- Page 1 IH SERIES ELECTRIC INDUCTION COOKTOP USER MANUAL...
-
Page 2: Safety Warning
Safety Warning Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the main electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •... - Page 3 • Failure to install the appliance correctly could invalidate any warranty or liability claims. Operation And Maintenance Electrical Shock Hazard • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the main power supply and contact a qualified technician.
- Page 4 Cut Hazard • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted.Use with extreme care and always store safely and out of reach of children. • Failure to use caution could result in injury or cuts. Important Safety Instructions •...
- Page 5 • Do not use pans with jagged edges or drag pans across the Induction glass surface as this can scratch the glass. • Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can scratch the Induction glass. •...
-
Page 6: Product Overview
instruction for use as suitable or cooktop guards incorporated in the appliance.The use of inappropriate guards can cause accidents. This appliance incorporates an earth connection for functional purposes only. Congratulations On the purchase of your new Induction cooktop.We recommend that you spend some time to read this Instruction/Installation Manual in order to fully understand how to install correctly and operate it. - Page 7 Top view (IH60BF) Control panel (IH60BF) 4 8 3 1. ON / OFF control 2. Pause function control 1. 2000W boost to 2600W zone 3. Keep warm function control 2. 1500W boost to 2000W zone 4. Boost function control 3. 2000W boost to 2600W zone 5.
- Page 8 Top view (IH90BF) 1. Max. 2000w boost 2600w zone 2. Max. 1500w boost 2000w zone 3. Max. 2000w boost 2600w zone 4. Max. 1500w boost 2000w zone 5. Max. 2300w boost 3000w zone 6. Glass plate 7. Control panel 3 sec Control panel (IH90BF) 1.
-
Page 9: Using The Touch Controls
Iron pot Magnetic circuit Ceramic glass plate Induction coil Induced currents Before Using Your New Induction Cooktop • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your induction cooktop. -
Page 10: Choosing The Right Cookware
Choosing The Right Cookware • Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test. - Page 11 Always lift pans off the induction cooktop – do not slide, or they may scratch the glass. Pan Dimensions The cooking zones are up to a limit, automatically adapted to the diameter of the pan. However the bottom of this pan must have a mini- mum of diameter according to the corresponding cooking zone.
-
Page 12: Using Your Induction Cooktop
Using Your Induction Cooktop To start cooking 1. Touch the ON/OFF control. After power on, the buzzer beeps once, all displays show “ – “ or “ – – “, indicating that the induction cooktop has entered the state of standby mode. 2. -
Page 13: When You Have Finished Cooking
If The Display Flashes Alternately With The Heat Set- ting This means that: • you have not placed a pan on the correct cooking zone or, • the pan you’re using is not suitable for induction cooking or, • the pan is too small or not properly centred on the cooking zone. No heating takes place unless there is a suitable pan on the cooking zone. -
Page 14: Using The Boost Function
Make sure the power display shows “0”, then shows “H”. 3. Turn the whole cooktop off by touching the “ON/OFF” control. 4. Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. - Page 15 3. The boost power will last for 5 minutes and then the zone will go back to the power stage which was set before boost. 4. If you want to cancel the boost during this 5 minutes, touch the heating zone selection button, an indicator next to the key will flash. And then touch the Boost button.
- Page 16 Power Management For IH60BF/IH77BF There are 2 group, for each group, if you need to use boost please decrease the power level of the other zone in the same group to “5” or less first, otherwise and “P” symbols will flash on the display of the select- ed zone and power level “9”...
- Page 17 Using The Keep Warm (For IH60BF/IH77BF/IH90BF) Keep warm function is suitable for keeping food warm. Using The Keep Warm To Get Stable Temperature 1. Touch the heating zone selection button that you wish to use keep warm, an indicator next to the key will flash. 2.
- Page 18 Using The Pause Function- Stop+Go (For IH60BF/IH77BF/IH90BF) Pause function can be used at any time during cooking. It allows to stop the induction cooktop and come back to it. Make sure the cook zone is working. 1. Touch the heating zone selection button that you wish to use STOP+GO, an indicator next to the key will flash.
-
Page 19: Locking The Controls
Locking The Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled. To lock the controls Touch the keylock control. -
Page 20: Using The Timer
Auto Shutdown Protection Auto shutdown is a safety protection function for your induction cooktop. It shut down automatically if ever you forget to turn off your cooking. The default working times for various power levels are shown in the below table: Power level Default working timer (hour) When the pot is removed, the induction cooktop can stop heating... - Page 21 3. Set the time by touching the “-“or “+” control. Hint: Touch the “-“ or ”+” control of the timer once to decrease or increase by 1 minute. Touch and hold the “-“ or “+” control of the timer to decrease or increase by 10 minutes.
- Page 22 3. Set the time by touching the “-“or “+” control of the timer. Hint: Touch the “-“ or ”+” control of the timer once to decrease or increase by 1 minute. Touch and hold the “-“ or “+” control of the timer to decrease or increase by 10 minutes.
-
Page 23: Cooking Guidelines
(set to 6 minutes) (set to 3 minutes) 2. When cooking timer expires, the corresponding heating zone will be automatically switch off and show “H”. NOTE: If you want to change the time after the timer is set, you have to start from step 1. - Page 24 • Some tasks, including cooking rice by the absorption method, may require a setting higher than the lowest setting to ensure the food is cooked properly in the time recommended. Searing steak To cook juicy flavoursome steaks: 1. Stand the meat at room temperature for about 20 minutes before cooking.
-
Page 25: Heat Setting
Heat Settings The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the induction cooktop to find the settings that best suit you. Heat setting Suitability •... -
Page 26: Care And Cleaning
Care And Cleaning What? How? Important! 1. Switch the power to the • When the power of the cooktop is Everyday soiling cooktop off. switched off, there will be no ‘hot on glass 2. Apply a cooktop cleaner surface’ indication but the cooking (fingerprints, while the glass is still warm zone may still be hot! Take... -
Page 27: Hints And Tips
Hints And Tips Problem What to do Possible causes The induction No power. Make sure the induction cooktop is cooktop cannot connected to the power supply be turned on. and that it is switched on. Check whether there is a power outage in your home or area. - Page 28 Problem Possible causes What to do Pans do not The induction cooktop Use cookware suitable for induction become hot and cannot cooking. See section ‘Choosing the appears in the detect the pan because it is right cookware’. display. not suitable for induction The induction cooktop Centre the pan and make sure that cannot...
-
Page 29: Failure Display And Inspection
Failure Display and Inspection If an abnormality comes up, the induction cooktop will enter the protective state automatically and display corresponding protective codes: Problem What to do Possible causes Temperature sensor of the Please contact the supplier. F3/F4 induction coil failure Temperature sensor of the Please contact the supplier. -
Page 30: Installation
Cooking cooktop IH60BF/IH77BF Cooking Zones 4 Zones Supply Voltage 220-240V~, 50/60Hz Installed Electric Power 6600W-7400W Product Size LxWxH 23.2″ 20.5″ 2.4″ 30.3″ 20.5″ 2.4″ Building-in Dimensions AxB 22.0″ 19.3″ Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice. - Page 31 Under any circumstances, make sure the Induction cooker cooktop is well ventilated and the air inlet and outlet are not blocked. Ensure the Induction cooker cooktop is in good work state. As shown below: Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 30.0’’.
- Page 32 • you consult local building authorities and by-laws if in doubt regarding installation. • you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the cooktop. When you have installed the cooktop, make sure that •...
- Page 33 Glass Retaining bracket Screw ST3.5*8 mm worktop/kitchen cabinet Bottom case Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The cooktop will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the cooktop electronics.
-
Page 34: Connecting The Cooktop To The Mains Power Supply
Cul out worktop to supplied dimensions shown (fig. 1) with suitable equipment. Seal the cutedge of the worktop using silicone or PTFE and allow to dry prior to fitting the hob. Fig 2 Stretch out the supplied seal along the underside edge of the hob ensur- ing the ends overlap. - Page 35 The power supply cable must not touch any hot parts and must be positioned so that its temperature will not exceed 75˚C at any point. Check with an electrician whether the domestic wiring system is suitable without alterations. Any alterations must only be made by a qualified electrician.
- Page 36 SCAN ME 8350 Patriot Blvd STE B, 1 (844) 538-7890 www.gaslandchef.com support@gaslandchef.com N. Charleston, SC 29418...
