Page 1
SensoGate WA130H User Manual Retractable Fitting Read before installation. www.knick.de Keep for future use.
Page 2
SensoGate WA130H Supplemental Directives READ AND SAVE THIS DOCUMENT FOR FUTURE REFERENCE. BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT, PLEASE ENSURE A COMPLETE UNDERSTANDING OF THE INSTRUC- TIONS AND RISKS DESCRIBED HEREIN. ALWAYS OBSERVE ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS IN THIS DOCUMENT COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE.
“operating company”) may be conducted, subject to the requirements set forth herein, by placing the product into the service position (SERVICE limit position). If the product is used with any product or part not authorized by Knick, the operating company assumes all risks and liabilities related thereto.
Product Code, p. 12 ➜ The immersion lock can be seen at the yellow indicator ring on the drive unit of the SensoGate WA130H. If the yellow indicator ring is missing, the safeguard func- tion is not available. A mechanical lock prevents the SensoGate WA130H with- out a mounted solid-electrolyte sensor from being moved into the process position (PROCESS limit position).
Safety Accessories, p. 8 ➜ Operating the SensoGate WA130H without a retainer or locking clamp is at the risk of the operating company. The operating company must take action to rule out the possibility of the screw joint cou- pling nut accidentally loosening.
The retainer clamp prevents the coupling nut of the Ingold socket (25 mm) screw joint from accidentally coming loose. The wires of the retainer clamp connect the SensoGate WA130H to the cus- tomer’s process port. A locking lug on the retainer clamp engages in the groove of the coupling nut (form‑fit).
• Non-metallic components are cleaned with a moist cloth only. Mechanically Generated Sparks Single impacts on metal parts or collisions between metal parts of the SensoGate WA130H-X are not a potential ignition source if the following conditions are met: • Possible impact velocity is less than 1 m/s.
Maintenance, p. 33 ➜ Lubricants Only use lubricants approved by Knick. Special applications or upgrades to special lubricants are avail- able on request. Usage of any other lubricants shall constitute an unintended use of the product. Maintenance, p. 33 ➜...
• As applicable, supplementary datasheet for special versions 2.2 Product Identification The different versions of the SensoGate WA130H are encoded in a model designation. The model designation is stated on the nameplate, the delivery note, and the product packaging. Nameplates, p. 14 ➜...
SensoGate WA130H 2.2.2 Product Code Basic Unit WA130H – _ _ _ _ _ _ _ _ – _ _ _ Explosion protection ATEX Zone 0 – None – Sensor Sensor, ⌀12 mm with PG13.5 pH sensor ⌀12 mm with pressurization unit, pressure chamber for compressed air supply Optical sensor, ⌀12 mm with PG 13.5...
Page 13
SensoGate WA130H Basic Unit WA130H – _ _ _ _ _ _ _ _ – _ _ _ Connection PEEK media connection PEEK media connection with integrated connection for additional medium Special version None - 0 0 0 Equipped with special grease (provided by customer)
SensoGate WA130H 2.3 Nameplates The SensoGate WA130H is identified by nameplates on the drive unit and the process unit. The infor- mation provided on the nameplates varies according to the version of the SensoGate WA130H. Nameplate, Version Without Ex Approval Note: The figure shows a nameplate for the SensoGate WA130H-N version by way of example.
Page 15
SensoGate WA130H Nameplate, Version With Ex Approval Note: The figure shows a nameplate for the SensoGate WA130H-X version by way of example. WA130H-**********-*** xxxxxxx / xxxx ® SensoGate 14163 Berlin Process Unit Made in Germany Type WA130H-**********-*** xxxxxxx / xxxx Max.
Permissible Changes, p. 20 ➜ The process connection is used to fasten the SensoGate WA130H to the process port. The pneumatically operated drive unit moves the SensoGate WA130H into the service position (SERVICE limit position) or the process position (PROCESS limit position).
SensoGate WA130H 2.5.1 Retractable Fitting Note: The figure shows an example version of the SensoGate. Product Code, p. 12 ➜ 1 Drive unit 9 Multiplug connection piece 2 Process unit 10 SensoLock 3 Outlet hose (not included) 11 Coupling nut...
SensoGate WA130H 2.5.2 Drives and Sensor Holders Note: The figure shows a selection from the product line. Product Code, p. 12 ➜ 1 Short immersion depth, sensors with solid 2 Short immersion depth, sensors with liquid electrolyte electrolyte...
In the event of a change to the version, the product must be identified accordingly. It is recommended that changes to the SensoGate WA130H be carried out by the Knick Repair Service. After making the necessary changes, a functional and pressure test is carried out and, if necessary, a modified nameplate is attached.
The SensoGate WA130H can assume two limit positions (service or process position). Note: The SensoGate WA130H is only disconnected from the process in the service position (SERVICE limit position). This is not the case in any other position, i.e., there remains contact with the process.
3 Installation 3.1 General Installation Instructions Process Analysis System: Installation Example The SensoGate WA130H is designed for operation within a fully automatic Knick process analysis system. The process analysis system may typically comprise the following products: • Protos industrial transmitter •...
Dimension Drawings, p. 51 ➜ Note: The installation angle of the SensoGate WA130H depends on the sensor type. An installa- tion angle of up to 10° above the horizontal plane is permissible for all sensor types. An installation angle upside down (see view A) is only permitted if using sensors approved for upside-down oper- ation.
Upside-Down Installation If installing the SensoGate WA130H upside down, lay the outlet hose in an arc above the level of the calibration chamber. This prevents gravity from causing the calibration chamber to leak. 1 Calibration chamber...
“Media Connection” for Operation With Process Analysis System When using a Knick process analysis system, all media cables and the connecting cable for limit signals are combined in one hose, the media connection (2). The media connection is connected to the SensoGate WA130H using a shared connector, the multiplug (1).
3.5.2 Multiplug: Installation Check the gaskets and O‑rings of the multiplug (1) for correct positioning and damage, and replace them if necessary. Troubleshooting, p. 41 ➜ Position and connect the multiplug (1) to the SensoGate WA130H. Fasten the multiplug (1) with two screws (2).
Optional: Ensure that installed safety accessories (e.g., ZU0818 retainer clamp) are securely fastened. Safety Accessories, p. 8 ➜ If using the product in hazardous locations, check that the SensoGate WA130H is correctly con- nected to the plant’s equipotential bonding system. Installing and Removing Sensors, p. 29 ➜...
5.1 Moving into the Process Position (PROCESS Limit Position) WARNING! Process, rinse, or additional media, potentially containing hazardous substances, may escape from the SensoGate WA130H. Only move the SensoGate WA130H into the process posi- tion (PROCESS limit position) if a sensor is installed.
Note: The outlet is used to discharge trapped rinse medium and must not be closed. By moving the SensoGate WA130H to the limit positions, pressurized process medium may enter the calibration chamber. When the outlet is closed, this process medium may be compressed and splash out during a sensor replacement.
Note: Rinse the sensor prior to removal in order to prevent entrainment of chemically aggressive process medium in the area of the sensor holders. Move the SensoGate WA130H into the service position (SERVICE limit position). Moving into the Service Position (SERVICE Limit Position), p.
Push in the sensor (3). Note: In the case of inclined installation, turn the electrolyte filling hole towards the top to prevent electrolyte from flowing out during operation of the SensoGate WA130H. Observe any deviating direction of installation specified by the sensor manufacturer.
Note: Rinse the sensor prior to removal in order to prevent entrainment of chemically aggressive process medium in the area of the sensor holders. Move the SensoGate WA130H into the service position (SERVICE limit position). Moving into the Service Position (SERVICE Limit Position), p.
NOTICE! In the event of a malfunction, pressurized process medium, potentially containing hazard- ous substances, may escape from the SensoGate WA130H. Loosen the sensor no more than a maxi- mum of 1.5 turns to ensure that pressure resistance is still available in the event of a malfunction.
To check the function of the immersion lock, the situation of a missing sensor is simulated. Note: The functional test is only available for a SensoGate WA130H with the safeguard “Immersion Lock Without a Mounted Liquid-Electrolyte Sensor”. The safeguard can be seen at the yellow indicator ring (2)
6.3 Corrective Maintenance 6.3.1 Corrective Maintenance Safety Instructions WARNING! Process medium, potentially containing hazardous substances, may escape from the SensoGate WA130H. Follow the safety instructions. Safety, p. 5 ➜ CAUTION! Risk of cutting injuries from broken sensor glass. Handle the sensor with care. Follow the safety instructions in the sensor manufacturer’s documentation.
The coupling nut can be tightened only if the drive unit is cor- rectly inserted into the process unit. Turn the SensoLock ring to the “unlock” position. SensoGate WA130H is unlocked. ✓ Push the drive unit (1)
6.3.4 Immersion Tube: Removal Remove the drive unit (1). Drive Unit: Removal, p. 35 ➜ ✓ SensoGate WA130H is unlocked. Pull on the immersion tube (4) until the process position (PROCESS limit position) is reached. Loosen the screws around 4 rotations using a screwdriver of type TX25 (3)
SensoGate WA130H 6.3.5 Immersion Tube: Installation Install the sensor (4). Installing and Removing Sensors, p. 29 ➜ If the drive unit is not in process position (PROCESS limit position): Firmly push the immersion tube (5) into the sensor protection tube (6), at the same time rotating around 60° clockwise up to the hard stop.
SensoGate WA130H 6.3.6 Calibration Chamber: Removal Note: Service sets ZU0754 or ZU0740 are required to remove the calibration chamber. Tools, p. 50 ➜ Remove the process unit from the drive unit. Drive Unit: Removal, p. 35 ➜ Remove the screws (1) with a screwdriver of type TX25. Keep the screws (1)
✔ 6.3.8 Knick Repair Service The Knick Repair Service offers professional corrective maintenance for the product to the original quality. Upon request, a replacement unit can be obtained for the period of the repair. Further information can be found at www.knick.de.
Faulty multiplug. Send the media connection to your local contact for repair. knick.de ➜ SensoGate WA130H does not move. Multiplug not installed correctly. Install the multiplug correctly. Multiplug: Installation, p. 26 ➜ Sensor not installed correctly. Install the sensor correctly.
Perform maintenance on the drive unit or check the functionality of the process unit using a replacement drive. Troubleshooting unsuccessful: Stop the process; depressurize or drain off the process medium if necessary. Remove the SensoGate WA130H and send it to your local contact for repair. knick.de ➜...
Operation in Hazardous Locations, p. 9 ➜ WARNING! Process or rinse medium, potentially containing hazardous substances, may es- cape from the SensoGate WA130H or the process port. Follow the safety instructions. Safety, p. 5 ➜ Stop the process; depressurize or drain off the process medium if necessary.
SensoGate WA130H 9 Spare Parts, Accessories, and Tools 9.1 Seal Kits The seal kits are available in different materials. The smaller seal kits (“Set X/1”) only contain O-rings for direct contact with the process medium. The extended seal kits (“Set X/2”) also include O-rings for contact with the rinse medium.
Page 45
SensoGate WA130H Seal Kits for Dairy-Pipe, Tri-Clamp, Varivent, BioControl Process Connection Process-wetted Rinse-wetted O-rings O-rings 1 Scraper ring 215.000-420 7 O-ring 20 × 4 mm 2 O-ring 23 × 2 mm 8 O-ring 8 × 2 mm 3 O-ring 13 × 1.5 mm 9 O-ring 4 x 2 mm 4 O-ring 6 ×...
Page 46
SensoGate WA130H Seal Kits for Ingold-Socket H1 Process Connection Process-wetted Rinse-wetted O-rings O-rings 1 Scraper ring 215.000-420 8 O-ring 21 × 2 mm 2 O-ring 23 × 2 mm 9 O-ring 8 × 2 mm 3 O-ring 13 × 1.5 mm 10 O-ring 4 x 2 mm 4 O-ring 6 ×...
SensoGate WA130H 9.2 Spare Parts Safety Label The safety label provides information on the safeguard “Immersion Lock Without a Mounted Solid-Electrolyte Sensor”. Safeguards, p. 6 ➜ Damaged or lost safety labels will be replaced on request. ZU0739 Bellows The bellows (only used on versions with liquid-electrolyte sensors) protect the fit- ting beneath the pressure chamber against external contamination and wear.
Page 48
ZU0713 Hose, 20 m (Extension for ZU0670) This assembly group maintains the defined gauge pressure in the pressure chamber in versions of the SensoGate WA130H for liquid-electrolyte sensors. ZU0759 and ZU0759/1 Protective Cap The protective cap protects against the effects of weather exposure and prevents the ingress of external liquids or particles into the area of the sensor connections.
Page 49
SensoGate WA130H ZU0717 (Straight) Weld-In Socket for Boiler Walls Process connection: Ingold socket (Ø 25 mm, G1¼) Weld-in sockets with an HSD (Handling Safety Design) safety function feature spe- cial grooves on the sealing surface for the process connection O-ring. These grooves prevent the O-ring from sealing if the Ingold coupling nut loosens inad- vertently when process pressure is present.
The retainer clamp ZU0818 prevents the coupling nut of the Ingold socket (25 mm) screw joint from accidentally coming loose. The wires of the retainer clamp connect SensoGate WA130H to the customer’s process port. A locking lug on the retainer clamp engages in the groove of the coupling nut (form-fit).
SensoGate WA130H 10 Dimension Drawings Retractable Fitting for Solid-Electrolyte Sensor, Short and Long Immersion Depth Note: All dimensions are given in millimeters [inches]. PG 13.5 Ø 12 [0.47]...
Page 52
SensoGate WA130H Retractable Fitting for Liquid-Electrolyte Sensor, Short and Long Immersion Depth Note: All dimensions are given in millimeters [inches]. Ø 12 [0.47]...
Page 53
SensoGate WA130H Process Connections Dairy pipe DIN 11851 DN 40 ... DN 100 Short immersion depth (ID) Dairy pipe DIN 11851 DN 40 ... DN 100 Long immersion depth (ID) Clamp 1″ ... Clamp 3.5″ Short immersion depth (ID)
Page 54
SensoGate WA130H Clamp 2″ ... Clamp 3.5″ Long immersion depth (ID) Varivent ≥ DN 50 Short immersion depth (ID) Varivent ≥ DN 65 Short immersion depth (ID)
Page 55
SensoGate WA130H Varivent ≥ DN 80 Long immersion depth (ID) 25 mm Ingold socket BioControl DS 50 or DS 65...
Pressure in pressure chamber 0.5 … 1 bar (7.25 … 14.5 psi) above process pressure of max. 7 bar (101.5 psi) For compressed air, rinse and calibration media (re- Unical 9000 multiplug tractable fitting control air) Weight Depending on material and version. Please contact Knick or your designated sales representative for detailed infor- mation.
Page 57
SensoGate WA130H Abbreviations Width across flats ATEX Atmosphères Explosibles (explosive atmospheres) Conformité Européenne (European conformity) Classification, labeling, and packaging Deutsches Institut für Normung (German Institute for Standardization) Diamètre nominal (nominal size) EPDM Ethylene propylene diene monomer rubber European Union U.S. Food and Drug Administration...
SensoGate WA130H Technical Terms CE Marking Manufacturer’s declaration, in accordance with EU Regulation 765/2008, that the product is in conformity with the appli- cable requirements set out in the European Union harmonization legislation providing for its affixing. Corrective Maintenance Measures taken to return an item under review to an operational condition, with the exception of improvements.
SensoGate WA130H Index Accessories General Installation Instructions Accessory tool Genuine spare parts Accompanying slip, seal kit Ambient temperature ATEX certificate Hazardous locations Hazardous substances Highly efficient charge-generating mechanisms Bellows Ignition sources Calibration chamber Immersion Lock Without a Mounted Liquid-Electrolyte Accessory tool, O-rings 50...
Page 60
SensoGate WA130H Nameplate Safeguards Drive unit, with Ex approval 15 Overview 6 Drive unit, without Ex approval 14 Retrofit 20 Process unit, with Ex approval 15 Safety accessories Process unit, without Ex approval 14 Locking clamp 8 Notes on safety information Retainer clamp K8 8...
Page 62
Knick Elektronische Messgeräte GmbH & Co. KG Headquarters Beuckestraße 22 • 14163 Berlin Germany Phone: +49 30 80191-0 Fax: +49 30 80191-200 info@knick.de www.knick.de Local Contacts www.knick-international.com Translation of the original instructions Copyright 2023 • Subject to change Version 6 • This document was published on November 27, 2023.
