Summary of Contents for Barkan 43
- Page 1 3 Movement PLASMA / LCD WALL MOUNT Safety & assembly instructions model Touch & Tilt Max Plasma / LCD 50" / 127cm 132lbs 60kg Barkan ™ A better point of view www.barkanmounts.com Mounting systems...
- Page 2 Page 2 of 7 The provided Screen bolts may change in size according to changing screen requirements 3/8” 7 mm 10 mm 13 mm 5/16” 1/4” 7/16” 1/2” Please make sure that package contains all parts...
- Page 3 Page 3 of 7 Bracket assembly to screen K O F B A C E E N S C R Assemble bracket in center CENTER Height adjustment of screen for optimum viewing position...
- Page 4 Page 4 of 7 Concrete, Solid bricks or Hollow Wood stud wall concrete block walls Level, mark and drill Level, mark and drill ‡ ! Assembly to wall Assembly to wall Min 2 Max 9...
- Page 5 Page 5 of 7 Arm assembly Bolt assembly Arm assembly to wall plate TEST 132lbs/60kg Tilt mechanism assembly...
- Page 6 Page 6 of 7 Bolt assembly Tilt mechanism assembly to arm Covers assembly Covers assembly Mount screen to the wall LEFT & RIGHT ADJUSTMENT Easy screen positioning during installation, for enhanced viewing quality QUICK CONNECT...
- Page 7 Page 7 of 7 Safety lock hardware assembly FALL & THEFT PROOF Secure locking system, preventing theft and accidents Padlock not included TOUCH & TILT Tools free tilt Screen leveling 2.5º SCREEN LEVELING Touch&tilt A built-in mechanism to adjust 0º-20º the screen CABLE MANAGEMENT Hides cables inside the mount...
