- Page 1 Quick Start Guide Pegasus 8 LED Fresnel 1400 East 66th Avenue - Denver, CO 80229 USA +1 303 500-7072 - www.Altmanlighting.com...
- Page 2 Altman Lighting Regional Manager. El material en este manual es solo para fines informativos y está sujeto a cambios sin previo aviso. Altman Lighting no asume responsabilidad por errores u omisiones que puedan aparecer en este manual. Para comentarios y suger- encias sobre correcciones y/o actualizaciones a este manual, por favor visite el sitio web de Altman Lighting en www.
-
Page 3: Important Information
Pegasus 8 LED Fresnel Quick Start Guide Important Information Product Safety Notices When using electrical equipment, basic safety precautions should always be followed including the following: 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. Do not mount near gas or electric heaters. -
Page 4: Fcc Notice
Altman Lighting, Inc., a subsidiary of Altman Stage Lighting Company, Inc., herein referred to as Altman, warrants each new product (except for spare parts or products Altman does not manufacture) for a period of TWO (2) years from date of shipment to correct by repair or replacement any part defect due to faulty material or workmanship. Under these same terms products with an LED light source shall be warranted for a period of FIVE (5) years and One (1) day. -
Page 5: Table Of Contents
Pegasus 8 LED Fresnel Quick Start Guide Table Of Contents Important Information Product Safety Notices Warnings FCC Notice Altman Lighting Product Warranty Warranty Terms Warranty Service Table Of Contents Installation & Set Up Overview Components Power Requirements Connecting Power Dimming Curve Switch... -
Page 6: Installation & Set Up
Quick Start Guide Pegasus 8 LED Fresnel Installation & Set Up Overview The Altman Pegasus 8 Fresnel is a 8-inch white output LED Fresnel that is both Mains Dimmable and DMX controlled all in one luminaire Components Pegasus 8 Pegasus 8... -
Page 7: Power Requirements
POWER CONNECTION - DMX CONTROL MODE: The PEGASUS Luminaire should be connected to either a constant circuit or relay device when in DMX mode. Note: Altman Lighting recommends that all Non- Dim circuits powering solid state luminaires are routinely powered down to both conserve energy and maximize luminaire performance. -
Page 8: Dmx / Mains Dim Switch
Figure 4: Daisy Chain Power and Data Diagram Connecting DMX The Pegasus 8 LED Fresnel offers two DMX512 connections. One for DMX Input (from a DMX source) and one DMX throughput (out). Basic DMX512 installation consists of connecting multiple DMX controlled Pegasus 8 LED Fresnel together (up to 32 Total devices per DMX string) in “daisy-chain”... -
Page 9: Connecting To A Dimming Systems
Pegasus 8 LED Fresnel Quick Start Guide Connecting to a Dimming Systems When Pegasus is set to Mains Dim Mode the luminaire should be connected to a Phase cut dimmer either for-ward or reverse phase. Typical Phase Cut dimmers include: SCR’s (Silicon Controlled Rectifiers), IGBT’s (Insul-lated Gate Bipolar Transistors), and TRIAC dimmers). -
Page 10: Pegasus Accessory Holder
Quick Start Guide Pegasus 8 LED Fresnel Pegasus Accessory Holder Each Pegasus LED Luminaire is equipped with an accessory holder to hold the supplied color frame Note: The accessory holder can also hold a 8inch Barndoor. Barndoor is sold separately. -
Page 11: Programming And Settings
Pegasus 8 LED Fresnel Quick Start Guide Programming and Settings Programming Buttons Overview Spectra Series Products offer three (3) buttons to program the fixture. With these three buttons, you can program or set. To activate the three digit display, press any of the three button. After 4 seconds of inactivity, the display will go blank. -
Page 12: Switching Between Dmx Mode / Local Channel Control
Quick Start Guide Pegasus 8 LED Fresnel Switching Between DMX Mode / Local Channel Control DMX Mode DMX Mode is used for Setting DMX Address, Absence of DMX, Dimming Curve and DMX Termination Local Channel Control Mode Local Channel Control is a special mode that allows you to manually control the output of the fixture To Switch between Local Channel Control and DMX Mode: 1. -
Page 13: Absence Of Dmx
Pegasus 8 LED Fresnel Quick Start Guide Absence of DMX When connected to a DMX network, if there is a loss of signal the following settings will effect the behavior of the Pegaus Luminaire upon signal loss. This mode can be programmed by entering a number greater than 900. There are four (4) different options upon the loss of signal. -
Page 14: Locked / Unlock Mode
Quick Start Guide Pegasus 8 LED Fresnel Locked / Unlock Mode The luminaire can have its buttons disabled or locked so unwanted changes cannot be made. To Lock or Unlock the Fixture Buttons: 1. Wait until the display goes blank 2. -
Page 15: Cleaning And Care
If you have any questions regarding the use or care of your Pegasus LED Lumi- naire, please contact Altman Lighting technical support or your local Authorized Dealer. If you have any questions regarding the use or care of your Pegasus LED Luminaires, please contact Altman Lighting technical support at support@altmanlighting.com... -
Page 16: Troubleshooting
The chart below provides possible causes and remedies for various error messages and/or symptoms. If this chart is unable to address your issue, please contact your authorized dealer or Altman customer service for assistance. Any service and maintenance (including troubleshooting), other than described herein should be per- formed by an Authorized Altman Lighting Dealer or Service Center. -
Page 17: Specifications
Pegasus 8 LED Fresnel Quick Start Guide Specifications Specifications LED Source Electrical LED Chip Available in 2700K, Voltage Range 100-240 VAC 50/60 Hz 3000K, 4000K, or 5000K Input Connection PowerCon In and Thru Max Power Consumption 150W Current Inrush 15Apk Max 1/2 cycle @230VAC LED Refresh Rate Array rating >50,000 hours to...
