GASLAND IH77BFH User Manual

Electric induction cooktop
Hide thumbs

Advertisement

Quick Links

Download this manual
IH77BFH
ELECTRIC
INDUCTION
COOKTOP
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the IH77BFH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GASLAND IH77BFH

Summary of Contents for GASLAND IH77BFH

  • Page 1 IH77BFH ELECTRIC INDUCTION COOKTOP USER MANUAL...

  • Page 3: Safety Warning

    Safety Warning Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •...

  • Page 4: Health Hazard

    • This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. • Failure to install the appliance correctly could invalidate any warranty or liability claims. Operation And Maintenance Electrical Shock Hazard •...
  • Page 5 • Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other cooking zones that are on. Keep handles out of reach of children. • Failure to follow this advice could result in burns and scalds. Cut Hazard •...
  • Page 6 them in its use. The instructor should be satis ed that they can use the appliance without danger to themselves or their surroundings. • Do not repair or replace any part of the appliance unless speci cally recommended in the manual. All other servicing should be done by a quali ed technician.

  • Page 7: Product Overview

    CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. WARNING: In order to prevent tipping of the appliance, this stabilizing means must be installed. Refer to the instructions for installation. WARNING: Use only cooktop guards designed by the manufactuer of the cooking appliance or indicated by the manufacture of the appliance in the instruction for use as suitable or cooktop guards incorporated in the appliance.
  • Page 8 Control panel 1. Timer control 2. ON/OFF control 3. Power regulating key/boost function control 4. keylock control 5. Keep warm function control 6. Stop and go function control 7. Flex zone control/BBQ function control A Word On Induction Cooking Induction cooking is a safe, advanced, e cient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface.

  • Page 9: Using The Touch Controls

    Before Using Your New Induction Cooktop • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective lm that may still be on your induction cooktop. Using The Touch Controls • The controls respond to touch, so you don’t need to apply any pressure.
  • Page 10 • Cookware made from the following materials is not suitable: pure stainless steel, aluminium or copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware. Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits at against the glass, and is the same size as the cooking zone.

  • Page 11: Using Your Induction Cooktop

    Pan Dimensions The cooking zones are up to a limit, automatically adapted to the diameter of the pan. However the bottom of this pan must have a minimum of diame- ter according to the corres ponding cooking zone. To obtain the best e ciency of your hob, please place the pan in the centre of the cooking zone.

  • Page 12: When You Have Nished Cooking

    4. Select a heat setting by touching the “-” “+” control or slider along the power level control. • If you don’t choose a heat setting within 1 minute, the induction hob will automatically switch o . You will need to start again at step 1. •...
  • Page 13 2. Turn the cooking zone o by touching and holding the “-” and scrolling down to “0”. Make sure the power display shows “0”, then shows “H”. and the 3. Turn the whole cooktop o by touching the ON/OFF control. 4.

  • Page 14: Restrictions When Using

    Using The Boost To Get Larger Power 1. Touch the control panel button that you wish to boost, then hold the “b” for 3 second. The power display will show “P” to indicate that the zone is boosting. 2. The boost power will last for 5 minutes and then the zone will go back to the power stage which was set before boost.
  • Page 15 1. In group a, if use boost on one zone, rst make sure that the other zone is working on/below power level 5. When you select one zone and press ‘boost’ button, if the other zone is working above power level 5, the “P”...

  • Page 16: Power Management Function

    b. If you want to use the boost function on group b ‘s right one zone , only one of the zone on the group b can be used at the same time. You need to decrease the power level of the other zone to ”5 “ or less rst, otherwise “P”...
  • Page 17 • Only Group b has this function. The function will activate when the total electricity loading of the cooking zones exceeds 3600 W. • The function decreases the power to the other cooking zones. Using The Keep Warm Keep warm function is suitable for keeping food warm. Using The Keep Warm To Get Stable Temperature 1.
  • Page 18 3. If you want to cancel the keep warm, touch the slider of the selection control, an indicator next to the key will ash. And then touch the keep warm function control, the heating zone will go back to “0” power stage.
  • Page 19 Flex Zone • This area can be used as a single zone or as two di erent zones, accordingly to the cooking needs anytime. • Flexible area is made of two independent inductors that can be controlled separately. When working as a single zone, a cookware is moved from one zone to the other one within the exible area keeping the same power level of the zone where the cookware originally was placed, and the part that is not covered by cookware will not heat.
  • Page 20 2. Touch the ex zone selection button, to activate the exible area as a single big zone, the power level indicators of the front zone and the rear zone will indicate the same power level and led indicator next to the ex zone button will light up.

  • Page 21: Locking The Controls

    Using The Barbecue Function BBQ is the function that used at the exizone mode which will allow the pan surface temperature stay at a reasonable level. 1. Touch any point of the slider for the left zones to active the zone, then touch the flexizone key and hold 3 second, the hob will go into the BBQ mode and show ‘b’, ‘q’.

  • Page 22: Over Temperature Protection

    To unlock the controls 1. Make sure the Induction hob is turned on. 2. Touch and hold the keylock control for a while (3 second). 3. You can now start using your Induction hob. When the hob is in the lock mode, all the controls are disable except the ON/OFF, you can always turn the induction hob o with the ON/OFF control in an emergency, but you shall unlock the hob rst in the next operation.

  • Page 23: Using The Timer As A Minute Minder

    When the pot is removed, the induction hob can stop heating immediately and the hob automatically switch o after 2 minutes. People with a heart pace maker should consult with their doctor before using this unit. Using The Timer You can use the timer in two di erent ways: •...
  • Page 24 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will ash for 5 seconds. 6. Buzzer will bips for 30 seconds and the timer indicator shows “- -”...
  • Page 25 4. To cancel the timer, touch the slider of the selection control, and then touch the “-” of timer and scrolling down to “0”, the timer is cancelled, and the “00” will show in the minute display, and then “--”. 5.

  • Page 26: Cooking Guidelines

    (set to 6 minutes) (set to 3 minutes) 2. When cooking timer expires, the corresponding heating zone will be automatically switch o and show “H”. NOTE: If you want to change the time after the timer is set, you have to start from step 1.
  • Page 27 Simmering, cooking rice • Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the surface of the cooking liquid. It is the key to delicious soups and tender stews because the avours develop without overcooking the food. You should also cook egg-based and ourthickened sauces below boiling point.

  • Page 28: Heat Settings

    Heat Settings The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the induction hob to nd the settings that best suit you. Heat setting Suitability •...

  • Page 29: Care And Cleaning

    Care And Cleaning What? How? Important! • When the power of the Everyday 1. Switch the power to the cooktop is switched o , cooktop o . soiling on there will be no ‘hot surface’ glass 2. Apply a cooktop indication but the cooking ( ngerprints, cleaner while the glass...

  • Page 30: Hints And Tips

    What? How? Important! 1. Switch the power to the Spillovers on the • The cooktop may beep and cooktop o . touch controls turn itself o , and the touch 2. Soak up the spill controls may not function 3. Wipe the touch control while there is liquid on area with a clean them.
  • Page 31 Problem Possible causes What to do Rough-edged cookware. Use cookware with at and smooth bases. See ‘Choosing the right The glass is being cookware’. scratched. Unsuitable, abrasive See ‘Care and cleaning’. scourer or cleaning products being used. This may be caused by the This is normal for Some pans make construction of your...

  • Page 32: Failure Display And Inspection

    Problem Possible causes What to do The induction Technical fault. Please note down the error cooktop or a letters and numbers, switch the cooking zone has power to the induction cooktop turned itself o o at the wall, and contact a unexpectedly, a quali ed technician.
  • Page 33 The above are the judgment and inspection of common failures. Please do not disas- semble the unit by yourself to avoid any dangers and damages to the induction cooktop. Model IH77BFH Cooking Zones 5 Zones Supply Voltage 220-240V~ Frequency 50/60Hz...
  • Page 34 Under any circumstances, make sure the Induction cooktop is well ventilated and the air inlet and outlet are not blocked. Ensure the Induction cooktop is in good work state. As shown below. NOTE: The safety distance between the hotplate and the cup board above the hotplate should be at least 30 inch.

  • Page 35: Before Locating The Fixing Brackets

    • The isolating switch will be easily accessible to the customer with the cooktop installed. • You consult local building authorities and by-laws if in doubt regarding installation. • You use heat-resistant and easy-to-clean nishes(such as ceramic tiles) for the wall surfaces surrounding the cooktop. When You Have Installed The Cooktop, Make Sure That •...
  • Page 36 Screw Bracket Screw Hole Bottom Base Worktop/Kitchen cabinet Glass A ST3.5*8...

  • Page 37: Connecting The Cooktop To The Mains Power Supply

    Cautions 1. The induction cooktop must be installed by quali ed personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The cooktop will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the cooktop electronics.
  • Page 38 The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below. • If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent with dedicated tools to avoid any accidents.
  • Page 39 This appliance is labeled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possi- ble damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
  • Page 40 SCAN ME 8350 Patriot Blvd STE B, 1 (844) 538-7890 www.gaslandchef.com support@gaslandchef.com N. Charleston, SC 29418...
