAM IC-150L (w/ Front Door & Lid Logos) Model: IC-150-L235B-1, IC-150-LB235B-1 IC-150-L235B-1, IC-150-LB235B-1 POWER PLUG TEMPERATURE PROBE TH1: THERMOSTAT SWITCH OF DOOR SIDE LIGHT TR1,TR2: POWER ADAPTOR SWITCH OF LOGO LIGHT FRONT DOOR SIDE LIGHT EVAPORATOR FAN FRONT DOOR LOGO LIGHT CONDENSER FAN TOP LID LOGO LIGHT...
- Page 8 Innovative DisplayWorks, Inc. 8825 Boston Place, Rancho Cucamonga CA 91730...
