Page 1
Anti-Theft Tablet Desk Stand
360° Rotation, Swivel & Tilt
Black
Black &
White
For more information: barkanmounts.com
If you are satisfied with the product, please give us a 5 stars rating on the website you bought it from. If you
are not satisfied please contact us at
https://www.barkanmounts.com/support
and we will solve the problem for you.
Tablet Size
Tablet Weight
7"-14"
US
EU
17.7cm-35.5cm
3.1lbs
1.4kg
Safety instructions and installation warnings (provided separately)
must be read in full, prior to assembly.
Advertisement
Related Manuals for Barkan T71HL
Summary of Contents for Barkan T71HL
- Page 1 Page 1 Anti-Theft Tablet Desk Stand 360° Rotation, Swivel & Tilt Black Black & White For more information: barkanmounts.com If you are satisfied with the product, please give us a 5 stars rating on the website you bought it from. If you are not satisfied please contact us at https://www.barkanmounts.com/support and we will solve the problem for you.
-
Page 2: Included Parts
Page 2 Included Parts not to scale Stand Clamp Allen head bolt Washer Screw Anti-slip sticker PVC pads Allen key Required Tools No. 2+3 1/8” 3 mm... - Page 3 Page 3 Place the PVC adaptors inside the clamp holders Z6 x 2 Loosen the screw, open the ruler on the back according to your device size and tighten the screw. Example – for a device that is 10” to 11”, open the ruler to 10”. Follow the steps according to your preferred method of securing the stand.
- Page 4 Page 4 Optional Attach the adhesive stickers to the bottom of the stand to prevent it from sliding. Optional lock slot Assemble the clamp on to the stand.
- Page 5 Page 5 Locking Open the clamp, relock it and Unlock the clamp Close the clamp on your device take out the key Tilt adjustment 1. Remove the plastic cover. 2. Using the Allen key (Z6) Tighten the screw in order to create the necessary friction for 360 ROTATION the tool-free tilt mechanism.
