- Page 1 Lighting Lighting BRINGING IMAGINATION TO LIGHT BRINGING IMAGINATION TO LIGHT LED Ellipsoidal Spot LED ELLIPSOIDAL SPOTLIGHT 20160926 PRODUCT MANUAL...
- Page 2 La compagnie Altman Lighting n’assume aucune responsibilité sur toute erreur ou ommis- sion inscrite dans ce manuel. Pour tous commentaires ou suggestions concernant des corrections et/ ou les mises à jour de ce manuel, veuillez s’il vous plait contacter le bureau de Altman Lighting le plus proche.
-
Page 3: Important Information
It is recommended that a qualified electrician perform this installation. WARNING: The PHX LED Ellipsoidal IS NOT for residential installation or use. IMPORTANT! -
Page 4: Fcc Notice , Dmx Resources, Altman Standard Warranty
Altman Lighting, Inc., a subsidiary of Altman Stage Lighting Company, Inc., herein referred to as Altman, war- rants each new product (except for spare parts or products Altman does not manufacture) for a period of TWO (2) years from date of shipment to correct by repair or replacement any part defect due to faulty material or workmanship. -
Page 5: Table Of Contents
PHX LED Ellipsoidal Installation & User’s Manual TABLE OF CONTENTS Important Information FCC Notice , DMX Resources, Altman Standard Warranty Table of Contents - this page About this Manual Product Descriptions - Part Number Ordering Accessories Product Overview and Installation... -
Page 6: About This Manual
PRODUCT DESCRIPTIONS The 5°, 10°, 19°, 26°, 36° and 50° fixed focus and 15°-30° 30°-50° Zoom PHX LED Ellipsoidals are state of the art luminaires in function, style, and efficiency. These ellipsoidals have been designed and engineered with a number of innovative details and features enhancing versatility and efficiency without sacrificing performance. -
Page 7: Accessories
Color Frame, 71/2” x 71/2” Malleable Iron Pipe Clamp SC-36-BK 36” Black Safety Cable with Spring Clamp PHXZ-SFLGSB PHX Soft Focus lens with B Size Pattern Holder PCL-PBG-12-* 5’ 20A powerCON with Parallel Blade U Ground (Edison) INCLUDED ACCESSORIES - FIXED FOCUS FIXTURES 4.5-CF* Color Frame, 61/4”... -
Page 8: Product Overview And Installation
PHX LED Ellipsoidal Installation & User’s Manual PRODUCT OVERVIEW - Fixed Focus Yoke Lens Barrel Slot Lens Barrel PHX 250 PHX Engine Housing Color Frame Holder PHX 150 PAGE 6... - Page 9 PHX LED Ellipsoidal Installation & User’s Manual PRODUCT OVERVIEW - Zoom Fixtures Yoke Lens Barrel Color Frame Holder PHX Engine Housing 30-50 Degree Zoom 15-30 Degree Zoom PAGE 7...
- Page 10 PHX LED Ellipsoidal Installation & User’s Manual PRODUCT OVERVIEW - Zoom Focus Continued 8.11in 205.93mm 30.00in 762.00mm PHX 150 w/ 15-30 Degree Zoom PHX 250 w/ 15-30 Degree Zoom 10.02in 254.38mm 10.6in 269.24mm 8.11in 205.93mm 30.00in 762.00mm 10.02in 254.38mm PHX 150 w/ 30-50 Degree Zoom PHX 250 w/ 30-50 Degree Zoom 10.6in 269.24mm...
-
Page 11: Yoke And Shutter Assembly
PHX LED Ellipsoidal Installation & User’s Manual YOKE AND SHUTTER ASSEMBLY YOKE & SHUTTER ASSEMBLY USING SHORT YOKE POSITION 1. Remove T-Handle and its Shutter Rotation Lock Knob 2. associated hardware. 3. Remove yoke bolts, cup washers Rotating Shutter Assembly: ***Shutter Assembly Screw Guides and pivot covers. -
Page 12: Accesory Instructions
Warning: Supporting mechanism and structure must be capable of supporting the weight of the PHX LED Ellipsoidal. For product technical information (including weight), refer to "TECHNICAL SPECIFICATIONS" on page 19. Check applicable codes in your area for specific requirements. -
Page 13: Cleaning And Care
Unlike most fixtures, the PHX LED Ellipsoidal Luminaire requires very little routine maintenance by the user. This section covers portions of the luminaire that can be removed for cleaning. The PHX LED Ellipsoidal Luminaire special care when it comes to cleaning the lens assembly. -
Page 14: Fixed Focus Lens Positioning
PHX LED Ellipsoidal Installation & User’s Manual CLEANING / REPLACING LENSES WARNING: Never use glass or window cleaner or any abrasive material to clean CLEANING / REPLACING LENSES a lens. These types of cleaners will stain the lens surface. Abrasive materials will damage the surface of the lens. -
Page 15: Installation And Set Up
A qualified electrician must perform this installation. Note: The PHX LED Ellipsoidal Luminaire is intended for installation in accordance with the National Electric Code and local regulations. To assure full compliance with local codes and regulations, check with your local electrical inspector before installation. -
Page 16: Operation Menu And Options
PHX LED Ellipsoidal Installation & User’s Manual OPERATION MENU AND OPTIONS Button Control Explanation Button Control / Function MENU Move to previous menu and cancel current action ENTER Select and accept current action Scroll up through options and selections DOWN... - Page 17 PHX LED Ellipsoidal Installation & User’s Manual OPERATION MENU AND OPTIONS CONTINUED The table below demonstrates the Player Options you can choose from. Menu Category Control Type Option 1 Option 2 Option 3 Factory Default Enable/Disable Off/On Delay 1 sec to 99 min 2.0 Seconds...
-
Page 18: Operation Menu And Options
PHX LED Ellipsoidal Installation & User’s Manual OPERATION MENU AND OPTIONS CONTINUED The tables below demonstrates the Fixture Settings, Options, and Fixture Information you can choose from. Using the same techniques shown on the two previous pages you can select, view, and edit these options. -
Page 19: Phx150 Rdm Ansi E1.20 Information
PHX LED Ellipsoidal Installation & User’s Manual PHX150 RDM ANSI E1.20 INFORMATION PHX 150 Supported Parameters ON----------------01 4F 6E 20 20 20 20 20 20 Smoothing 0xA104 OFF---------------00 4F 66 66 20 20 20 20 20 OFF---------------00 4F 66 66 20 20 20 20 20... -
Page 20: Phx250 Rdm Ansi E1.20 Information
PHX LED Ellipsoidal Installation & User’s Manual PHX250 RDM ANSI E1.20 INFORMATION PHX 250 Supported Parameters ON----------------01 4F 6E 20 20 20 20 20 20 Smoothing 0xA104 OFF---------------00 4F 66 66 20 20 20 20 20 Dmx Loss 0x9023 HOLD-------------01... -
Page 21: Master Channel - Fixture Resolution & Configuration
PHX LED Ellipsoidal Installation & User’s Manual MASTER CHANNEL - Fixture Resolution & Configuration Master Channel is selectable as ON or OFF and provides a Master Fade channel that dims all 4 colors proportionally at the same time in order to maintain the color. This installs an intensity channel at the end of the DMX string. -
Page 22: Master Channel - Fixture Resolution & Configuration
PHX LED Ellipsoidal Installation & User’s Manual MASTER CHANNEL - Fixture Resolution & Configuration Fixture Type: RGBA DMX Map 8 Bit (one DM X channel per color) this is normal resolution Channel 1 White Master Channel Off Bit Type Channel 1... -
Page 23: Technical Specifications
North American Models: ETL / cETL Listed (NON-IC Rated luminaire) International Models: CE Marked. TROUBLE SHOOTING WARNING! Any service and maintenance (including troubleshooting), other than described herein should be performed by an Authorized Altman Lighting Dealer or Service Center. Description Symptom Possible Cause and Action No Light Output. - Page 24 BRINGING IMAGINATION TO LIGHT BRINGING IMAGINATION TO LIGHT Corporate Offices: 57 Alexander Street Yonkers, NY 10701 (914)-476-7987 www.altmanlighting.com Document Number: 49-0220 Version as of: 20160926 PHX LED Ellipsoidal Spot Luminaire Installation & User’s Manual ©2016 Altman Stage Lighting Co. Inc., All rights reserved.
