S Y S T E M S
Getting Started with Mira Connect™
Introduction
Mira Connect is an AV control system that communicates with and controls AV products over an Ethernet network, RS‑232
using a Global Caché IP2SL, Infra‑Red (IR) using a Global Caché IP2IR, or with contact closures using a Global Caché IP2CC.
If you are just getting started with Mira Connect, please watch our
see our
additional
resources, see our
Mira Connect Administrators
When controlling an AV product with RS‑232, see the
and read our
RS‑232 best practices
Figure 1:
The Mira Connect AV control system supports thousands of devices and is used in a wide variety of applications.
A typical application will involve Mira Connect controlling one or more displays, a DSP device, video switching, and other
equipment, including contact closures for raising or lowering a screen.
Figure 2:
Mira Connect typically controls displays and projectors, cameras, video switchers, DSP audio devices, and more.
Aveo Systems, Inc. • 4455 Lower Roswell Road • #681593 • Marietta, GA 30068
Phone: +1.678.653.7090 • Email: sales@aveosystems.com •
IT Network Basics for AV Professionals
Guide.
Global Caché Integration Guide
and
RS‑232 troubleshooting
Video Sources
Video
Switcher
Tuner
Camera
PC-based
Soft Codec
Audio Sources
DSP
Audio Processor
aveosystems.com
Getting Started with Mira Connect
short training
videos, review our
article, and find even more information in the
for how to configure a Global Caché IP2SL
articles.
Projection Screen
and motor
Display
Loudspeakers
Amplifier
1
Copyright © Aveo Systems, Inc. All rights reserved.
technical
documents,

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mira Connect and is the answer not in the manual?

Questions and answers

Related Manuals for Aveo Systems Mira Connect

Summary of Contents for Aveo Systems Mira Connect

  • Page 1 Introduction Mira Connect is an AV control system that communicates with and controls AV products over an Ethernet network, RS‑232 using a Global Caché IP2SL, Infra‑Red (IR) using a Global Caché IP2IR, or with contact closures using a Global Caché IP2CC.
  • Page 2 If you don’t already have an account, you’ll need to create one. There is no cost to create a Mira Portal account. Next, you’ll pair a Mira Connect to the room. Use the Preview Mira Connect in a web browser feature if you don’t have a Mira Connect yet.
  • Page 3 Step 3. Pair Mira Connect to the room in Mira Portal. If you have a Mira Connect appliance, connect it to the network and power it on. Mira Connect appliances can use a PoE network connection and/or use a separate power supply. Mira Connect requires on‑site WAN access to pair with the room in Mira Portal.
  • Page 4 1 3 1 4 1 1 Expires in 60 minutes Figure 4: From the Mira Connect touchscreen, select the language, select the network connection, and receive a pairing code from Mira Portal. Step 4. Add an AV product in Mira Portal.
  • Page 5 Click ADD to add equipment to the room. Select the product family from the list of equipment shown. Aveo Systems, Inc. • 4455 Lower Roswell Road • #681593 • Marietta, GA 30068 Copyright © Aveo Systems, Inc. All rights reserved.

  • Page 6: Add Equipment

    In this example, there is a VIDEO INPUTS tab that for defining video input sources. Aveo Systems, Inc. • 4455 Lower Roswell Road • #681593 • Marietta, GA 30068 Copyright © Aveo Systems, Inc. All rights reserved.
  • Page 7 To find the correct IP address, navigate the product’s user interface and find the IP address or set a static IP address. Edit the equipment in Mira Portal to change the IP address used by Mira Connect to the correct IP address of the device.
  • Page 8 If there are issues, including using the same control point more than once, edit the Aveo Systems, Inc. • 4455 Lower Roswell Road • #681593 • Marietta, GA 30068 Copyright © Aveo Systems, Inc. All rights reserved.

  • Page 9: Troubleshooting Connection Issues

    • Test that Mira Connect can power on and power off the device using Wake‑on‑LAN. If the device will not power on, double check the MAC address for the device, and confirm that the device’s Wake‑on‑LAN mode has been enabled. See the product’s documentation for how to enable Wake‑on‑LAN.
  • Page 10 S Y S T E M S Troubleshooting Tips when Controlling over IR • If Mira Connect cannot connect to an AV product controlled over IR, ensure the IP address entered for the AV product is the correct IP address for the Global Caché IP2IR interface.
  • Page 11 For more information please contact our Support Department at support@aveosystems.com. About Aveo Systems Aveo Systems is a leading provider of intuitive and easy‑to‑use AV control solutions for audio, video, and collaboration, improving how systems are used and managed by customers worldwide. For contact information, see AveoSystems.com/contact‑us.
